Signal name
Pin (J2)
83
I2S_SDO3
84
SPDIF_TX
85
I2C2_SDA
86
GND
87
I2C1_SDA
88
I2C2_SCL
89
I2C4_SDA
90
I2C1_SCL
91
UART2_RX
92
I2C4_SCL
93
UART3_RX
94
UART2_TX
95
UART3_RTSn
96
UART3_TX
97
PWM1
98
UART3_CTSn
99
PWR_KEY
100
GPIO7_C5_D

How to use the MINI3288 module

2.1 Connectors

◆ PCB dimension of the connectors
Customize the embedded system based on
Fuction 1
Power Ground
SC_RST
SC_CLK
IR_RX or PWM2
GPS_MAG or HSADC_D0_T1
IR_TX or PWM3 or EDPHDMI_CEC
GPS_SIG or HSADC_D1_T1
GPS_RFCLK or GPS_CLK_T1
12
Your Idea
IO Type
Fuction 2
GPIO6_A7_d
I/O
GPIO6_B3_d
I/O
GPIO6_B1_u
I/O
P
GPIO8_A4_u
I/O
GPIO6_B2_u
I/O
GPIO7_C1_u
I/O
GPIO8_A5_u
I/O
GPIO7_C6_u
I/O
GPIO7_C2_u
I/O
GPIO7_A7_u
I/O
GPIO7_C7_u
I/O
GPIO7_B2_u
I/O
GPIO7_B0_d
I/O
GPIO7_A1_d
I/O
GPIO7_B1_u
I/O
I
GPIO7_C5_d
I/O
