SSR Motorsports SR-E500 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR-E500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SSR Motorsports SR-E500

Summary of Contents for SSR Motorsports SR-E500

  • Page 1 Owner’s Manual...
  • Page 2 Congratulations on your decision to purchase an SSR SR-E500 motorcycle. In your possession is a state of the art motorsports vehicle that will provide your child with endless excitement so long as you maintain it properly. It is our hope that your child will enjoy many safe and fun rides! Read through this Owner’s Manual carefully, practice caution when checking...
  • Page 3 This Owner’s Manual contains the latest information at the time of printing. However, minor differences due to further developments in design may still be present. This Owner’s Manual can not be copied or reproduced without written consent. All rights reserved: This Owner’s Manual applies to the following model: SR-E500...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SYMBOL DEFINITIONS........18 1.1 Service Symbols Used........18 SAFETY PRECAUTIONS........20 2.1 Intended Use..........20 2.2 Misuse..............20 2.3 Note/Warning..........21 2.4 Warning Symbols.........21 2.5 Modification Warning.........22 2.6 Safe Operation..........23 2.7 Fall or Accident..........26 SR-E500 OWNER’S MANUAL...
  • Page 5 TABLE OF CONTENTS 2.8 Protective Apparel........26 2.9 Repair Warnings..........27 2.10 Environment...........28 2.11 Owner’s Manual..........29 2.12 Fire Hazard............30 IMPORTANT NOTES..........32 3.1 Manufacturer Warranty......32 3.2 Oil & Auxiliary Substances......32 3.3 Spare Parts & Accessories......32 3.4 Service..............33 SR-E500 OWNER’S MANUAL...
  • Page 6 TABLE OF CONTENTS 3.5 Customer Service.........34 3.6 Power Supply..........34 3.7 Operation at low temps......35 VEHICLE OVERVIEW..........36 4.1 Vehicle Overview.........36 SERIAL NUMBER............38 5.1 Vehicle Identification Number....38 5.2 Vehicle Nameplate........38 5.3 Battery Label..........39 SR-E500 OWNER’S MANUAL...
  • Page 7 TABLE OF CONTENTS 5.4 Motor Number..........39 CONTROLS..............40 6.1 Left Hand Brake Lever.........40 6.2 Right Hand Brake Lever......40 6.3 Throttle Grip...........41 6.4 Ignition Lock/Key.........41 6.5 Start Button............42 COMBINATION DISPLAY........43 7.1 Combination Display Overview....43 7.2 Display Function...........44 SR-E500 OWNER’S MANUAL...
  • Page 8 TABLE OF CONTENTS 7.3 Boot Screen...........44 7.4 Display Specs..........45 7.5 Display Interface..........46 7.6 Drive Mode Selection........47 7.7 Fault Codes............47 7.8 Trip Odometer Reset........48 7.9 Setting Km or Mi..........49 7.10 Power Display..........50 7.11 Fault Codes............51 SR-E500 OWNER’S MANUAL...
  • Page 9 TABLE OF CONTENTS PREPARING FOR USE...........52 8.1 Notes on Preparing For Use......52 RIDING INSTRUCTIONS........59 9.1 Pre-ride Inspection........59 9.2 Starting the Vehicle........61 9.3 Setting Off............62 9.4 Applying the Brakes........62 9.5 Riding and Water..........63 9.6 Stopping/Parking.........65 9.7 Transporting...........66 SR-E500 OWNER’S MANUAL...
  • Page 10 TABLE OF CONTENTS SERVICE SCHEDULE..........68 10.1 Additional Information.......68 10.2 Required Maintenance.......68 10.3 Recommended Maintenance....73 SUSPENSION SETUP..........74 11.1 Setting Sag Via Rider Weight....74 11.2 Rear Shock Absorber........75 11.3 Checking Unloaded Sag......76 11.4 Measuring Static Sag........77 SR-E500 OWNER’S MANUAL...
  • Page 11 TABLE OF CONTENTS 11.5 Measuring Riding Sag........78 11.6 Adjusting Rear Shock Preload....79 11.7 Handlebar Warning........82 SERVICE INSTRUCTIONS........83 12.1 Lifting the Unit Using a Motorcycle Stand..............83 12.2 Removing the Unit From a Motorcycle Stand..............83 12.3 Removing the Front Forks......85 SR-E500 OWNER’S MANUAL...
  • Page 12 12.4 Installing the Front Forks......86 12.5 Removing the Lower Triple Clamp..87 12.6 Installing the Lower Triple Clamp...89 12.7 Checking Steering Stem Bearing Play..............92 12.8 Adjusting Steering Stem Bearing Play..94 12.9 Lubricating the Steering Stem Bearings............96 12.10 Removing the Front Cover......96 SR-E500 OWNER’S MANUAL...
  • Page 13 12.12 Removing the Front Fender....97 12.13 Installing the Front Fender......98 12.14 Removing the Rear Shock Absorber...98 12.15 Installing the Rear Shock Absorber..99 12.16 Removing the Seat........100 12.17 Installing the Seat........101 12.18 Checking the Drive Chain.....102 12.19 Cleaning the Drive Chain......103 SR-E500 OWNER’S MANUAL...
  • Page 14 TABLE OF CONTENTS 12.20 Checking Drive Chain Tension....105 12.21 Adjusting Drive Chain Tension....108 12.22 Chain, Sprockets and Chain Guide Inspection...........111 12.23 Checking the Frame........115 12.24 Checking the Swingarm......116 12.25 Checking the Handlebar Grips....117 SR-E500 OWNER’S MANUAL...
  • Page 15 13.2 Checking the Front/Rear Brake Fluid..121 13.3 Adding Front/Rear Brake Fluid....125 13.4 Checking the Front Brake Pads.....129 13.5 Changing the Front Brake Pads....130 13.6 Checking the Rear Brake Pads....133 13.7 Changing the Rear Brake Pads....133 WHEELS & TIRES..........140 SR-E500 OWNER’S MANUAL...
  • Page 16 14.2 Installing the Front Wheel......141 14.3 Removing the Rear Wheel......143 14.4 Installing the Rear Wheel......146 14.5 Checking the Tire Condition....149 14.6 Checking the Tire Pressure.....151 14.7 Checking Spoke Tension......152 MOTOR, BATTERY, & BATTERY CHARGER154 15.1 Overview of Battery........154 15.2 Battery Compartment......154 SR-E500 OWNER’S MANUAL...
  • Page 17 15.4 Positioning the Battery Charger...156 15.5 Charging the Battery........160 15.6 Checking Controller Three Phase Cables & Power Line Hardware........167 COOLING..............168 16.1 Cooling............168 CLEANING & CARE..........169 17.1 Cleaning the Motorcycle......169 STORAGE..............173 18.1 Storage............173 18.2 Preparing For Use After Storage...176 SR-E500 OWNER’S MANUAL...

