Chevrolet Corvette C7 / C7 Z06
Quarter Panel Intake Vents 2015-2019 Installation
[CF-700804]
Components List:
2 x Carbon Fiber Quarter Panel Vent
(Left and Right)
Approximate Installation Time:
Installation Procedures:
APR Performance, Inc.
4850 Murrieta St
Chino, CA 91710 U.S.A
Phone: (909) 594-3796 Fax: (909)594-3926
sales@aprperformance.com
WWW.APRPERFORMANCE.COM
1 Hour
1. Unscrew and remove all 3 torx
screws holding the rear quarter
pedal near the door pillar.
2. Open the rear trunk hatch and
unscrew all 4 torx screws holding
the top side quarter panel. After
this step is completed, you can
gently pull the panel away from
the car body.
Advertisement
Related Manuals for APR PERFORMANCE CF-700804
Summary of Contents for APR PERFORMANCE CF-700804
- Page 1 4 torx screws holding the top side quarter panel. After this step is completed, you can gently pull the panel away from the car body. APR Performance, Inc. 4850 Murrieta St Chino, CA 91710 U.S.A Phone: (909) 594-3796 Fax: (909)594-3926 sales@aprperformance.com...
- Page 2 4. Remove # 3 secure nut on the back side of the vent. 5. Remove all 3 stud inserts from the factory vent and install them over to the carbon fiber one. APR Performance, Inc. 4850 Murrieta St Chino, CA 91710 U.S.A Phone: (909) 594-3796 Fax: (909)594-3926 sales@aprperformance.com...
- Page 3 Note: using a flat panel tool will help getting the weather strip to stay on top of the panel. APR Performance, Inc. 4850 Murrieta St Chino, CA 91710 U.S.A Phone: (909) 594-3796 Fax: (909)594-3926...
- Page 4 WWW.APRPERFORMANCE.COM 8. Reinstall all 7 torx screws back to the panel. 9. Repeat all steps to other side. Installation is now complete! APR Performance, Inc. 4850 Murrieta St Chino, CA 91710 U.S.A Phone: (909) 594-3796 Fax: (909)594-3926 sales@aprperformance.com...
