- Page 1 320 CC Owner’s Manual Revised March 2020 Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631...
- Page 2 Dear New Cobia Owner, On behalf of Cobia Boats, I would like to congratulate you on your purchase. We at Cobia strive to build the best products possible and wish you years of trouble-free enjoyment. There are many things to know about the operation, care, and maintenance of our products and the systems we install in them.
-
Page 3: Table Of Contents
Table of Contents Cobia 320 CC Specifications....................4 Cobia 320 CC Deck Layout ....................5 Pre-Operation Checklist ......................6 Maintenance & Cleaning ....................... 7 Engine Break-In Period ......................8 Helm & Command Link Gauges .................... 9 Fuel-Water Separator & Drain ....................10 Bilge ............................11... -
Page 4: Cobia 320 Cc Specifications
Cobia 320 CC Specifications L.O.A........................32’ 0” BEAM..............………………….…....10’ 03” DRAFT..........................23” WEIGHT W/O ENGINE..................7,324 LBS. FUEL CAPACITY....................275 GAL. DEADRISE @ TRANSOM..................21.5 DEG. MAXIMUM H.P......................700 TRANSOM HEIGHT…………………………………..…...…….………………….. 25” TWINS MAXIMUM CAPACITIES............10 PERSONS OR 1700 LBS Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 •... -
Page 5: Cobia 320 Cc Deck Layout
Cobia 320 CC Deck Layout Boarding Ladder Fuel Fill Livewell Table Lift Anchor Locker Storage Hatches Forward Console/Head Leaning Post/Tackle Station Entry Bilge Access Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 6: Pre-Operation Checklist
Pre-Operation Checklist We recommend you print this document and store it at the helm station. Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 7: Maintenance & Cleaning
Maintenance Cobia advises owners that maintenance and repairs should be performed at an authorized Cobia Dealer. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group. Cleaning Each Cobia boat is constructed using the finest materials and components available. -
Page 8: Engine Break-In Period
DO NOT operate the boat if the engine stop switch system does not function properly. Go to a Cobia Dealer to have this resolved immediately. The lanyard should be securely attached to the boat operator at all times that the engine is on. -
Page 9: Helm & Command Link Gauges
Yamaha engine owner’s manual located in the Cobia Duffel Bag. Cobia Duffel Bag Along with your boat, you received a Duffel Bag with your new Cobia. Inside the Duffel Bag are the following items: o Large Livewell Standpipe o Short Livewell Standpipe o 1.5”... -
Page 10: Fuel-Water Separator & Drain
If there appears to be an excessive amount of water, the filter component should be replaced. See your authorized Cobia Dealer for replacement parts. Maintenance Note: Yamaha recommends replacing the 10- micron fuel filter on new boats after the first 10 hours or 1 month of operation and every 50 hours or every 6 months thereafter. -
Page 11: Bilge
Bilge Bilge Access First, locate the controls on the electronic lift assist, labeled “Hatch”, mounted on the starboard side of the tackle station directly across from the gunwale. Next, press and hold the top button on the controls. This will cause the rear access to lift revealing the bilge access. - Page 12 Bilge The bilge of your Cobia should always be checked before and after a launch. While checking the bilge, note that a small amount of water in the bilge is normal. However, a large amount of water or any signs of fuel or oil requires immediate attention.
-
Page 13: Systems
If the bilge pump still does not turn on, it likely needs to be replaced. It is not recommended to use your boat if the bilge pump and/or float switch are not functioning properly. Systems Ball Valves Ball valves can be used to serve several purposes. They allow seawater to enter the boat, in the case of livewells, and they also act as a safeguard to stop water from entering. -
Page 14: Battery Switch And Main Distribution Panel
Battery Switch and Main Distribution Panel The battery switches and main distribution panel are located in the port compartment on the side of the leaning post. The battery switches are labeled to correspond with each battery and the component it powers. Each engine has its own battery and there is a house battery that powers the boat’s other electrical systems. - Page 15 At the bottom of the distribution panel and to the left of the windlass breaker are the breakers for the forward table, power steering, electronics, helm panel, stereo amp (if applicable) and aft hatch. All these components run off the house battery (s). If popped these breakers will show red in the window below the “OFF”...
