Summary of Contents for Housewatch 55-176
- Page 1 TWIN 8W LED SOLAR SPOTLIGHT I N S T R U C T I O N S Model No: 55-176...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..................3 IMPORTANT SAFETY INSTRUCTIONS ............3 INSTALLING THE SPOTLIGHT ...............4-5 OPERATION AND TESTING..............6-8 SETTING UP FOR AUTOMATIC OPERATION ..........9 MAINTENANCE PROGRAM ................9 TROUBLESHOOTING................10 SPECIFICATIONS..................11 WARRANTY INFORMATION ..............12... -
Page 3: Introduction
INTRODUCTION The Housewatch LED solar spotlight is a low-energy, high powered outdoor fitting. The LED spotlight is suitable for installation on walls in a range of outdoor locations including entrances, gardens, staircases, garages and parking areas. IMPORTANT SAFETY INSTRUCTIONS Please follow these instructions carefully before attempting to install and operate this spotlight. -
Page 4: Installing The Spotlight
INSTALLING THE SPOTLIGHT **NOTE: Charge the spotlight for a full day before use** PACKAGE INCLUDES • Light fixture x 1 • Stainless steel screws x 4 • Wall anchors x 4 • Solar panel x 1... -
Page 5: Mounting The Spotlight
MOUNTING THE SPOTLIGHT Using the screws and wall anchors provided, secure the spotlight horizontally to the wall and the solar panel in direct sunlight up to 5 metres away from the spotlight. Ensure that the connection between and the solar panel is firmly tightened as per Figures 1 &... -
Page 6: Operation And Testing
OPERATION & TESTING WALK TESTING PROCEDURE The sensor will rotate from left to right and up and down. Adjust the sensor to point in the desired direction (see Figure 3 & 4) for the sensor movements. 1. Set the two adjustment controls on the bottom of the sensor, (see Figure 6 on page 8) to the following positions: TIME - Slide switch: 5 seconds LUX - Slide switch: Day... - Page 7 3. Walk across the detection area approximately 5 metres from the unit. As you walk across the detection 'zone' the lamp will illuminate. Now stand still until the lamp extinguishes (this should take approximately 5 seconds). Max.12m Tilt 180° Max. Sensor head adjust SIDE VIEW Pan: left 90°,right 90°...
- Page 8 OPERATION & TESTING FIGURE 6...
-
Page 9: Setting Up For Automatic Operation
SETTING UP FOR AUTOMATIC OPERATION Once the walk tests are completed, the unit can be switched to automatic operation. The TIME setting controls how long the unit remains illuminated following activation and after all motion ceases. The minimum time (slide switch) is approximately 5 seconds, the maximum time (slide switch) is approximately 2 minutes. -
Page 10: Troubleshooting
TROUBLESHOOTING Problem Recommended Action Lights do not turn on 1) Charge the solar spotlight for a full day before 2) Check sensor is level and pointed at the area you desire and movement is not directly towards the sensor but across the lens. Check sensor is mounted at the recommended height. -
Page 11: Specifications
SPECIFICATIONS Model Description: Twin 8W LED Solar Spotlight Model Numbers: 55-176 Detection Range: Up to 12 metres Detection Angle: 180˚ Power Supply: DC3.7V Max. Switchable Load: LED 8W x 2 Lamp Type: 8W high power LED x 2 Time On Adjustment:... -
Page 12: Manufacturer's Warranty
MANUFACTURER’S WARRANTY This Housewatch product is guaranteed for a period of 2 (Two) years from date of purchase, provided the product has been installed in accordance with this instruction manual and local electrical wiring regulations and codes of practice. This guarantee shall become invalid if this product has been incorrectly installed, misused, tampered with or accidentally damaged.
