F-8HD-1D-TVI-TX/RX
Step 1: Connect Power
Connect Included Power Supplies to Transmitter (T) and Receiver (R)
"PWR" LEDs on both T and R indicate power is properly connected
Step 2: Connect Fiber
Connect Transmitter to
Receiver using Single
Mode Fiber (Not Included)
Distance up to 120km
https://thorbroadcast.com
"FIBER" LEDs on both T and R indicate fiber is properly connected
800-521-8467
sales@thorfiber.com
Quick Setup Guide
Advertisement
Related Manuals for Thor Broadcast F-8HD-1D-TVI-TX
Summary of Contents for Thor Broadcast F-8HD-1D-TVI-TX
- Page 1 800-521-8467 sales@thorfiber.com F-8HD-1D-TVI-TX/RX Quick Setup Guide Step 1: Connect Power Connect Included Power Supplies to Transmitter (T) and Receiver (R) “PWR” LEDs on both T and R indicate power is properly connected Step 2: Connect Fiber Connect Transmitter to...
- Page 2 RS port on the Transmitter only applies to model F-8HD-TVI-1D-TX/RX Similar models such as F-8HD-TVI-TX/RX do not have this feature. Scan for more info: “DATA” LEDs on both T and R indicate RS data is properly connected F-8HD-1D-TVI-TX/RX Quick Setup Guide https://thorbroadcast.com 800-521-8467 sales@thorfiber.com...