  • Page 18: Symbol Definitions

    In the interest of safety of your child, have these jobs performed by an authorized SSR Motor- sports dealer. Your motorcycle will be optimally cared for by their specially trained experts using any special tools required. Indicates information with more details or tips. SR-E500 OWNER’S MANUAL...
  • Page 19 SYMBOL DEFINITIONS 1 Indicates the result of a testing step. Indicates the end of an activity, including potential reworking. SR-E500 OWNER’S MANUAL...

  • Page 20: Safety Precautions

    This vehicle must only be used as intended. Dangers can arise for people, property, and the environment if the product is misused. Misuse also includes the use of operating and auxiliary fluids which do not meet the required specification for the respective use. SR-E500 OWNER’S MANUAL...

  • Page 21: Note/Warning

    Warning Symbols Warning Identifies a danger that will immediately and invariably lead to fatal or serious injury if the appropriate measures are not taken. SR-E500 OWNER’S MANUAL...

  • Page 22: Modification Warning

    Identifies a danger that will lead to environmental damage if the appropriate measures are not taken. Modification Warning No mechanical, electrical, or electronic modification may be made to the vehicle, since safe operation cannot be guaranteed. Examples of inadmissible manipulation and modifications: SR-E500 OWNER’S MANUAL...

  • Page 23: Safe Operation

    Children often underestimate or fail to recognize dangerous situations. - Your child must already be able to ride a bicycle. - Your child must be able to pick the vehicle up independently after a fall. SR-E500 OWNER’S MANUAL...
  • Page 24 Only let your child ride the vehicle if they are physically and mental- ly ready to do so. Warning Danger of burns Some vehicle components become very hot when the vehicle is operated. SR-E500 OWNER’S MANUAL...
  • Page 25 If the tempera- ture of the motor, lithium-ion battery, or the electronics rises above the permissible operating temperature, the power of the vehicle will be reduced considerably. This protects the system against damage from overheating. SR-E500 OWNER’S MANUAL...

  • Page 26: Fall Or Accident

    Fall or Accident After a fall or accident, evaluate the condition of your vehicle before you attempt to ride the vehicle again. Protective Apparel Warning Risk of injury Missing or poor protective apparel presents an increased safety risk. SR-E500 OWNER’S MANUAL...

  • Page 27: Repair Warnings

    - When you ride a motorcycle, set an example for your child and wear suitable protective apparel. Repair Warnings Warning Risk of Injury There is a risk of electric shock when working on live components. Working on live components requires special training, qualifications, and tools. SR-E500 OWNER’S MANUAL...

  • Page 28: Environment

    Protect the vehicle against access by unauthorized persons while you are performing work on the vehicle. 2.10 Environment When your respect the rights of others and use your motorcycle legally, you will help protect the future of motorcycling and avoid many con- flicts and problems. SR-E500 OWNER’S MANUAL...

  • Page 29: Owner's Manual

    When disposing of lithium-ion batteries, observe the relevant laws and guidelines of your country. Your authorized SSR Motorsports dealer can dispose of lithium-ion bat- teries free of charge and in an environmentally friendly manner. Electrical devices like the battery charger may not be disposed of with household waste.

  • Page 30: Fire Hazard

    The Owner’s Manual is an important component of the vehicle and must be handed over to the new owner if the vehicle is sold. 2.12 Fire Hazard Warning Fire hazard Damaged rechargeable lithium-ion batteries present a fire hazard. SR-E500 OWNER’S MANUAL...
  • Page 31 Mechanical damage may cause an internal cell short circuit and as a consequence may cause the battery to self-ignite. Contact an SSR Motorsports dealer immediately if major damage to the rechargeable lithium-ion battery has occurred. There is no particular fire hazard for this vehicle when the rechargeable lithium-ion battery is intact.

  • Page 32: Important Notes

    Modification, alteration, and installation of parts that are not genuine SSR Motorsports parts are not covered by the manufacturer warranty. Oil & Auxiliary Substances Use the operating and auxiliary substances (such as oils and lubricants) specified in this Owner’s Manual.

  • Page 33: Service

    For this reason, it may be necessary to inspect of replace parts before the next scheduled service interval. It is imperative that you adhere to the stipulated service intervals. If you observe these exactly, you will ensure a much longer service life for your motorcycle. SR-E500 OWNER’S MANUAL...

  • Page 34: Customer Service

    3 IMPORTANT NOTES Customer Service Your authorized SSR Motorsports dealer will be happy to answer any questions you may have about your vehicle. Power Supply A rechargeable lithium-ion battery (1) is installed in the vehicle. The lithium-ion battery supplies the electric motor (2) with voltage.

  • Page 35: Operation At Low Temps

    The lithium-ion battery is not damaged by this power reduction. The lithium-ion battery heats up when the vehicle is in operation. When the temperature of the lithium-ion battery exceeds a threshold value, full vehicle power is restored after the vehicle is restarted. SR-E500 OWNER’S MANUAL...

  • Page 36: Vehicle Overview

    Right Rear # Plate Seat Throttle Grip Front Brake Lever Front Number Plate Ignition Switch Front Fender Right Front Shroud Right Front Fork Front Tire Charging Port Motor Rear Shock Absorber Swingarm Rear Brake Caliper Rear Brake Rotor SR-E500 OWNER’S MANUAL...
  • Page 37 Rear Brake Lever Left Front Fork Rubber Handgrip Handlebar Lower Triple Clamp Upper Triple Clamp Left Rear # Plate Frame Rear Rim Chain Cover Rear Sprocket Side Stand Left Front Shroud Front Brake Caliper Front Brake Rotor Front Rim SR-E500 OWNER’S MANUAL...

  • Page 38: Serial Number

    5 SERIAL NUMBER Vehicle Identification Number The vehicle identification number (1) is stamped into the right side of the steering stem. Vehicle Nameplate The vehicle nameplate (1) is located on the left side of the frame. SR-E500 OWNER’S MANUAL...

