Installation Manual
Vehicle: 2006-2015 Mazda Miata NC
Product: GTC-200 Wing
APR Performance, Inc.
4850 Murrieta St
Chino, CA 91710 U.S.A
Phone: (909) 594-3796 Fax: (909)594-3926
sales@aprperformance.com
1. Place strips of
masking tape on
the side edges of
the trunk lid.
2. Mark a line at 10"
from the front of
the leading edge
on the deck lid.
See photo.
3. Place the billet
base plate with
front leading edge
to the 10" mark
line and lining up
the outer edge
with the deck's
edge.
4. Mark 2 mounting
holes to the trunk
lid with a pen or
pencil.
Advertisement
Related Manuals for APR PERFORMANCE GTC-200 Wing
Summary of Contents for APR PERFORMANCE GTC-200 Wing
- Page 1 Installation Manual Vehicle: 2006-2015 Mazda Miata NC Product: GTC-200 Wing 1. Place strips of masking tape on the side edges of the trunk lid. 2. Mark a line at 10” from the front of the leading edge on the deck lid.
- Page 2 Note: Do not tighten all the nuts down. You need to leave the mount a little loose for aligning the wing upper bracket later. APR Performance, Inc. 4850 Murrieta St Chino, CA 91710 U.S.A Phone: (909) 594-3796 Fax: (909)594-3926 sales@aprperformance.com...
- Page 3 10. You can start tightening the bottom mount nuts. 11. Adjust the wing angle to where you want it then begin tightening all M8 bolts. Installation Complete. APR Performance, Inc. 4850 Murrieta St Chino, CA 91710 U.S.A Phone: (909) 594-3796 Fax: (909)594-3926 sales@aprperformance.com...
