The 2024 version of the PorkBarrel has no circuit changes and some minor layout adjustments.
The PCB has been converted from a 2-layer to 4-layer design for low noise operation.
The Pork Barrel is a clone of the classic Boss® CE-2™. The CE-2™ has a signature sound and
been a staple of many guitar and bass pedal boards for decades. Next to the EHX Small Clone, it is
one of the most instantly recognizable chorus effects out there. Even if you don't like chorus, this is
one of the best analog ones ever made.
The Pork Barrel is designed to utilize several different BBD types (MN3207 or MN3007) depending
on availability and price. Minimal modifications are required to set the build up for these different
BBDs, and this will be explained in detail later on in this document. A BLEND control mod has also
been added. This allows for both a chorus and vibrato effect (by eliminating the dry signal). It is
completely optional.
•
RATE: Chorus speed from slow to fast.
•
DEPTH: Chorus depth from min to max.
•
BLEND: Mix of dry, chorus and vibrato. CCW is dry (no modulation), 1/4 up to middle is chorus
and fully CW is vibrato.
•
T1: Sets he bias of the chorus effect.
Further Study:
https://www.electrosmash.com/boss-ce-2-analysis
Terms of Use:
You are free to use purchased PorkBarrel24 circuit boards for both DIY and small commercial operations. You may not offer PorkBarrel24 PCBs for
resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance
for is available via the
available to respond via email in a timely and continuous manner, and (2) posting technical problems and solutions in the forum creates a record from which other
members may benefit.
All copyrights and registered trademarks are property of their original owners. Any mention of trademarked or intellectual properties in this documents is purely for
comparative purposes.