-
Page 16: Ladder & Props
Props Prop selection on your Cobia is determined by your local Cobia Dealer, but all props are based on recommendations from Cobia Boat Company and Yamaha Marine in order to give your boat maximum overall performance. -
Page 17: Fuel System
Fuel System Fuel System This Cobia comes equipped with a 275-gallon fuel cell stationed below the leaning post between the stringer system. The fuel fill receptacle is on the port gunwale. Every fuel tank is pressure tested at the factory before and after installation. -
Page 18: Self-Bailing Cockpit & Livewell
Cobia Dealer immediately. Refer to page 11 for further information regarding bilge pump operation and maintenance. -
Page 19: Rod Storage & Fish Lockers
Port Gunwale Storage Rack Port and Starboard Fish Lockers The 320 CC has two fish lockers on the port (70 gal.) and starboard (45 gal.) sides. These lockers are insulated and each one is connected to a macerator with the contents being dumped overboard. -
Page 20: Macerator Access & Operation
Macerator Access & Operation Macerator Switches The switches for each fish box macerator are located on the switch panel left of the steering helm. These can be operated independently of each other and the switches are labeled. Macerator Access In order to access the macerators, open the bilge access hatch by using the controls on the starboard side of the tackle station. -
Page 21: Anchor Locker
Standard Features Cockpit Bolsters Cockpit bolsters are standard with the 320 CC. These will add some comfort to legs when fighting with the big fish. The bolster cushions are mounted to the port and starboard gunwales that house an additional three rod holders each. The forward rod holder is mounted at 45 degrees to the outboard side. - Page 22 Table Lift The 320 CC features an electric table lift in the bow seating area that comes standard with the boat. The table can be lowered all the way down to sit flush with the deck allowing full access to the bow area (1).
- Page 23 To raise the cleats simply grip the indents and lift until locked. To recess these items simply push them back into the deck. As with all stainless moving parts on your Cobia, it is recommended that you routinely apply a stainless safe corrosion inhibitor and lubricant to keep these items working properly.
- Page 24 Fresh Water Shower The fresh water tank on your new Cobia can be filled at the cap labeled “FRESH WATER” on the back starboard corner near the transom. The hose nozzle is on the port aft bulkhead. To pressurize the system, flip the switch labeled “FRESH WATER” on the switch panel at the helm.
- Page 25 Console/Head Access Located at the top on the inside of the console/head access door is a locking gas shock that aides in opening the door and keeping the door open once the shock is fully extended. With the door fully opened, it can only be closed by releasing the pressure of the metal sleeve on the door side against the shock that is mounted to the console.
- Page 26 Once you’ve finished using the head, press the flush button labeled “Elec Head” on the switch panel. This will push the contents of the head into the holding tank. Note that the toilet contents will always go into the holding tank first, no matter if planning on pumping out or using the macerator.
- Page 27 to be going downward. Next, press down the macerator switch on the panel. This will push the contents in the holding tank out the bottom of the boat through the waste discharge thru hull. Once the process is complete it is advisable to close the discharge valve and put the Y-valve handle back into the pump-out position.
-
Page 28: Optional Features
T-Top There are several different T-Top options for the Cobia 320 CC. The T-Tops come with either a Weblon or a fiberglass hard top. Each of these tops has the option of being outfitted with an electronics box, forward and aft facing LED spreader lights, outriggers, recessed LED overhead lights, speakers, additional storage and electronic space. - Page 29 Aft Personal Flotation Device Storage Optional JL Stereo System If you chose the stereo option, your 320 CC came with a JL Audio Stereo system Media Master 100 with four matching speakers and an auxiliary plug located under the helm in the glove box.
- Page 30 A bow plate and anchor roller have been added to accept the anchor and keep it far enough from the bow of your 320 CC to prevent damage to the bow. The windlass is mounted just aft of the bow roller plate.
- Page 31 Closing the Clutch: The clutch provides a link between the gypsy and the main shaft. The clutch is released (disengaged) by using the clutch handle which, when inserted into the drum or gypsy cover, must be turned counter clockwise. The clutch will be re- engaged by turning it clockwise.
-
Page 32: Cobia 320 Cc Hull Wire Harness
Cobia 320 CC Hull Wire Harness Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 33: Cobia 320 Cc Deck Wire Harness
Cobia 320 CC Deck Wire Harness Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 34: Cobia 320 Cc Hardtop Wire Harness
Cobia 320 CC Hardtop Wire Harness Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 35: Cobia 320 Cc Fuel System
Cobia 320 CC Fuel System Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 36: Cobia 320 Cc Water Drain System
Cobia 320 CC Water Drain System Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 37: Cobia 320 Cc Water Supply System
Cobia 320 CC Water Supply System Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 38: Cobia 320 Cc Bunk Placements
Cobia 320 CC Bunk Placements Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 39: Cobia 320 Cc Bunk Placements
Cobia 320 CC Bunk Placements Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 40: Upholstery Care & Cleaning Guide
Upholstery Care & Cleaning Guide Maverick Boat Group 3207 Industrial 29th St. • Fort Pierce, Florida 34946 • cobiaboats.com (772)-465-0631... -
Page 41: Warranty
Self repairs and repairs done by a non- authorized Cobia Dealer may void the warranty on the boat. The following information is general in nature and should not be considered a repair manual or guidelines set forth by Maverick Boat Group.
