F-4A-B-XLR-TX/RX
Quick Setup Guide
Step 1: Connect Power
Connect the Included Power Supplies to the Transmitter (Tx) and the Reciever (Rx)
"PWR" LEDs on both Tx and Rx indicate power is connected properly
Step 2: Connect Fiber
Connect Transmitter to
Receiver using Single
Mode Fiber (Not Included)
ST/PC fiber connector
Distance up to 20-120Km
(model dependent)
"FIBER" LEDs on both Tx and Rx indicate fiber is connected properly
Advertisement
Related Manuals for Thor Broadcast F-4A-B-XLR-TX
Summary of Contents for Thor Broadcast F-4A-B-XLR-TX
- Page 1 800-521-8467 sales@thorfiber.com F-4A-B-XLR-TX/RX Quick Setup Guide Step 1: Connect Power Connect the Included Power Supplies to the Transmitter (Tx) and the Reciever (Rx) “PWR” LEDs on both Tx and Rx indicate power is connected properly Step 2: Connect Fiber...
- Page 2 Step 3: Connect Audio (EXAMPLE) Signal IN Signal OUT R Audio 1 (Female) = T Audio 1 (Male) T Audio 1 (Female) = R Audio 1 (Male) R Audio 2 (Female) = T Audio 2 (Male) T Audio 2 (Female) = R Audio 2 (Male) R Audio 3 (Female) = T Audio 3 (Male) T Audio 3 (Female) = R Audio 3 (Male) R Audio 4 (Female) = T Audio 4 (Male)
