F-16A-RCA-TX/RX
Step 1: Connect Power
Connect the included Power Cables to the TRANSMITTER and RECEIVER.
PWR LED will indicate when power is connected properly.
Step 2: Connect Fiber
Using Fiber Cable (not included) Connect the FIBER port
of the TRANSMITTER to the FIBER port of the RECEIVER
FIBER LED on TRANSMITTER will blink and FIBER LED on RECEIVER
will light solid when fiber connection is properly established.
https://thorbroadcast.com
800-521-8467
sales@thorfiber.com
Quick Setup Guide
Advertisement
Related Manuals for Thor Broadcast F-16A-RCA-TX
Summary of Contents for Thor Broadcast F-16A-RCA-TX
- Page 1 800-521-8467 sales@thorfiber.com F-16A-RCA-TX/RX Quick Setup Guide Step 1: Connect Power Connect the included Power Cables to the TRANSMITTER and RECEIVER. PWR LED will indicate when power is connected properly. Step 2: Connect Fiber Using Fiber Cable (not included) Connect the FIBER port...
- Page 2 Tx Audio IN13 = Rx Audio Out13 RECEIVER. Tx Audio IN14 = Rx Audio Out14 Tx Audio IN15 = Rx Audio Out15 Tx Audio IN16 = Rx Audio Out16 F-16A-RCA-TX/RX Quick Setup Guide https://thorbroadcast.com 800-521-8467 sales@thorfiber.com...