  • Page 39: Battery Label

    SERIAL NUMBER 5 Battery Label The battery label (1) is located on the bottom end of the battery. Motor Number The motor number (1) is located on the right side of the motor. SR-E500 OWNER’S MANUAL...

  • Page 40: Controls

    The left brake lever is used to activate the rear brake. Front Brake Lever The right hand brake lever (1) is located on the right side of the handlebar. The right hand brake lever is used to activate the front brake. SR-E500 OWNER’S MANUAL...

  • Page 41: Throttle Grip

    Ignition Off - in this position, the electric circuit of the battery is interrupted and the vehicle cannot be activated. Ignition On - in this position, the electric circuit of the battery is opened and the vehicle can be started. SR-E500 OWNER’S MANUAL...

  • Page 42: Start Button

    When the start button is pressed, the vehicle switches into standby mode. Info Selecting a power level switches the vehicle from standby mode to riding mode. If the vehicle is not moved for 120 seconds, the vehicle automatically switches to standby mode. SR-E500 OWNER’S MANUAL...

  • Page 43: Combination Display 7

    - Press the button to adjust between trip meter and odometer. Info - Turning the power on, the display automatically powers on. - Turning the power off, the display automatically powers off. SR-E500 OWNER’S MANUAL...

  • Page 44: Display Function

    7 COMBINATION DISPLAY Display Functions Boot Screen Turn on the ignition switch (p.41) the vehicle is activated and the display shows “PAS 0” state and is in standby mode. Press the “+” button to activate “PAS 1” for riding. SR-E500 OWNER’S MANUAL...

  • Page 45: Display Specs

    COMBINATION DISPLAY 7 Specifications Power Rated Operation Current 42mA/36V Maximum Operation Current 42mA Key Off Current Drain < 1uA Output Current 42mA Operating Temperature -4 °F ~ 140 °F Storage Temperature -22 °F ~ 158 °F SR-E500 OWNER’S MANUAL...

  • Page 46: Display Interface

    Briefly press the “M” button to switch between total mileage (miles), and trip mileage (miles). Info If the vehicle is not moved for 120 seconds, the vehicle automatically switches to standby mode until the start button is pressed again. SR-E500 OWNER’S MANUAL...

  • Page 47: Drive Mode Selection

    Error Code Display When the electric vehicle electronic control sys- tem encounters an error, the display will auto- matically display the error code, the fault code is displayed in the speedometer digital segment, the format is E**. SR-E500 OWNER’S MANUAL...

  • Page 48: Trip Odometer Reset

    Press the “M” button for more than 2 seconds, the display will change to “N”, press the “+” button to change it to “Y” then press the “M” button again, the display will be reset to 0.0. SR-E500 OWNER’S MANUAL...

  • Page 49: Setting Km Or Mi

    Then short press the “+” or “-” button to adjust the MPH and KPH settings. Make your adjustment and short press “M” again to lock the adjustment. Long press the “M” button (3 seconds) again to return to the main display. SR-E500 OWNER’S MANUAL...

  • Page 50: Power Display

    - The five-segment battery power display. When the battery is full, the five-segment lights are all on. When the battery is depleted, the out- er frame of the battery flashes, indicating that it needs to be charged immediately. SR-E500 OWNER’S MANUAL...

  • Page 51: Fault Codes

    Hall Sensor Wire Failure Throttle Failure Overvoltage Protection Phase Current Overcurrent Voltage Failure Motor Temp. Too High Controller Temp. Too High Phase Current Overflow Phase Current Failure Phase Wire Short Circuit Wire Current Failure Brake Failure Communication Failure SR-E500 OWNER’S MANUAL...

  • Page 52: Preparing For Use

    - Your child must understand that rules and instructions from you or from another responsible person must be followed. - Make it clear to your child that they should not, under any circumstances, operate the vehicle without supervision. SR-E500 OWNER’S MANUAL...
  • Page 53 - Ensure your child wears appropriate protective clothing such as a helmet, boots, eye protection, gloves, pants, a long-sleeved jersey, and a shirt of jacket on all rides. Always use protective apparel for your child that is in good condition and meets the legal requirements. SR-E500 OWNER’S MANUAL...
  • Page 54 Make sure that only tires with a similar tire tread pattern are fitted to the front and rear wheels. Warning Danger of crashes This vehicle is not designed to carry passengers. - Make it clear to your child that they must not carry a passenger. SR-E500 OWNER’S MANUAL...
  • Page 55 Note Overloading The suspension components will become damaged or destroyed if overloaded. Do not exceed the maximum permissible weight of the rider. Warning Risk of misappropriation People who act without authorization endanger themselves and others. SR-E500 OWNER’S MANUAL...
  • Page 56 - Protect the vehicle against access by unauthorized persons. - Ensure that the pre-sales inspection work has been completed by an authorized SSR Motorsports dealer. (PDI = Pre-Delivery Inspection) - Rear through the entire Owner’s Manual together with your child before riding for the first time.
  • Page 57 Your child should begin by riding to another person, who can help your child stop and turn. - Erect obstacles for your child to navigate around so that your child becomes accustomed to the vehicles handling characteristics. SR-E500 OWNER’S MANUAL...
  • Page 58 Maximum Rider Weight 88 lbs. (40kg) Guideline: Maximum Rider Height < 51.2 in (< 130cm) - Check the spoke tension (p.152) Info The spoke tension must be checked after 30 minutes of operation. SR-E500 OWNER’S MANUAL...

  • Page 59: Riding Instructions 9

    - Check the throttle grip, Lithium-ion battery, and electric motor for external damage. - Check the front brake fluid level. (p.121) - Check the rear brake fluid level. (p.121) - Check the front brake pads. (p.129) - Check the rear brake pads. (p.133) SR-E500 OWNER’S MANUAL...
  • Page 60 - Check the chain tension. (p.105) - Check the tire condition. (p.149) - Check the tire pressures. (p.151) - Check the spoke tension. (p.152) Info The spoke tension must be checked regularly as incorrect spoke tension will strongly impair riding safety. SR-E500 OWNER’S MANUAL...

  • Page 61: Starting The Vehicle

    - Check the charging level of the lithium-ion battery. Starting the Vehicle - Fold up the side stand. - Turn On the ignition key switch. The vehicle is in standby mode. - Push the start button. (p.42) SR-E500 OWNER’S MANUAL...

