F-12G-8SDI-CWDM-TX/RX
Quick Setup Guide
8 Channel SD/HD 3G/12G SDI Over single fiber Transmitter/Receiver Kit
Step 1: Connect Power
Connect the included Power Supplies to the Transmitter and the Receiver
"PWR" LEDs on both units indicate that power is properly connected
Step 2: Connect Fiber
Connect Transmitter to Receiver using Single
Mode Fiber with ST/PC connector (Not Included)
Distance up to 10km
"FIBER" LED on the Receiver indicates that fiber is properly connected
Advertisement
Related Manuals for Thor Broadcast F-12G-8SDI-CWDM-TX
Summary of Contents for Thor Broadcast F-12G-8SDI-CWDM-TX
- Page 1 800-521-8467 sales@thorfiber.com F-12G-8SDI-CWDM-TX/RX Quick Setup Guide 8 Channel SD/HD 3G/12G SDI Over single fiber Transmitter/Receiver Kit Step 1: Connect Power Connect the included Power Supplies to the Transmitter and the Receiver “PWR” LEDs on both units indicate that power is properly connected...
- Page 2 Receiver Outputs SDI 1-8 Step 4: Loop Outputs (Example) Signal IN TRANSMITTER Signal “V1-V8” LEDs on both T and R indicate video is properly connected Signal Scan for more info: RECEIVER Signal OUT F-12G-8SDI-CWDM-TX/RX Quick Setup Guide https://thorbroadcast.com 800-521-8467 sales@thorfiber.com...
