Cake Bukk Limited Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Bukk
Limited
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bukk Limited and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cake Bukk Limited

Summary of Contents for Cake Bukk Limited

  • Page 1 Bukk Limited Manual...
  • Page 3 Welcome to CAKE! We are extremely flattered that you have chosen to ride a CAKE electric motorbike. It’s our obligation to do the best we can to serve you with the product, information, service and spare parts for an effortless experience. ...

  • Page 4: Table Of Contents

    1.7 Customer service 2. Warranty 3. Getting started 3.1 Unboxing the vehicle 3.2 Preparing for use 3.3 Powering on 3.4 Downloading the Ride CAKE App 3.5 Overview of App functions 4 Description 4.1 General description 4.2 Battery 4.3 Dashboard 4.4 Ride modes 4.5 Brake modes...
  • Page 5 Contents 6 Service schedule 7 Diagnostics 8 Spare parts and accessories 9 Technical data 10 Contact and support...

  • Page 6: Symbols Used

    Indicates mandatory safety information. Indicates required maintenance according to the service schedule. Indicates environmental measures. Indicates a reference to the CAKE app. 1. Safety 1.1 Owner’s manual Before riding the vehicle for the first time, read through this entire manual and make sure you fully understand it.

  • Page 7: Risk Symbols

    1.2 Risk symbols Safety instructions are emphasized in the text. Read them carefully to avoid hazardous situations and to operate the vehicle safely. Danger A hazard that will immediately lead to death or serious permanent injury. Warning A hazard that may lead to death or serious permanent injury.
  • Page 8 Placement of safety labels and marks on the vehicle...

  • Page 9: Safety Advice

    Cake 0 Emission AB L1e-B CAKE 0 EMISSION AB YW2 XXXXXXXXXXXXXX HAMMARBY FABRIKSV. 43 A Type label --dB(A) - --min 120 30 Stockholm 4,0 kW 45 km/h max 245 KG Sweden B Electric battery C Electric motor D Hot parts...
  • Page 10 Do not use the vehicle if you are physically or mentally impaired. Do not ride with a passenger unless you have installed a proper CAKE passenger seat, see ridecake.com/en/products/spare-parts/ . The vehicle is completely silent when it has been powered on but is at a standstill.
  • Page 11 Only operate the vehicle when it is in perfect technical condition. • Always wear a helmet and appropriate clothing. • Always use Ride mode 1 when riding a CAKE bike for the first time. • Ride mode 3, is recommended for highly skilled riders. Accident/damaged vehicle WARNING! Fire hazard.
  • Page 12 Do not open the charger. • Work on the battery and charger must only be performed by an authorized CAKE workshop. • Remove the battery before starting any work on the vehicle. WARNING! Risk of personal injury. If another brake fluid than the stated is used, the brakes may cease to function.
  • Page 13 Spare parts and accessories For safety reasons, only use spare parts and accessories recommended by CAKE. CAKE accepts no liability for any damage or loss caused by other spare parts or accessories. When required by this manual, have spare parts and accessories installed by an authorized CAKE workshop.

  • Page 14: Customer Service

    EU regulations governing the disposal of used vehicles, there are no legal regulations that pertain to the disposal of an end-of-life motorcycle. Please, contact CAKE if you need support in this matter. 1.7 Customer service Visit ridecake.com/en/service-support/ for information on authorized dealers...

  • Page 15: Preparing For Use

    3.2 Preparing for use WARNING! When charging, always first connect the charger to the battery. Thereafter, connect the charger to the mains supply. • Charge the battery to 100%, i.e., until the charger LED is steady green, see Charging the battery (5.1 Handling the battery) (Due to shipping regulations, the battery state of charge is low during transport.) •...