  • Page 62: Setting Off

    - Explain to your child that they must brake carefully several times to dry out and remove dirt from the brake pads and rotors. - On sandy, wet, or slippery surfaces, use the rear brake. - Always finish braking before you begin a turn. SR-E500 OWNER’S MANUAL...

  • Page 63: Riding And Water

    Do not rush toward water crossings that you are not aware of the depth of. Don’t let water flood the motor which could lead to motor malfunction. SR-E500 OWNER’S MANUAL...
  • Page 64 Before plugging in the charger, wipe the battery and connection socket first to avoid accidents. Info For the safety of your vehicle, the wading depth under normal operation is less than “A” (100mm / 4 inches). SR-E500 OWNER’S MANUAL...

  • Page 65: Stopping/Parking

    - Do not touch any parts such as the motor, lithium-ion battery, or brake system before these vehicle parts have cooled down. - Let the vehicle parts cool down before you perform any work on the vehicle. SR-E500 OWNER’S MANUAL...

  • Page 66: Transporting

    - Park the vehicle on a firm and level surface. - Ensure that nobody sits on the vehicle when the vehicle is parked on the side stand. Transporting Note Danger of Damage The parked vehicle can roll away or fall over. SR-E500 OWNER’S MANUAL...
  • Page 67 - Allow the vehicle to cool down before covering it. - Turn off the ignition switch to power off the vehicle. - Use tie downs or other suitable de- vices to secure the motorcycle against falling over or rolling away. SR-E500 OWNER’S MANUAL...

  • Page 68: Service Schedule

    10.1 Additional Information For the riding safety of your child, you must regularly check the vehicle. Any authorized SSR Motorsports dealer would be pleased to help you if you have any issues performing this repair work. 10.2 Service Schedule Every 80 Operating Hours...
  • Page 69 Check and charge the Lithium-ion battery. Check the front brake pads. (p.129) Check the rear brake pads. (p.133) Check the brake rotors. (p.119) Check the brake hoses for damage and leakage. Check the front brake fluid level. (p.121) One-time interval Periodic interval SR-E500 OWNER’S MANUAL...
  • Page 70 Check the frame. (p.115) Check the swingarm. (p.116) Check the swingarm bearing play. Check the tire condition. (p.149) Check the tire pressure. (p.151) Check the wheel bearings for play. Check the wheel hubs. One-time interval Periodic interval SR-E500 OWNER’S MANUAL...
  • Page 71 Check the chain, rear sprocket, motor sprocket, and chain guide. (p.111) Check the chain tension. (p.105) Grease all moving parts (e.g., levers, drive chain, ...) and check for smooth operation. Check the steering stem bearing play. (p.92) One-time interval Periodic interval SR-E500 OWNER’S MANUAL...
  • Page 72 Service the front forks. Service the rear shock absorber. Check the tightness of the easily accessible, safety-relevant EVERY RIDE bolts, screws, and nuts. Final Check: Check the vehicle for safe operation and take a test ride. One-time interval Periodic interval SR-E500 OWNER’S MANUAL...

  • Page 73: Recommended Maintenance

    Every 20 Operating Hours After 10 Operating Hours Every 12 Months Change the front brake fluid. Change the rear brake fluid. Service the front forks. Service the rear shock absorber. Lubricate the steering stem bearings. (p.96) One-time interval Periodic interval SR-E500 OWNER’S MANUAL...

  • Page 74: Suspension Setup

    - This vehicle is delivered preset for a standard rider’s weight (with full protective apparel). Guideline Standard Rider Weight 25 - 40 kg (55 - 88 lbs) SR-E500 OWNER’S MANUAL...

  • Page 75: Rear Shock Absorber

    - Small weight differences can be compensat- ed by adjusting the spring preload, but in the case of larger weight differences, the springs must be replaced. 11.2 Rear Shock Absorber The rear shock absorber is mounted between the frame and swingarm. SR-E500 OWNER’S MANUAL...

  • Page 76: Checking Unloaded Sag

    Main Work - Measure the vertical distance between the rear axle and a fixed point such as the side cov- - Note the value as dimension A. Finishing Work - Remove the motorcycle from the lift stand. (p.83) SR-E500 OWNER’S MANUAL...

  • Page 77: Measuring Static Sag

    - Measure the distance between the rear axle and a fixed point again. - Note the value as dimension B. Info The static sag is the difference between measurements A and B. Check the static sag. Static Sag 6 mm (0.23in) SR-E500 OWNER’S MANUAL...

  • Page 78: Measuring Riding Sag

    - With another person holding the motorcycle, the rider, wearing full protective apparel, sits on the seat in a normal seating position (feet on footpegs) and bounces up and down a few times. The rear wheel suspension levels out. SR-E500 OWNER’S MANUAL...

  • Page 79: Adjusting Rear Shock Preload

    The riding sag is the difference between measurements A and C. Check the riding sag. Riding Sag 60mm (2.34in) If the riding sag differs from the specified measurement: - Adjust the spring preload. (p.79) 11.6 Adjusting Rear Shock Absorber Spring Preload SR-E500 OWNER’S MANUAL...
  • Page 80 - Turn the adjusting ring (1) until the spring is no longer under tension Hook Wrench Tool (45-52) - Measure the total spring length while the spring is not under tension. SR-E500 OWNER’S MANUAL...
  • Page 81 Depending on the static sag and/or the riding sag, it may be necessary to increase or decrease the spring preload. Finishing Work - Install the shock absorber. (p.99) - Remove the motorcycle from the lift stand. (p.83) SR-E500 OWNER’S MANUAL...

  • Page 82: Handlebar Warning

    The handlebar may break as a result. - Change the handlebar if the handlebar is damaged or bent. Info Make sure the cables and wiring are routed correctly. SR-E500 OWNER’S MANUAL...

  • Page 83: Service Instructions

    - Park the vehicle on a firm and level surface. - Lift the motorcycle at the frame under the electric motor. Neither wheel is in contact with the ground. - Secure the motorcycle against falling over. 12.2 Removing the Motorcycle From the Stand SR-E500 OWNER’S MANUAL...
  • Page 84 (1) down to the ground with your foot and lean the motorcycle on it. Info When you are riding, the side stand (1) must be folded up. Finishing Work - Remove the motorcycle from the lift stand. (p.83) SR-E500 OWNER’S MANUAL...

