- Page 1 10W & 20W SPOTLIGHT I N S T R U C T I O N S 10W Model No’s: 55-138 & 55-139 20W Model No’s: 55-226 & 55-227...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..................3 IMPORTANT SAFETY INSTRUCTIONS ............3 INSTALLING THE SPOTLIGHT ..............4-7 MAINTENANCE PROGRAM ................7 TROUBLESHOOTING..................8 SPECIFICATIONS..................8 WARRANTY INFORMATION ..............10... -
Page 3: Introduction
INTRODUCTION The Housewatch LED spotlight is a low-energy, high powered outdoor fitting. The LED spotlight is suitable for installation on walls in a range of outdoor locations including entrances, gardens, staircases, garages and parking areas. IMPORTANT SAFETY INSTRUCTIONS Please follow these instructions carefully before attempting to install and operate this spotlight. -
Page 4: Installing The Spotlight
INSTALLING THE SPOTLIGHT 1. REMOVE FRONT COVER Use a Phillips head screwdriver to unscrew the three screws on the front cover, then open the back junction box. - Page 5 INSTALLING THE SPOTLIGHT 2. FIX THE SPOTLIGHT JUNCTION BOX TO THE WALL Using the screws and screw plugs provided, secure the spotlight horizontally to the wall.
- Page 6 INSTALLING THE SPOTLIGHT 3. CONNECTION Connect the cable to the terminal block on the wall plate as above. NEUTRAL (Blue) LIVE (Brown) 4. REPLACE FRONT COVER Rescrew the front cover in place with a Phillips head screwdriver.
-
Page 7: Maintenance Program
INSTALLING THE SPOTLIGHT BOTTOM BOTTOM OUTDOOR WALL INSTALLATION REQUIREMENT MAINTENANCE PROGRAM 1. After a period of time the lamp and lantern surfaces can accumulate dust and debris. This accumulation of dust and debris can directly influence the performance of lamps and fitting. A regular cleaning maintenance program for lamps and lanterns should be run on a 6 monthly cycle. -
Page 8: Troubleshooting
Problem Recommended Action Lights do not turn on 1) Check light switch is on 2) Check wiring SPECIFICATIONS Model Description: 10W Light 20W Light 55-138 55-226 55-139 55-227 Detection Angle: 140˚ Power Supply: AC 100-240V (50Hz) Max. Switchable Load: LED 10W... - Page 9 NOTES...
-
Page 10: Warranty Information
MANUFACTURER’S WARRANTY This Housewatch product is guaranteed for a period of 2 (Two) years from date of purchase, provided the product has been installed in accordance with this instruction manual and local electrical wiring regulations and codes of practice. This guarantee shall become invalid if this product has been incorrectly installed, misused, tampered with or accidentally damaged.