  • Page 16: Powering On

    • Check that the Bodywork is properly fastened. If needed, adjust the clamping force. in Fig. 3.1. Fig. 3.1 Clamping force adjuster • Read the safety instructions. • Get to know the controls. • Ensure the vehicle is registered and insured in accordance with applicable laws.
  • Page 17 . In order to change the mode to customized see Fig. 6 mode: use the CAKE Connect app, Downloading the CAKE Connect app. 4. To change brake mode, turn the knob to the right on the dashboard to the wanted brake mode, see Fig.
  • Page 18 Front brake Rear brake Dashboard Throttle Grip Kill switch Stem Fig. 5, Handlebar Fig. 6, Dashboard A. Ride mode B. Warning LED C. Battery SOC D. Brake mode...

  • Page 19: Overview Of App Functions

    4. Once logged in, standing by the vehicle, enable Bluetooth on your mobile device. 5. When asked to pair with Cake, answer Yes. => The vehicle is connected to your mobile device. You can start using the below app features.
  • Page 20 Advanced ride modes NOTE: The following applies to bikes equipped with the feature ‘Advanced ride modes’. Advance ride modes let you go deeper into your bike settings to customize the riding experience even further. • Adjust throttle sensitivity to allow for more aggressive response perfect for MX-style riding or gentler response that fits a muddy trail on rainy forest •...

  • Page 21: Description

    Trail/enduro riding up to 3 hours * Range Driver’s license requirement None All ride modes and brake modes are configurable in the Ride CAKE app Explore: The ultimate mode for Ride mode 1 exploration. Speed limited to 60km/h and up to 3h* trail riding.

  • Page 22: Battery

    4.2 Battery The battery has 5 LEDs indicating the state of charge (SOC): Table 1, state of charge (SOC) when discharge LED1 LED2 LED3 LED4 LED5 0 ~ 20% 21 ~ 40% 41 ~ 60% 61 ~ 80% 81 ~ 100% Table 2.

  • Page 23: Dashboard

    4.3 Dashboard The dashboard on the stem is the bike’s control panel. Here you can see the bikes SOC (state of charge), Power mode, Brake mode and warning notifications The Dashboard has 4 LEDs indicating the state of charge (SOC): State of charge indicator Battery SOC LED 4...
  • Page 24 Performance state indicator Warning signals when vehicle in power limitation mode Warning Warning LED color Battery low Blue (Steady) (In combination with low SOC) Battery warm Blue (Fade in / out) Motor warm Orange (Steady) Controller warm Yellow (Steady) Limp mode active Green (Fade in / out)
  • Page 25 The Blinking error codes should be according to the table below. The general structure of the fault codes should be that the number of blinks occurs then there should be a 3 second delay until the code repeats. The codes should repeat until the vehicle is restarted.

  • Page 26: Ride Modes

    3 hours trail riding. This mode is ALWAYS recommended when riding a CAKE bike for the first time. This power mode still has high torque for rideability offroad as well as something for new riders to progress with. This Mode is perfect for tracks where control is more valued than power.

  • Page 27: Brake Modes

    4.5 Brake modes On the knob to the right, you can put the bike into 3 different braking modes. This ranges from a freewheel experience, much of what you feel on an MTB, which is suited for mellow riding on flats, to a hard engine brake, that is similar to the engine brake on a 4-stroke motorcycle, which is suited for technical riding.

  • Page 28: Operating

    5. Operating WARNING! Risk of burns. Stay clear of vehicle parts that are hot after usage. 5.1 Handling the battery WARNING! Fire hazard. Do not use a damaged battery, as it is highly flammable. A damaged battery may self-ignite. NOTICE When the battery is not connected to the vehicle or the charger, the battery must be stored indoors.
  • Page 29 Only use the intended charger. Only use the intended battery. Regularly examine the charger for any damages, especially the cord, plug, and enclosure. Do not use a damaged charger. Contact CAKE Service & support. During charging, place the battery in a well-ventilated area.
  • Page 30 • Check the SOC in the CAKE app. Charging the battery WARNING! Only charge the BUKK battery with the 72V CAKE charger 1. Disconnect the kill switch. 2. Disconnect the battery connector 3. Plug the charger into the charging connector found on the battery.
  • Page 31 Charging Information • charger communicates to the smart battery management system (BMS) and ensure the battery is charge after the optimal conditions.  • If the battery is cold or hot the charging time will be increased. • Make sure the battery is above 0 °C / 32 °F, the battery is colder the charging will not start to protect the battery life and ensure safety.
  • Page 32 Removing the battery and seat NOTICE When the battery is not connected to the vehicle or the charger, the battery must be stored indoors. Otherwise, humidity may enter through the inlet and permanently damage the battery. If you get water in the connector of your battery. Turn the battery upside down to remove any body of water.