  • Page 85: Removing The Front Forks

    - Remove the front wheel. (p.140) Main Work - Remove the bolts (1) and remove the brake caliper. - Allow the brake caliper and the brake hose to hang loosely to the side. Info Do not kink the brake hose. SR-E500 OWNER’S MANUAL...

  • Page 86: Installing The Front Forks

    - Loosen bolts D then remove the right fork leg. 12.4 Installing the Front Forks - Position the brake caliper over the rotor, se- cure with bolts (1), and tighten. Guideline 20Nm (14.8lbf.ft) Bolts, Front Brake Caliper SR-E500 OWNER’S MANUAL...

  • Page 87: Removing The Lower Triple Clamp

    Bolts, Upper Triple Clamp - Tighten Bolts D Guideline 15Nm (11.1lbf.ft) Bolts, Lower Triple Clamp Finishing Work - Install the front wheel. (p.141) 12.5 Removing the Lower Triple Clamp Preparatory Work - Raise the motorcycle with a lift stand. (p.83) SR-E500 OWNER’S MANUAL...
  • Page 88 Cover the components to protect them against damage. Do not kink the brake hoses or cables. - Remove the locking nut (2) - Remove the lower triple clamp with steering stem. - Remove the upper steering head bearing. SR-E500 OWNER’S MANUAL...

  • Page 89: Installing The Lower Triple Clamp

    - Insert the lower triple clamp with the steering (1). stem. Install the upper steering stem bearing - Push on protective ring (2). - Position the upper triple clamp with the handlebar. - Install the bolt D, but do not tighten it yet. SR-E500 OWNER’S MANUAL...
  • Page 90 12 CHASSIS SERVICE - Tighten bolts F. Guideline 15Nm (11.1lbf.ft) Bolts, Lower Triple Clamp Tighten bolt D. Guideline M10x1.5 Bolt, Steering Stem 45Nm (33.1lbf.ft) Tighten bolt E. Guideline M10 45Nm (33.1lbf.ft) Bolts, Fork Crown SR-E500 OWNER’S MANUAL...

  • Page 91: Play

    - Install the front cover. (p.97) - Check that the cables and brake hose are routed correctly. - Install the front wheel. (p.141) - Check the steering head bearing play. (p.92) - Remove the motorcycle from the lift stand. (p.83) SR-E500 OWNER’S MANUAL...
  • Page 92 Danger of crashes Incorrect steering stem bearing play impairs the handling characteristics and damages components. - Correct incorrect steering head bearing play immediately. (Your authorized SSR Motorsports dealer will be happy to help.) Info If the vehicle is operated for a lengthy period with play in the steering stem bearings, the bearings and the bearings seats in the frame will become damaged over time.
  • Page 93 Play should not be detectable in the steering head bearings. If there is detectable play: - Adjust the steering stem bearing play. (p.94) - Move the handlebar back and forth over the entire steering range. SR-E500 OWNER’S MANUAL...

  • Page 94: Adjusting Steering Stem Bearing Play

    - Check the steering stem bearings and re- place if required. Finishing Work - Remove the motorcycle from the lift stand. (p.83) 12.8 Adjusting the Steering Stem Bearing Play Preparatory Work - Raise the motorcycle with a lift stand. (p.83) SR-E500 OWNER’S MANUAL...
  • Page 95 - Using a plastic hammer, gently tap on the upper triple clamp to avoid stresses. - Tighten bolts (1). Guideline M10 45Nm (33.1lbf.ft) Bolts, Fork Crown Finishing Work - Check the steering stem bearing play. (p.90) - Remove the motorcycle from the lift stand. (p.83) SR-E500 OWNER’S MANUAL...

  • Page 96: Bearings

    The steering stem bearings are cleaned and lubricated in the course of removal and installation of the lower triple clamp. 12.10 Removing the Front Cover - Remove the bolt (1). - Remove the front cover from the front fender. SR-E500 OWNER’S MANUAL...

  • Page 97: Installing The

    - Position the front cover. - Mounting lugs (2) engage the front fender. - Install and tighten the bolt (1). Bolt, Front Cover 4Nm (3 lbf.ft) 12.12 Removing the Front Fender - Remove the bolts (1), take off the front fender. SR-E500 OWNER’S MANUAL...

  • Page 98: Installing The Front Fender

    - Position the front fender. Mount and tighten bolts (2). Guideline: Bolt, Fender 6Nm (4.4 lbf.ft) 12.14 Removing the Rear Shock Absorber Preparatory Work - Raise the motorcycle with a lift stand. (p.83) Main Work Note the installation position of the rear shock absorber. SR-E500 OWNER’S MANUAL...

  • Page 99: Installing The Rear Shock Absorber

    12.15 Installing the Rear Shock Absorber Warning Danger of crashes Modifications to the suspension settings may seriously alter the handling characteristics. Main Work - Mount the shock absorber with bolt (1). Guideline If necessary, observe the installation position noted during removal. SR-E500 OWNER’S MANUAL...

  • Page 100: Removing The Seat

    - Mount the shock absorber with bolt (1). - Lift the swingarm, install bolt (2) and tight- en it. Bolt, Bottom Shock 25Nm (18.4lbf.ft) Absorber Finishing Work - Remove the motorcycle from the lift stand. (p.83) 12.16 Removing the Seat SR-E500 OWNER’S MANUAL...

  • Page 101: Installing The Seat

    - Pull the seat toward the rear of the unit to remove it. 12.17 Installing the Seat - The seat retainer hook (2) must be fitted into the frame seat lug (1), lower the rear of the seat and push it forward. SR-E500 OWNER’S MANUAL...

  • Page 102: Checking The Drive Chain

    12 CHASSIS SERVICE - Install the wingnut (1). 12.18 Checking the Chain for Dirt - Check the chain for coarse dirt accumulation. If the chain is very dirty: - Clean the chain. (p.103) SR-E500 OWNER’S MANUAL...

