Restart the Module Dock

• One SuperSpeed USB 3.x port on the host computer, using the Power and Data end of the Y-cable. Leave the Power
Only end of the Y-cable unplugged.
• Two High-Speed USB 2.0 ports on the host computer, using both the Power and Data, and Power Only ends of the
Y-cable.
Step 2 Do one or both of the following actions:
• Insert a Sensor SFP into the Module Dock SFP port.
• Connect a Sensor Module to the Module Dock RJ-45 port using an Ethernet (patch cord) cable.
The power LEDs on the Module Dock light up orange as the unit is booting. When the Power LED is lit green, you are
ready to configure the active connected device.
Restart the Module Dock
To restart the Module Dock:
Step 1 Ensure that the Module Dock is not actively completing any firmware updates or other operations.
Step 2 Press and release the Reset button located on the side of the unit (indicated by in the numbered diagram to the left).
Step 3
Click OK when the confirmation message appears.
The unit's power LEDs are lit orange as it restarts.

Revert the Module Dock to Factory Settings

To revert the Module Dock to factory settings:
Step 1 Ensure that the Module Dock is not actively completing any firmware updates or other operations.
Step 2
Press and hold the Reset button for 10 seconds.
The unit's power LEDs begin to blink slowly as the factory default configuration is applied. The unit will reload the main
page within approximately three minutes.
