- Page 1 2 x 10W SPOTLIGHT I N S T R U C T I O N S 55-161 (White) 55-162 (Black)
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..................3 IMPORTANT SAFETY INSTRUCTIONS ............3 INSTALLING THE SPOTLIGHT ..............4-6 COLOUR TEMPERATURE ADJUSTMENT ..........7 MAINTENANCE PROGRAM ................7 TROUBLESHOOTING..................8 SPECIFICATIONS..................8 WARRANTY INFORMATION ..............10... -
Page 3: Introduction
INTRODUCTION The Housewatch LED spotlight is a low-energy, high powered outdoor fitting. The LED spotlight is suitable for installation on walls in a range of outdoor locations including entrances, gardens, staircases, garages and parking areas. IMPORTANT SAFETY INSTRUCTIONS Please follow these instructions carefully before attempting to install and operate this spotlight. -
Page 4: Installing The Spotlight
INSTALLING THE SPOTLIGHT 1. REMOVE FRONT SPOTLIGHT HOUSING Use a Phillips head screwdriver to remove the three screws on the front cover, then open the rear Quick-Connect junction box. 2. FIX THE SPOTLIGHT QUICK-CONNECT JUNCTION BOX TO THE WALL Using the screws and screw plugs provided, secure the spotlight's junction box horizontally to the wall. - Page 5 INSTALLING THE SPOTLIGHT 3. CONNECTION Connect the cable to the terminal block on the wall plate as above. NEUTRAL (Blue) LIVE (Brown) EARTH (Green/Yellow)
- Page 6 INSTALLING THE SPOTLIGHT 4. REPLACE SPOTLIGHT HOUSING Return and fasten the spotlight housing in place with three screws. BOTTOM BOTTOM OUTDOOR WALL INSTALLATION REQUIREMENT...
-
Page 7: Colour Temperature Adjustment
COLOUR TEMPERATURE ADJUSTMENT Adjust the colour temperature by pressing the button as shown below. Pressing the button cycles through 3000K, 4000K and 5000K. MAINTENANCE PROGRAM 1. After a period of time the lamp and lantern surfaces can accumulate dust and debris. This accumulation of dust and debris can directly influence the performance of lamps and fitting. -
Page 8: Troubleshooting
TROUBLESHOOTING Problem Recommended Action Lights do not turn on 1) Check light switch is on 2) Check wiring SPECIFICATIONS Model Description: 10W Light 2 x 10W Light 55-153 55-157 55-154 55-158 Power Supply: AC 100-240V (50Hz) Max. Switchable Load: LED 10W LED 2 x 10W Lamp Type: 10W high power LED... - Page 9 NOTES...
-
Page 10: Warranty Information
MANUFACTURER’S WARRANTY This Housewatch product is guaranteed for a period of 2 (Two) years from date of purchase, provided the product has been installed in accordance with this instruction manual and local electrical wiring regulations and codes of practice. This guarantee shall become invalid if this product has been incorrectly installed, misused, tampered with or accidentally damaged.