  • Page 103: Cleaning The Drive Chain

    Danger of Crashes Oil or grease on the brake rotors reduces the braking effect. - Always keep the brake rotors free of oil and grease. - Clean the brake rotors with brake cleaner when necessary. Note Environmental Hazard Hazardous substances cause environmental damage. SR-E500 OWNER’S MANUAL...
  • Page 104 - Raise the motorcycle with a lift stand. Main Work - Rinse off loose dirt with a soft jet of water. - Remove old grease residue with a chain cleaner. Chain Cleaner - After drying, apply chain lubricant. SR-E500 OWNER’S MANUAL...
  • Page 105 Danger of crashes Incorrect chain tension damages components and results in crashes. If the chain is tensioned too much, the chain, motor sprocket, rear sprocket, and rear wheel bearings wear more quickly. Some components may break if overloaded. SR-E500 OWNER’S MANUAL...
  • Page 106 - Set the chain tension in accordance with the specification. Preparatory Work - Raise the motorcycle with a lift stand. (p.83) Main Work - Press the chain upward at the end of the chain sliding piece and determine chain ten- sion SR-E500 OWNER’S MANUAL...
  • Page 107 Chain Tension 25 - 40mm (0.98 - 1.57in) If the chain tension does not meet the specification. - Adjust the chain tension. Finishing Work - Remove the motorcycle from the lift stand. (p.83) SR-E500 OWNER’S MANUAL...
  • Page 108 If the chain is too loose, the chain may fall off the motor sprocket or the rear sprocket. As a result, the rear wheel locks or the motor will be damaged. Check the chain tension regularly. Set the chain tension in accordance with the specification. SR-E500 OWNER’S MANUAL...
  • Page 109 - Check the chain tension. (p.105) Main Work - Loosen nut (1). - Loosen nut (2). - Adjust the chain tension by turning the adjusting nuts D left and right. Guideline Chain Tension 25 - 40mm (0.98 - 1.57in) SR-E500 OWNER’S MANUAL...
  • Page 110 The rear wheel is then correctly aligned. - Tighten nuts (2). - Make sure that the chain adjusters E are fitted correctly on the swingarm. - Tighten nut (1). Guideline Nut, rear wheel M12x1.5 75Nm (55.3 spindle lbf.ft) SR-E500 OWNER’S MANUAL...
  • Page 111 - Raise the motorcycle with a lift stand. (p.83) Main Work - Check the chain, rear sprocket and motor sprocket for wear. If the chain, rear sprocket or motor sprocket is worn: - Change the drivetrain kit. SR-E500 OWNER’S MANUAL...
  • Page 112 If the chain is worn: - Change the drive chain kit. Info When a new chain is mounted, the rear sprock- et and motor sprocket should also be changed. New chains wear out faster on old, worn sprockets. SR-E500 OWNER’S MANUAL...
  • Page 113 - Tighten the screw of the chain sliding guard. 3Nm (2.2 lbf.ft) Screw, chain sliding guard - Check the chain sliding piece for wear. If the lower edge of the chain pins is in the line with, or below the chain sliding guard. SR-E500 OWNER’S MANUAL...
  • Page 114 Bolt, chain sliding piece 10Nm (7.37 lbf.ft) - Change the chain guide for wear. Info Wear can be seen on the front of the chain guide. If the light part of the chain guide is worn: - Change the guide. SR-E500 OWNER’S MANUAL...
  • Page 115 - Remove the motorcycle from the lift stand. (p.83) 12.23 Checking the Frame - Check the frame for cracks and deformation. If the frame exhibits cracks or deformation due to a mechanical impact: - Change the frame. SR-E500 OWNER’S MANUAL...
  • Page 116 Repair of the frame is not authorized by SSR Motorsports. 12.24 Checking the Swingarm - Check the swingarm for damage, cracking, and deformation. If the swingarm shows signs of damage, cracking, or deformation: - Change the swingarm. SR-E500 OWNER’S MANUAL...
  • Page 117 Repairing the swingarm is not authorized by SSR Motorsports. 12.25 Checking the Rubber Grips - Check the rubber handgrip on the handlebar for damage, wear, and looseness. If a rubber grip is damaged, worn, or loose: - Change the rubber grip. SR-E500 OWNER’S MANUAL...
  • Page 118 The left sleeve is installed onto the handlebar. The rubber grip can only be replaced with the sleeve of the throttle tube. SR-E500 OWNER’S MANUAL...
  • Page 119 Danger or crashes Worn out brake rotors reduce the braking effect. - Make sure that worn-out brake rotors are replaced immediately (Your authorized SSR Motorsports dealer will be happy to help.) - Check the front and rear brake rotor thickness at multiple points for the dimension A.
  • Page 120 - Change the front brake rotor. - Change the rear brake rotor. - Check the front and rear brake rotors for damage, cracking, and deformation. - Change the front brake rotor. - Change the rear brake rotor. SR-E500 OWNER’S MANUAL...
  • Page 121 - Check the brake system and do not continue riding until the problem is corrected. (Your authorized SSR Motorsports dealer will be happy to help.) Warning Skin Irritation Brake fluid causes skin irritation.
  • Page 122 Danger of Crashes Old brake fluid reduces the braking effect. - Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized SSR Motorsports dealer will be happy to help.) SR-E500 OWNER’S MANUAL...
  • Page 123 Info Never use DOT brake fluid. It is silicone-based and can be purple in color. Oil seals and brake lines are not designed for DOT brake fluid. Only use clean mineral oil from a sealed container. SR-E500 OWNER’S MANUAL...
  • Page 124 If the brakes feel spongy and/or have inade- quate braking effect, replace the fluid: - Add front/rear brake fluid. (p.125) Info Immediately clean up any mineral oil that has over-flowed or spilled using soap. SR-E500 OWNER’S MANUAL...
  • Page 125 - Check the brake system and do not continue riding until the problem is corrected. (Your authorized SSR Motorsports dealer will be happy to help.) Warning Skin Irritation Brake fluid causes skin irritation.
  • Page 126 Danger of Crashes Old brake fluid reduces the braking effect. - Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized SSR Motorsports dealer will be happy to help.) SR-E500 OWNER’S MANUAL...
  • Page 127 Info Never use DOT brake fluid. It is silicone-based and can be purple in color. Oil seals and brake lines are not designed for DOT brake fluid. Only use clean mineral oil from a sealed container. SR-E500 OWNER’S MANUAL...
  • Page 128 - Once the lever feels solid, insert the bowl stopper E and remove the bowl. - Reinstall the bleeder bolt. (search for bicycle brake bleed kit to find the kit we used) Info Immediately clean up any mineral oil that has over-flowed or spilled using soap. SR-E500 OWNER’S MANUAL...