  • Page 33: Before Every Ride

    Attaching the battery 1. Place the battery in the battery holder. 2. Attach the battery signal cable. 3. Attach the seat Slide on the seat clamp on the hook, (A) in Fig. 11. Push down the clamp, (A) in Fig. 11. Attach the sprint Push down the seat and move the quarter turn handle a quarter of a turn,...

  • Page 34: Starting

    NOTICE Saftey pin must be used as intended! If pin is not attached, you risk personal and property damage. Saftey pin must be used as intended! If pin is not attached, you risk personal and property damage 5.3 Starting Before you start the vehicle, please remember that this is an all-electric vehicle that is very silent when it’s on.

  • Page 35: Accelerating

    5.6 Changing ride mode When the vehicle is active, change ride mode by turning the left knob on the dashboard. Configure all ride modes in the CAKE Connect app. 5.7 Braking WARNING! Risk of personal injury. There is no foot brake. Remember that you control both the rear and front brakes from the handlebar.

  • Page 36: Powering Off

    When storing the vehicle for long time, disconnect the battery connector. To avoid unnecessary aging and/or discoloration, store the vehicle in a dry and cool place. CAKE recommends you use the vehicle at least once a month to preserve all vehicle components in good condition. Pay close attention to how to handle and care for the battery in a safe way, see Handling the battery.

  • Page 37: Service Schedule

    6. Service schedule Service table and Service intervals Before After After Service intervals After Crash every Ride every 10h every 20h Check tire pressure Check tread depth, tire Check rims for damage Check spoke tension Check brake discs Check brake pads Check brake fluids Check braking ability test drive Check brake hoses for damage...

  • Page 38: Troubleshooting

    2 weeks, discharged. fully charge the battery. Check if the warning LED shows an error code. Use the CAKE app/ There is a motor Diagnostics to possibly solve the issue.  issue.  Contact an authorized CAKE workshop.
  • Page 39 2 hours and try again. DANGER! Risk of electrical shock. Contact CAKE Service & support. Do not Other error. attempt to solve the problem in any other way!
  • Page 40 Contact an authorized CAKE workshop.  though the vehicle starts.  not working. Use the CAKE app/Diagnostics to possi- The blinking is an bly solve the issue. error code that can be interpreted in The dashboard is blinking the CAKE app.

  • Page 41: Spare Parts And Accessories

    8 Spare parts and accessories Please, see ridecake.com/en/products/spare-parts/ . 9 Technical data & RangSpeede Bukk Limited Top speed 90 km/h - 56 mph Trail/Enduro riding: up to 3 Range hours* Drivetrain Type Chain drive Jante - Interior Permament Electric motor...
  • Page 42 Controller Ride mode 1 - Explore The ultimate mode for exploration. Speed limited to 60km/h and up to 3h trail riding. Ride mode 2 - Excel Perfect for enduro, track or active trail riding. Offers up to Ride modes 1,5h riding time. Top speed 90km/h.
  • Page 43 Front suspension WP AER 43mm CONE VALVE FORK Highly adjustable with Type compression damping, air pressure and rebound damping. Travel 278mm Rear suspension Type Öhlins S46 Travel 297mm (rear wheel) Brakes Formula Front brake and Type Formula rear hand brake Stainless steel, 240/220mm Disc diameter, 3 mm thickness...

  • Page 44: Contact And Support

    © 2023 CAKE 0 Emission AB All rights reserved This manual is being updated continuously. Make sure you have the latest version; visit ridecake.com/manuals. Manual Article Number: CB9000 BUKK Limited bike, revision 1 This document is valid for the following models: BUKK Limited...
