- Page 1 Operation & Maintenance Manual GEK-99986 Catalog # WPEGRRLV 115 VAC, 60/50 Hz Low Voltage WavePro EntelliGuard Circuit Breakers Remote Racking Operator For Small Frame Breakers 800A - 2000A and Large Frame Breakers 3200A - 5000A...
-
Page 2: Section 1. Introduction
The remote racking operator is portable and is racking motor and gearbox attached to the front designed for attachment to the WavePro & of the breaker. The remote racking operator Entellisys Low Voltage Power Circuit Breaker in requires 115Vac, 50/60Hz control power. -
Page 3: Section 3.Description
Attach the Remote Racking Operator to the The drive train is made of a gear motor (1, fig. 1), WavePro breaker by first depressing the OPEN And a square drive socket (2, fig. 1), which button on the front of the breaker. - Page 4 Remote Racking Operator for AKD-10 8 – Breaker Cover AC Plug Latch Opening 6 – Circuit Breaker Reset toggle Switch 30 foot cable 2 – Square drive Coupling 3 – Start Switch to Breaker Push Button 7 - Sliding 4 – Hand-Held Latch Control Box 5- IN/OUT...
- Page 5 ATTACHMENT / REMOVING DEVICE Racking operator – 3200-5000A Frame Attaching the Remote Racking Operator to WavePro Breakers the Large Frame WavePro or Entellisys circuit breaker The remote racking operator consists of a drive The circuit breaker must be in the OPEN position train, control switches, and attachment brackets.
- Page 6 Remote Racking Operator for AKD-10 Racking Screw Access Hole 7 – ¼ turn latch/Rod to mount to breaker 1-Motor and Gear Housing 6 – Circuit Breaker Reset Toggle Switch 5 – IN/OUT Directional Toggle Switch 4 – Hand Held Control Box 3 –...
- Page 7 Section 4. Modifications 4-1 Converting Large Frame Breaker to work with Remote Racker 1- Connecting Bracket – Align 1 to existing holes in breaker frame. 2,3,4,5 – ¼ -20 Bolt, Nut and Washers – Add ¼ in ch hardware to existing hole of bracket 1 and frame in upper position as shown.
- Page 8 4-2 Changing to Large Frame Breaker Door to work with Remote Racker Remote Racking Attachment Access holes Kit WPEGRRLFDR - 3200/4000A Wave Pro Door Kit WPEGRRLFDRDI- 3200/4000A Wave Pro Door with Defeatable Interlock Kit WPEGRR50DR – 5000A Wave Pro Door Kit WPEGRR50DRDI- 5000A Wave Pro Door with Defeatable Interlock...
- Page 9 Should further information be desired or should particular problems arise that are not covered sufficiently for the purchaser's purposes, the matter should be referred to the ABB Inc. —...
