- Page 1 220 CC Owner’s Manual Model Year 2025 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631...
-
Page 2: Table Of Contents
Systems ............................12 Cockpit Courtesy Lights ......................13 Ladder & Props ........................13 Fuel System ..........................15 Cobia 220 CC Fuel System .....................15 Self-Bailing Cockpit & Livewell ....................16 Rod Storage & Fish Lockers ....................17 Anchor Locker & Phenolic Plates ..................18 Battery Switch and Main Distribution Panel ................19 Console Interior and Head Unit .....................20... -
Page 3: Cobia 220 Cc Specifications
Cobia 220 CC Specifications L.O.A........................21’ 07” BEAM..............………………….…....8’ 09” DRAFT........................18” WEIGHT W ENGINE....................3,460 LBS. FUEL CAPACITY....................89 GAL. DEADRISE @ TRANSOM..................18 DEG. MAXIMUM H.P......................250 TRANSOM HEIGHT………………………………………………………………...…...… 25” MAXIMUM CAPACITIES............9 PERSONS OR 1,600 LBS. Livewell Fuel Fill Bilge Access Port Locker Anchor Locker... -
Page 4: Designated Occupant Positions
DESIGNATED OCCUPANT POSITIONS Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 5: Pre-Operation Checklist
Pre-Operation Checklist We recommend you print this document and store it at the helm station. Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 6: Maintenance & Cleaning
Maintenance Cobia advises owners that maintenance and repairs should be performed at an authorized Cobia Dealer. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group. Cleaning Each Cobia boat is constructed using the finest materials and components available. - Page 7 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631...
-
Page 8: Engine Break-In Period
DO NOT operate the boat if the engine stop switch system does not function properly. Go to a Cobia Dealer to have this resolved immediately. The lanyard should be securely attached to the boat operator at all times that the engine is on. -
Page 9: Helm & Command Link Gauges
Yamaha gauges, see your Yamaha owner's manual. Navigation Lights Your Cobia 220CC is equipped with port and starboard navigation lights and an anchor light. Navigation and anchor lights should not be modified, and additional lights should not be added such that they diminish the visibility of navigation lights or could be confused with navigation lights. -
Page 10: Cobia Duffel Bag
Part number: 43029210 standard; 43029610 with Hardtop or T-Top o Expiration Year: 2043 Cobia Duffel Bag Along with your boat, you received a Duffel Bag with your new Cobia. Inside the Duffel Bag are the following items: o Large Livewell Standpipe o Short Livewell Standpipe o 1.5”... -
Page 11: Garboard Drain Plug
Bilge Bilge Access The bilge of your Cobia is located in the aft seat compartment under the battery shelf. To open the backrest, release the latch located underneath the cushion on the starboard side of the seat and lift up. The backrest should come up easily. The bench seat can be opened to provide access to the battery shelf and bilge. - Page 12 Large quantities of water in the bilge may be an indication of a leak or that the bilge pump and/or automatic float switch is not functioning properly due to a jam, clog or electrical issue. The automatic float switch is wired to the hot side of the battery switch through the “BILGE”...
-
Page 13: Systems
Systems Ball Valves Ball valves can be used to serve several purposes. They allow seawater to enter the boat, in the case of livewells, and they also act as a safeguard to stop water from entering. To tell which position a ball valve is in, open or closed, look at the valve and determine the direction of flow. -
Page 14: Cockpit Courtesy Lights
Ladder & Props Stainless Boarding Ladder This Cobia model comes standard with a telescoping stainless-steel boarding ladder integrated into the starboard aft platform area. This provides a stepping area while the ladder is in the up position. Once the ladder is down and in the extended position, close the lid cover for safe and secure entry and exit via the ladder. - Page 15 Props Prop selection on your Cobia is determined by your local Cobia Dealer, but all props are based on recommendations from Cobia Boat Company and Yamaha Marine in order to give your boat maximum overall performance.
