Exige GTC-200 Wing Installation Manual
Components List:
1 x GTC-200 Wing
2 x Upper Brackets (Elise/Exige)
2 x Carbon Fiber Round Side Plates
2 x Black aluminum Pedestals (Exige)
2 x Rubber Gaskets(for pedestal cut as
needed)
2 x Adjustment Rods
4 x U-brackets w/ Rubber Gaskets
2 x Long Support Rods
8 x M6x25mm Bolts (for U-brackets
and Upper Brackets)
4 x M6 Washers
4 x M6 Nuts
WWW.APRPERFORMANCE.COM
Approximate Installation Time:
4 x M6x30mm Studs (for Base Stands)
4 x M8x30mm Bolts (for U-brackets)
6 x M8x20mm bolts
4 x M6x20mm APR Stainless Bolts
10x M8 Nuts
3 x Allen Keys
APR Performance, Inc.
4850 Murrieta St
Chino, CA 91710 U.S.A
Phone: (909) 590-3796
sales@aprperformance.com
1 Hour
Advertisement
Related Manuals for APR PERFORMANCE Exige GTC-200 Wing
Summary of Contents for APR PERFORMANCE Exige GTC-200 Wing
- Page 1 WWW.APRPERFORMANCE.COM Exige GTC-200 Wing Installation Manual Components List: Approximate Installation Time: 1 Hour 1 x GTC-200 Wing 2 x Upper Brackets (Elise/Exige) 4 x M6x30mm Studs (for Base Stands) 2 x Carbon Fiber Round Side Plates 4 x M8x30mm Bolts (for U-brackets)
- Page 2 Note: Professional Installation Recommended Remove two factory bolts and washers from the inside of the trunk as shown. Apply masking tape to the center, left, and right as shown. The left and right tape placements are approximately above the removed bolts and washers. Mark a line at 9.5”...
- Page 3 Note: Professional Installation Recommended Ensure that both left and right lines are exactly 19” apart along their entire lengths. Mark a small line at ¾” ahead of the rear edge. Line up a pedestal with the 3/4” line and mark hole locations. Insert the studs into the pedestal, and double check the hole you marked line up.
- Page 4 Note: Professional Installation Recommended Assemble the upper brackets, pedestals, and adjustment rods to the wing. Tighten the bolts/nuts just enough so there is no play in the pedestals. a. Place the wing/pedestal assembly onto the left and right tapes. b. Open and close the rear trunk lid to make sure there is enough space to clear the airfoil.
-
Page 5: Installation Is Now Complete
You should be able to turn the Adjustment Rods by hand.) Install the side plates using the APR bolts and washers. Make sure the APR Performance Logo is on the trailing edge of the air foil. Installation is now complete!
