- Page 1 HDF-140A-SEA DEEP FREEZER HDF-300A-SEA HDF-400A-SEA INSTRUCTION MANUAL 3-16 Minamiyakata, Sakae-cho, Toyoake, Aichi 470-1194 Japan L1V112111 (061424)
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION ............................1 I. INSTALLATION INSTRUCTIONS ..............................3 1. CONSTRUCTION ................................3 2. ACCESSORIES ...................................3 3. UNPACKING ..................................4 4. LOCATION ...................................4 5. INSTALLATION ..................................5 6. ELECTRICAL CONNECTIONS ............................6 7. TRIAL RUN ..................................6 II. OPERATING INSTRUCTIONS ..............................7 1. OPERATION ..................................7 2. LOCKING/UNLOCKING UNIT .............................8 3. -
Page 3: Important Safety Information
ENGLISH IMPORTANT SAFETY INFORMATION Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. Indicates a hazardous situation which, if not avoided, could result in death or WARNING serious injury. - Page 4 * If the supply cord is damaged, it must be replaced by a replacement cord available from Hoshizaki Parts/Service Centres. * Do not touch the electrical parts or operate the switches with damp hands. * This appliance is not intended for use by persons (including children) with reduced physical,...
-
Page 5: Installation Instructions
Spec depends on country. Door Gasket * Seal the cabinet to Cabinet Opening prevent air leak. Separator (accessory) Basket (accessory) Drain Cap Interior 2. ACCESSORIES HDF-300A-SEA HDF-140A-SEA HDF-400A-SEA Instruction Manual Polyethylene Scraper Instruction Manual Polyethylene Scraper Separator Basket Separator Basket... -
Page 6: Unpacking
IMPORTANT If any part is found damaged or missing, contact your local Hoshizaki service agent. 3) Remove the protective plastic film from the exterior. If the freezer is exposed to the sun or to heat, remove the film after the freezer cools. -
Page 7: Installation
ENGLISH IMPORTANT Do not install the unit where the floor can be affected by water. In some high humidity environments, condensation may form inside the machine and drip onto the floor. Allow adequate clearance between the unit and the surrounding walls. Especially, a side-by-side or back-to-back installation (possibly with other manufacturer’s unit) may cause condensation between the two units, resulting in dripping onto the floor. -
Page 8: Electrical Connections
ENGLISH 6. ELECTRICAL CONNECTIONS WARNING THIS APPLIANCE MUST BE EARTHED This freezer requires an earth that meets the national and local electrical code requirements. Disconnect the main power supply before making any electrical connections to prevent possible electric shock. Attach a sign to warn against turning on the power supply during the electrical work. -
Page 9: Operating Instructions
When shutting down the unit for more than a week, turn off the power supply. Dust may collect and cause heat generation or ignition. Before restarting the unit after a long shutdown, contact your local Hoshizaki service agent. To prevent possible electric shock, do not restart the unit by yourself. -
Page 10: Operation
ENGLISH 1. OPERATION 1) Plug in the unit. 2) Turn on the power switch. The temperature display indicates the cabinet temperature, and the compressor fan motor starts in 5 minutes. 2. LOCKING/UNLOCKING UNIT Door Lock WARNING Unlock When the door lock is used, the key must be kept by the administrator to avoid unexpected accidents caused by pranks. -
Page 11: Temperature Setting
ENGLISH 5. TEMPERATURE SETTING The cabinet temperature is factory-adjusted to -60°C. If necessary, readjust the temperature using the set key on the operation panel. IMPORTANT Pressing the down key will not speed up refrigeration, but will only lower the temperature setting. The temperature setting range given in “SPECIFICATIONS”... -
Page 12: Storing Items
ENGLISH 6. STORING ITEMS CAUTION Do not throw anything into the basket or load more than 10 kg in it. The basket may fall off and cause injury. Stored items must be wrapped up in a -60°C resistant plastic film or packed in a container. Extremely cold items easily get broken when they fall off, causing a risk of injury. -
Page 13: Maintenance
1. MAINTENANCE Use an invert soap (benzalkonium chloride) for daily maintenance. To use an invert soap (benzalkonium chloride), consult your local Hoshizaki service agency. Dilute an invert soap (benzalkonium chloride) according to its manufacturer’s instructions. Remove dirt by using a cloth containing a neutral cleaner. After using a neutral cleaner, wipe thoroughly with a cloth containing clean water. - Page 14 ENGLISH To remove the door gasket from the unit, remove its corner first. Door Gasket NOTICE To prevent damage to the gasket, do not strongly pull its corner. [c] EXTERIOR (WEEKLY) The exterior collects dust, moisture or oil easily. To keep it clean, wipe every exterior surface thoroughly with a cloth containing an invert soap.
-
Page 15: Inspection
Even if there are no problems with its use, a product out of warranty may have a risk of electric shock, fire, or water leak due to insulation degradation or aging of the electrical parts. Ask your local Hoshizaki service agent for the following inspections... -
Page 16: Before Calling For Service
If the freezer does not work properly, check the following table before calling for service. If the problem still exists, turn off the power switch and contact your local Hoshizaki service agent. When contacting your local Hoshizaki service agent, let them know the model name, serial number, date of installation (see warranty card) and state of the trouble. -
Page 17: Relocation, Disposal, Transfer
Warranty repairs should be completed by an approved Hoshizaki dealer or service agency using genuine Hoshizaki components. To obtain full details of your warranty and approved service agency, please contact your local Hoshizaki service agent, or the nearest Hoshizaki Service office:... -
Page 18: Specifications
Hoshizaki Vietnam TEL: +65 6225 2612 TEL: +8428 5417 3853 FAX: +65 6225 3219 sales@hoshizaki.com.vn (Sales) sales@hoshizaki.com.sg (Sales) service@hoshizaki.com.vn (Technical support) serviceadmin@hoshizaki.com.sg (Technical support) Hoshizaki Thailand Hoshizaki Malaysia TEL: +66 2 005 9980 TEL: +60 3 8023 5823 Line: @hoshizakithailand FAX: +60 3 8024 1823 https://www.facebook.com/HoshizakiThailand...