  • Page 129 Worn-out brake pads reduce the braking effect. If the minimum thickness is less than specified. - Ensure that worn-out brake pads are replaced immediately. (Your authorized SSR Motorsports dealer will be happy to help.) - Check the brake pads for minimum thickness >1mm (>0.04in)
  • Page 130 Changing the Front Brake Pads Warning Danger or crashes Incorrect servicing will cause the brake system to fail. Ensure that service work and repairs are performed professionally. (Your authorized SSR Motorsports dealer will be happy to help.) SR-E500 OWNER’S MANUAL...
  • Page 131 - Remove the brake pads. - Clean the brake caliper and the brake caliper bracket. - Position the new brake pads. Info Always change the brake pads in pairs. Ensure that the brake pads are correctly positioned in the holding spring. SR-E500 OWNER’S MANUAL...
  • Page 132 - Always keep the brake rotors free of oil and grease. - Clean the brake rotors with brake cleaner when necessary. - Check the brake rotors. - Position the brake caliper, install bolts (1), and tighten. Guideline Bolt, front brake caliper 20Nm (14.8 lbf.ft) SR-E500 OWNER’S MANUAL...
  • Page 133 If the minimum thickness is less than specified: - Change the rear brake pads. (p.133) - Check the brake pads for damage and cracking. If damage or wear is encountered. - Change the rear brake pads. (p.133) 13.7 Changing the Rear Brake Pads SR-E500 OWNER’S MANUAL...
  • Page 134 Danger or crashes Incorrect servicing will cause the brake system to fail. Ensure that service work and repairs are performed professionally. (Your authorized SSR Motorsports dealer will be happy to help.) Warning Skin Irritation Brake fluid causes skin irritation. - Keep brake fluid out of the reach of children.
  • Page 135 - Make sure that brake fluid for the front and rear brake is changed in accordance with the service schedule. (Your authorized SSR Motorsports dealer will be happy to help.) Warning Danger or crashes Oil or grease on the brake rotors reduces the brake effect.
  • Page 136 Danger of Crashes Brake pads that have not been approved alter the braking efficiency. Not all brake pads are tested and approved for SSR Motorsports motorcycles. The structure and friction coefficient of the brake pads, and thus their braking power, may very greatly from that of the original brake pads.
  • Page 137 Avoid contact between brake fluid and painted parts. Brake fluid attacks paint. Only use clean mineral oil from a sealed container. Preparatory Work - Raise the motorcycle with a lift stand. - Remove the nut (1). - Remove the chain adjuster (2). SR-E500 OWNER’S MANUAL...
  • Page 138 - Clean the brake caliper and the brake caliper bracket. - Allow the brake caliper and the brake line to hang loosely to the side. - Check the brake rotors. (p.119) - Install the new brake pads. SR-E500 OWNER’S MANUAL...
  • Page 139 - Install the brake caliper over the brake rotor. The brake pads are correctly positioned. - Install the wheel axle (1). - Install and tighten the nut (2). Finishing Work - Remove the motorcycle from the lift stand. (p.83) SR-E500 OWNER’S MANUAL...
  • Page 140 - Loosen nut (1). - Remove the wheel axle (2). Warning Danger or crashes Damaged brake rotors reduce the braking effect. - Always lay the wheel down in such a way that the brake rotor is not damaged. SR-E500 OWNER’S MANUAL...
  • Page 141 Installing the Front Wheel Warning Danger or crashes Oil or grease on the brake rotors reduces the braking effect. - Always keep the brake rotors free of oil and grease. - Clean the brake rotors with brake cleaner when necessary. SR-E500 OWNER’S MANUAL...
  • Page 142 - Change the front wheel bearings. - Clean and grease the contact surfaces the wheel spacers. - Clean the wheel axle. - Position the front wheel. The brake pads are correctly positioned. - Insert the wheel axle. SR-E500 OWNER’S MANUAL...
  • Page 143 - Remove the motorcycle from the lift stand. - Operate the front brake and compress the forks a few times firmly. That the fork legs straighten. 14.3 Removing the Rear Wheel SR-E500 OWNER’S MANUAL...
  • Page 144 - Remove the axle D far enough to allow the rear wheel to be pushed forward. - Push the rear wheel forward as far as possi- ble. Remove the chain from the rear sprocket. Info Cover the components to protect them against damage. SR-E500 OWNER’S MANUAL...
  • Page 145 - Hold the rear wheel and remove the wheel axle. Remove the rear wheel from the swingarm. Info Do not operate the rear brake lever when the rear wheel is removed. - Remove the spacers E. SR-E500 OWNER’S MANUAL...
  • Page 146 - Always keep the brake rotors free of oil and grease. - Clean the brake rotors with brake cleaner when necessary. Main Work - Check the wheel bearings for damage and wear. If the wheel bearing(s) are damaged or worn: - Change the rear wheel bearings. SR-E500 OWNER’S MANUAL...
  • Page 147 - Position the rear wheel and insert the wheel axle. The brake pads are correctly positioned. - Mount the chain. - Position the chain adjuster (2) on both sides and push the wheel axle in all the way. SR-E500 OWNER’S MANUAL...
  • Page 148 - Operate the rear brake lever repeatedly until the brake pads are in contact with the brake rotor and a firm feeling returns to the brake lever. Finishing Work - Remove the motorcycle from the lift stand. (p.83) SR-E500 OWNER’S MANUAL...
  • Page 149 The type, condition, and pressure of the tires all have a major impact on the handling characteristics of the motorcycle. The tires mounted on the front and rear wheels must have a similar profile. Worn tires have a negative effect on handling characteristics especially on wet surfaces. SR-E500 OWNER’S MANUAL...
  • Page 150 - Change the tires. - Check the tread depth. Info Observe the minimum profile depth required by national law. Minimum tread depth >2mm (>0.08in) If the tread depth is less than the minimum tread depth: - Change the tires. SR-E500 OWNER’S MANUAL...
  • Page 151 - Check tire pressure when the tires are cold. Off-road tire pressure FRONT 10 - 15 psi REAR 10 - 15 psi If the tire pressure does not meet specifications: - Correct the tire pressure. - Install the valve stem cap. SR-E500 OWNER’S MANUAL...
