- Page 1 20W & 40W SENSOR SPOTLIGHT I N S T R U C T I O N S 20W Model: 55-244 & 55-245 40W Model: 55-240 & 55-241...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..................3 IMPORTANT SAFETY INSTRUCTIONS ............3 INSTALLING THE SPOTLIGHT ...............4-7 OPERATION AND TESTING..............8-10 SETTING UP FOR AUTOMATIC OPERATION ..........11 MANUAL OVERRIDE MODE ..............11 MAINTENANCE PROGRAM ..............12 TROUBLESHOOTING ................12-13 SPECIFICATIONS..................14 WARRANTY INFORMATION ..............16... -
Page 3: Introduction
INTRODUCTION The Housewatch LED spotlight is a low-energy, high powered outdoor fitting. The LED spotlight is suitable for installation on walls in a range of outdoor locations including entrances, gardens, staircases, garages and parking areas. IMPORTANT SAFETY INSTRUCTIONS Please follow these instructions carefully before attempting to install and operate this spotlight. -
Page 4: Installing The Spotlight
INSTALLING THE SPOTLIGHT 1. REMOVE FRONT COVER Use a Phillips head screwdriver to unscrew the three screws on the front cover, then open the back junction box. - Page 5 INSTALLING THE SPOTLIGHT 2. FIX THE SPOTLIGHT JUNCTION BOX TO THE WALL Using the screws and screw plugs provided, secure the spotlight horizontally to the wall.
- Page 6 INSTALLING THE SPOTLIGHT 3. CONNECTION Connect the cable to the terminal block on the wall plate as above. NEUTRAL (Blue) LIVE (Brown) EARTH (Yellow/Green) 4. REPLACE FRONT COVER Rescrew the front cover in place with a Phillips head screwdriver.
- Page 7 INSTALLING THE SPOTLIGHT BOTTOM Lens must face down OUTDOOR WALL INSTALLATION REQUIREMENT...
-
Page 8: Operation And Testing
OPERATION & TESTING WALK TESTING PROCEDURE The sensor will rotate from left to right and up and down. Adjust the sensor to point in the desired direction (see Figure 1 & 2) for the sensor patterns. 1. Set the three adjustment controls on the bottom of the sensor, (see Figure 4 on page 10) to the following positions: TIME - Slide switch: 5 seconds, 1 min, 5 mins &... - Page 9 3. Walk across the detection area approximately 5 metres from the unit. As you walk across the detection 'zone' the lamp will illuminate. Now stand still until the lamp extinguishes (this should take approximately 5 seconds). FIGURE 2 SENSOR DETECTION RANGE NOTE: If the fitting is mounted higher than 2.4m, aiming the sensor down will reduce coverage distance.
- Page 10 OPERATION & TESTING Night FIGURE 4...
-
Page 11: Setting Up For Automatic Operation
SETTING UP FOR AUTOMATIC OPERATION Once the walk tests are completed, the unit can be switched to automatic operation. The TIME setting controls how long the unit remains illuminated following activation and after all motion ceases. The minimum time (slide switch) is approximately 5 seconds, the maximum time (slide switch) is approximately 12 minutes. -
Page 12: Maintenance Program
MAINTENANCE PROGRAM 1. After a period of time the lamp and lantern surfaces can accumulate dust and debris. This accumulation of dust and debris can directly influence the performance of lamps and fitting. A regular cleaning maintenance program for lamps and lanterns should be run on a 6 monthly cycle. 2. -
Page 13: Troubleshooting
TROUBLESHOOTING Problem Recommended Action PIR sensor will not Check that the power is switched ON at the circuit operate at all breaker/internal wall switch. Turn OFF the power to the unit and check the wiring connections as per the diagram (see page 6). Ensure no connections are loose. -
Page 14: Specifications
SPECIFICATIONS Model Description: 20W Sensor Light 40W Sensor Light Model Numbers: 55-244 (White) 55-240 (White) 55-245 (Black) 55-241 (Black) Detection Range: Up to 22 metres Detection Angle: 240˚ Power Supply: AC 100-240V (50Hz) AC 100-240V (50Hz) Max. Switchable Load: LED 20W... - Page 15 NOTES...
-
Page 16: Warranty Information
MANUFACTURER’S WARRANTY This Housewatch product is guaranteed for a period of 2 (Two) years from date of purchase, provided the product has been installed in accordance with this instruction manual and local electrical wiring regulations and codes of practice. This guarantee shall become invalid if this product has been incorrectly installed, misused, tampered with or accidentally damaged.