-
Page 16: Fuel System
Fuel System Fuel System This Cobia comes equipped with an 89-gallon fuel cell stationed below the leaning post between the stringer system. The fuel fill receptacle is on the port gunwale. Every fuel tank is pressure tested at the factory before and after installation. -
Page 17: Self-Bailing Cockpit & Livewell
Cobia Dealer immediately. Refer to page 9 for further information regarding bilge pump operation and maintenance. -
Page 18: Rod Storage & Fish Lockers
The livewell operates by pumping fresh seawater from the pump through an aerator head into the livewell. Drainage is achieved through the grate on the top of the standpipe, which, when unobstructed, will limit the water level to the standpipe’s highest point. -
Page 19: Anchor Locker & Phenolic Plates
Anchor Locker Phenolic Plate Location Your Cobia 220 comes standard with phenolic plates laminated into the cockpit floor. These plates secure the leaning post and optional T-top. They are designed for exceptional screw retention capabilities and provide the support required to secure such weight bearing items. -
Page 20: Battery Switch And Main Distribution Panel
Battery Switch and Main Distribution Panel The batteries are located under the aft helm seat cushion. The battery switch is located at the aft starboard cockpit. On a single battery system, your battery is wired to the number 1 side of the switch. With a second battery, one battery is wired to the number 1 position while the second battery is wired to the number 2 side of the switch. -
Page 21: Console Interior And Head Unit
Console Interior and Head Unit Console Interior Inside the console is the breaker panel for the switches at the helm. In addition, you will find the optional head system that your boat came equipped with. Breaker Panel Console Access Electric Head (Optional) The macerator is to be used only with direct discharge thru hull. -
Page 22: Seating
Seating Aft Bench Seat Your Cobia 220 CC comes with a highly innovative aft seat with a fold-down backrest. In the down position, the backside of the backrest provides a large flat area for rigging or cutting baits and protects the cushions from the elements. To open the backrest, release the latch located underneath the cushion on the starboard side of the seat and lift up. -
Page 23: Optional Features
T-Top There are several different T-Top options for the Cobia 220 CC. The T-Tops come with either a Weblon or a fiberglass hard top. Each of these tops has the option of being outfitted with an electronics box, forward and aft facing LED spreader lights, outriggers, recessed LED overhead lights, speakers, and additional storage. - Page 24 Trim Tabs Bennett trim tabs are optional on your new Cobia. External electric trim tabs can enhance the performance of your boat. The tabs on the 220 are electric and therefore do not require a trim tab pump. By not having a pump there is no possibility of fluid leaks from a pump.
- Page 25 A portable head unit is an option in the 220. The instruction manual can be found in the Cobia duffel bag and basic operating instructions are listed here. The optional head pump out fitting is located on the starboard side of the console. With this option, waste can be removed at an approved dumping station without removing the tank from the head.
- Page 26 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631...
- Page 27 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631...
- Page 28 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631...
- Page 29 Location and Reordering of Warning Labels IF LABEL IS DAMAGED, REMOVED, OR LOST, IF LABEL IS DAMAGED, REMOVED, OR LOST, REPLACE WITH NEW LABEL, PART NO. 59118503, REPLACE WITH NEW LABEL, PART NO. 59118506, AVAILABLE FROM DEALER OR MANUFACTURER. AVAILABLE FROM DEALER OR MANUFACTURER. INSTALL NEAR KEY SWITCH INSTALL NEAR HELM IF LABEL IS DAMAGED, REMOVED, OR LOST,...
- Page 30 Location and Reordering of Warning Labels IF LABEL IS DAMAGED, REMOVED, OR LOST, IF LABEL IS DAMAGED, REMOVED, OR LOST, REPLACE WITH NEW LABEL, PART NO. 59118502, REPLACE WITH NEW LABEL, PART NO. 59110900, AVAILABLE FROM DEALER OR MANUFACTURER. AVAILABLE FROM DEALER OR MANUFACTURER. INSTALL ON TRANSOM INSTALL NEAR FUEL FILL IF LABEL IS DAMAGED, REMOVED, OR LOST,...
-
Page 31: Cobia 220 Cc Fuel System
Cobia 220 CC Fuel System Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 32: Cobia 220 Cc Bunk Placements
Cobia 220 CC Bunk Placements Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 33: Cobia 220 Cc Bunk Placements
Cobia 220 CC Bunk Placements Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 34: Upholstery Care & Cleaning Guide
Upholstery Care & Cleaning Guide Upholstery Care & Cleaning Guide Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 35: Warranty
Cobia Boats advises owners that an authorized Cobia Dealer perform maintenance and repairs on your boat. Self repairs and repairs done by a non- authorized Cobia Dealer may void the warranty on the boat. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group.
