- Page 1 PLUS WRP001 INSTALLATION GUIDE IG_PLUS_WRP001_E02A TEKON ELECTRONICS AVEIRO, PORTUGAL +351 234 303 320 +351 933 033 250 sales@tekonelectronics.com...
- Page 2 DUOS WIRELESS SYSTEM INSTALLATION GUIDE PLUS WRP001 WIRELESS REPEATER INSTALLATION GUIDE Table of contents step WRP001 PLUS WIRELESS REPEATER CONFIGURATION Pages 3 to 10 step SITE SURVEY MODE Pages 11 to 12...
- Page 3 step WRP001 PLUS WIRELESS REPEATER CONFIGURATION...
- Page 4 PLUS WRP001 INSTALLATION GUIDE step CONNECT AND CONFIGURE THE PLUS WIRELESS REPEATER Loosen the 4 screws of the case and oppen it. Connect a micro USB cable to the computer and then to WRP001 PLUS Wireless Repeater. Open Tekon Configurator Software...
- Page 5 INSTALLATION GUIDE PLUS WRP001 step CONNECT AND CONFIGURE THE PLUS WIRELESS REPEATER Open the WRP001 PLUS Wireless Repeater device page. You can enter the device’s page in the following ways: 1st option: Click on “SMART TRANSMITTERS” in the left menu and then click on the device.
- Page 6 PLUS WRP001 INSTALLATION GUIDE step CONNECT AND CONFIGURE THE PLUS WIRELESS REPEATER Load the “Port COM” corresponding to the WRP001 PLUS Wireless Repeater. NOTE: If the USB cable has already been connected before opening the device page, “Port COM” will appear in the list, otherwise you need to click on the “...
- Page 7 INSTALLATION GUIDE PLUS WRP001 step CONNECT AND CONFIGURE THE PLUS WIRELESS REPEATER Click on to enter in Configuration Mode permanently LEDs flashing until wireless connection is established ANALOG WIRELESS TRANSMITTER WIRELESS REPEATER permanently...
- Page 8 PLUS WRP001 INSTALLATION GUIDE step CONNECT AND CONFIGURE THE PLUS WIRELESS REPEATER The software will connect to the device. NOTE: If the software is unable to connect to the device, the status is displayed. If it hasn’t connected, go back to the previous steps and check the port COM.
- Page 9 INSTALLATION GUIDE PLUS WRP001 step CONNECT AND CONFIGURE THE PLUS WIRELESS REPEATER Configure the “Wireless Network ID” and “Wireless Channel” previously obtained from the Gateway. Click on the “WRITE DEVICE” button to update the transmitter settings. . Wait for the software to write the new setting to the device. Wait for the status...
- Page 10 PLUS WRP001 INSTALLATION GUIDE step CONNECT AND CONFIGURE THE PLUS WIRELESS REPEATER Click to exit the configuration and return to normal operating mode. permanently LEDs flashing until wireless connection is established permanently ANALOG WIRELESS TRANSMITTER WIRELESS REPEATER Connection to the Gateway...
-
Page 11: Site Survey Mode
step SITE SURVEY MODE... - Page 12 PLUS WRP001 INSTALLATION GUIDE step SITE SURVEY MODE Site survey mode is a tool that allows a quick wireless signal strength evaluation at the site of installation. It doesn’t require additional equipment or software. This feature is available in all the transmitters and repeater from PLUS Product Family.