  • Page 152 Other spokes will become loose as a result. - Check spoke tension regularly, and in particular on a new vehicle. (Your authorized SSR Motorsports dealer will be happy to help.) - Rotate each spoke nipple briefly using a spoke wrench. SR-E500 OWNER’S MANUAL...
  • Page 153 You should hear a high pitched note. If the spoke tension differs: - Correct the spoke torque. Guideline Spoke nipple M3.5 3Nm (2.2 lbf.ft) SR-E500 OWNER’S MANUAL...
  • Page 154 15 MOTOR, BATTERY, CHARGER 15.1 Overview of the Battery Carrying Handle Charging Port Power Display Lithium Battery 15.2 Battery Compartment and Replacement Battery Battery Compartment Battery Retainer Bracket SR-E500 OWNER’S MANUAL...
  • Page 155 2 screws (2). - Connect the battery to unit D. Info Be careful not to crush the battery connector under the battery during installation. 15.3 Overview of the Battery Charger Battery Charger Charging Cable Power Cord SR-E500 OWNER’S MANUAL...
  • Page 156 - Do not use any additional adapters or extensions. Follow the applicable safety instructions of the power connection. Warning Risk of Injury There is a risk of electric shock if the battery charger or the cables have been manipulated or damaged. SR-E500 OWNER’S MANUAL...
  • Page 157 Info The battery charger contains sensitive electronics and must be handled with appropriate care. The battery charger may be damaged or destroyed if it is dropped, knocked or otherwise subject to mechanical overload. SR-E500 OWNER’S MANUAL...
  • Page 158 Info The battery charger should only be used in a dry environment, as moisture may penetrate into the interior when connecting and disconnecting the charger leads. - Check the battery charger and mains cable for external damage. SR-E500 OWNER’S MANUAL...
  • Page 159 - Battery Charger Specifications: Input Voltage 100 ~ 240V Input Voltage Frequency 50/60HZ Maximum Charging Voltage DC54.6 ± 0.2V Maximum Input Current 90-260V, AC2A Output Current Info A change in temperature can cause moisture to condense on the battery charger. SR-E500 OWNER’S MANUAL...
  • Page 160 Danger of Burns The plastic housing of the battery charger becomes hot during operation. - Only touch the battery charger once it has cooled. - After charging, allow the battery charger to cool before stowing it away. Battery Characteristics Guideline Battery Cell Type INR18650-26E SR-E500 OWNER’S MANUAL...
  • Page 161 Charging Voltage 54.6 ± 0.2V Standard Charge 2A, 54.6V Maximum Charge 3.5A, 54.9V 18A discharge, 35.1V cut Standard Discharge off, at 103.6~114.4 ° F 20A (continuous) Maximum Discharge Charge: 32~113 ° F Operating Temperature Discharge: -4~149 ° F SR-E500 OWNER’S MANUAL...
  • Page 162 - Never throw a battery into the household trash. - Dispose of the battery properly and in compliance with the applicable regulations. (Your authorized SSR Motorsports dealer is happy to help.) Info Do not activate the vehicle while the battery charger is connect- ed to the battery.
  • Page 163 - Charging Plug (2). - Make sure that all plugs, ports, and cables are dry. Warning Risk of Injury The intrinsic safety of the battery can only be guar- anteed if the original battery charger is used. SR-E500 OWNER’S MANUAL...
  • Page 164 - Connect the battery charger to the battery. Guideline Observe Plug Marking Insert the plug straight so that the contacts are not bent. - Connect the power plug for the battery charger to the wall outlet. Charging starts automatically. SR-E500 OWNER’S MANUAL...
  • Page 165 - Disconnect the battery charger power plugs from the wall outlet. - Unlock the charging plug lock counterclock- wise and disconnect the charging cable from the battery. Guideline: 1. Counterclockwise unlock charging plug nut with your right hand. 2. Remove the charging plug. SR-E500 OWNER’S MANUAL...
  • Page 166 If the charging socket protection cap is dirty: - Clean the charging socket protection cap with out water or compressed air. If the charging socket protection cap is damaged or worn: - Change the charging socket protection cap. SR-E500 OWNER’S MANUAL...
  • Page 167 (1) for looseness. If controller three-phase cables, power line installation screws (1) are loose. - Tighten the screws (1). Installation bolts 5Nm (3.7 lbf.ft) Info Controller three-phase cables, power lines should be checked every six months. SR-E500 OWNER’S MANUAL...
  • Page 168 COOLING 16 16.1 Cooling The battery (1) and the electric motor (2) are air-cooled. Cooling is effected by air flow from forward motion. The lower the speed, the less cooling effect. SR-E500 OWNER’S MANUAL...
  • Page 169 - Never clean the vehicle and battery with a pressure cleaner or a powerful jet of water. - Do not point a jet of water toward the battery discharge plug, even if the protection cap has been installed. SR-E500 OWNER’S MANUAL...
  • Page 170 Clean the motorcycle regularly to maintain its value and appear- ance over time. Avoid direct sunlight when cleaning the motorcycle. - Remove coarse dirt particles with a gentle water jet. - Spray heavily soiled parts with a normal commercial motorcycle cleaner, working with a soft brush. SR-E500 OWNER’S MANUAL...
  • Page 171 Never apply motorcycle cleaner to the dry motorcycle. Always rinse the motorcycle with water before use. - After rinsing the motorcycle with a gentle spray of water, allow it to dry thoroughly. Warning Danger of Crashes Moisture and dirt impair the brake system. SR-E500 OWNER’S MANUAL...
  • Page 172 - Clean the chain. (p.103) - Treat bare metal (except for brake rotors) with a corrosion inhibitor. - Treat all plastic parts and powder-coated parts with a mild cleaning and care product. SR-E500 OWNER’S MANUAL...
  • Page 173 - Check all motorcycle parts for function. - Clean the motorcycle. (p.169) - Check tire pressure. (p.151) - Charge the battery. (p.160) SR-E500 OWNER’S MANUAL...
  • Page 174 Therefore, during long-term storage of the lithium-ion battery, it should be recharged every 3 to 6 months. SR-E500 OWNER’S MANUAL...
  • Page 175 If the vehicle was placed on a lift stand, the tire and spring elements will be relieved of weight. - Raise the motorcycle with a lift stand. (p.83) - Cover the motorcycle with a tarp or cover that is permeable to air. SR-E500 OWNER’S MANUAL...
  • Page 176 18 STORAGE 18.2 Preparing For Use After Storage - Remove the motorcycle from the lift stand. (p.83) - Charge the battery. (p.160) - Perform checks and maintenance measures when preparing for use. (p.52) - Take a test ride. SR-E500 OWNER’S MANUAL...
  • Page 177 SR-E500 OWNER’S MANUAL...
