  • Page 1 LUMENFLEX Linear LED Strips https://www.orlight.com/linear-led/architectural-linear/lumenflex-family...
  • Page 2 LUMENFLEX SIDE MINI IP65 rated, side emitting mini flexible LED strip, offering a uniform and even light distribution with no LED hotspots. Suitable for both interior and exterior applications. Dual layer injection moulded connections ensure IP65 integrity. Available in a variety of colour temperatures with a light quality assurance of CRI>80. 3-Step MacAdams Ellipse binning strategy for colour consistency.
  • Page 3 LUMENFLEX SIDE IP68 rated, side emitting flexible LED strip, offering a uniform and even light distribution with no LED hotspots.Suitable for both interior and exterior applications. Single layer injection moulded connections ensure IP68 integrity. Available in a variety of colour temperatures with a light quality assurance of CRI>80. 2-Step MacAdams Ellipse binning strategy for colour consistency.
  • Page 4 LUMENFLEX TOP MINI IP65 rated, top emitting mini flexible LED strip offering a uniform and even light distribution with no LED hotspots. Suitable for both interior and exterior applications. Dual layer injection moulded connections ensure IP65 integrity. Available in a variety of colour temperatures with a light quality assurance of CRI>80.
  • Page 5 LUMENFLEX IP65 rated, side emitting mini flexible LED strip, offering a uniform and even light distribution with no LED hotspots. Suitable for both interior and exterior applications. Dual layer injection moulded connections ensure IP65 integrity. Available in a variety of colour temperatures with a light quality assurance of CRI>80. 3-Step MacAdams Ellipse binning strategy for colour consistency.
  • Page 6 LUMENFLEX TOP RGB IP65 rated, side emitting mini flexible LED strip, offering a uniform and even light distribution with no LED hotspots. Suitable for both interior and exterior applications. Dual layer injection moulded connections ensure IP65 integrity. Available in a variety of colour temperatures with a light quality assurance of CRI>80. 3-Step MacAdams Ellipse binning strategy for colour consistency.
  • Page 7 LUMENFLEX TOP SAMBA IP65 rated, side emitting mini flexible LED strip, offering a uniform and even light distribution with no LED hotspots. Suitable for both interior and exterior applications. Dual layer injection moulded connections ensure IP65 integrity. Available in a variety of colour temperatures with a light quality assurance of CRI>80. 3-Step MacAdams Ellipse binning strategy for colour consistency.
  • Page 8: Before Installation

    Precaution Before Installation Before Installation Before Installation Before Installation Before Installation LUMENFLEX Before Installation Installation Temperature Before Installation Precaution Precaution Precaution Precaution Precaution Precaution Precaution Ambient Installation Temperature Installation Temperature 0 ~ 45℃ /32~113℉ Installation Temperature Installation Temperature Installation Temperature...
  • Page 9 Before Installation Before Installation LUMENFLEX Before Installation Before Installation Lighting Test Unpacking Lighting Test Lighting Test 1. Check Working Voltage 1. Check Working Voltage 1. Check Working Voltage Please confirm the light in good condition once received, and pay Please confirm the light in good condition once received, and pay 1.
  • Page 10 Connector Glue on Connector LUMENFLEX ctor based on installation environments. Installation Caution Connector Connector Connector IP67 IP68 Connector Selection Glue on Connector Glue on Connector sed on installation environments. nnector based on installation environments. Please chose the suitable IP rated connector based on installation environments.
  • Page 11 LUMENFLEX Installation Caution Connector Cable Entry Options and Dimensions LF-TOP LF-TOP-SAMBA LF-TOP-RGB...
  • Page 12 LUMENFLEX Installation Caution Connector Cable Entry Options and Dimensions LF-SIDE...
  • Page 13 20mm for silicone regular cable. PVC Injection- PVC Injection- Silicone Injection- Silicone Injection- moulded Connector moulded Connector moulded Connector moulded Connector LUMENFLEX PVC Injection- Silicone Injection- PVC Injection- Silicone Injection- moulded Connector moulded Connector Installation Caution moulded Connector moulded Connector...
  • Page 14: Installation Caution

    Installation Caution Installation Caution Installation Caution Installation Caution LUMENFLEX Installation Caution Cable Cable Cable Cable Cable Anti-wicking Ferrule Anti-wicking Ferrule Anti-wicking Ferrule Anti-wicking Ferrule Anti-wicking Ferrule The anti-wicking ferrule is designed to lower the 1. The removal of anti-wicking ferrule will increase the 1.
  • Page 15: Profile Selection

    2. If any similar demands, please keep the profile clean after processing. 3. For the profile involved the serrated tape, please take its serrated LUMENFLEX tape out to avoid being deformed and useless affected by the high temperature generated, or discuss with the manufacturer to Installation Caution separate the package in advance.
  • Page 16 LUMENFLEX Installation Caution Profile LF-SIDE...
  • Page 17 LUMENFLEX Installation Caution Profile Profile Installation SELF-LOCKING PROFILE INSTALLATION light   Aluminium Profile Installation Surface Screw STANDARD PROFILE INSTALLATION Installation Surface Screw...
  • Page 18 Make su head on the edge is downward head on the edge is downward head on the edge is downward head on the edge LUMENFLEX when putting back. when putting back. when putting back. when putting ba Round Head...
  • Page 19 LUMENFLEX Installation Caution Profile Angular Misalignment Parallel Vertical Misalignment Parallel Horizontal Misalignment Installation Caution Above wrong misalignments will make the light improperly bent, and lead to the wrinkle or fracture on PCB. Light Installation Light Installation 【08】 It's not recommended to install the light repeatedly, otherwise the light inside might be damaged.
  • Page 20 LUMENFLEX ≥ ≥ 1 1 0 0 c c m m Installation Caution Light Uninstallation Light Uninstallation Prepare a screwdriver, and put the screwdriver at the bottom of Move the screwdriver and unclench the light upwardly. Be light.
  • Page 21: Installation

    LUMENFLEX CONTROLLER Installation Wiring Diagram Double-end Feed Note: Wiring Diagram A decoder is unnecessary if the controller or dimmer can control the light directly. In this case, its connection position and way are the same as the above decoder‘s. SPI Pixel Light...
  • Page 22: Wiring Diagram

    LUMENFLEX Installation Wiring Diagram In Series Data Note: A decoder is unnecessary if the controller can control the light directly. In this case, its connection position and way are the same as the above decoder’s. Please make sure the ground wire of controller and the negative wires of light are all connected well to form a current loop and carry out signal transmission.
  • Page 23 Installation 120Ω termination resistor Wiring Diagram Double-end Feed 【12】 Driver Configuration Table LF-MINI BC Code DRIVER (Non-Dim) SPECIFICATION LUMENFLEX LENGTH 15210 ORLRPV2435 LED Driver, DC24V, 35W Up to 7.5M 15214 ORLRPV2460 LED Driver, DC24V, 60W Up to 10M BC Code...
  • Page 24 LUMENFLEX Installation Length Matrix Driver Configuration Table LF-TOP BC Code DRIVER (Non-Dim) SPECIFICATION LUMENFLEX LENGTH 15210 ORLRPV2435 LED Driver, DC24V, 35W Up to 2.5M 15214 ORLRPV2460 LED Driver, DC24V, 60W Up to 5M 15199 ORLRPV24100 LED Driver, DC24V, 100W Up to 8M...
  • Page 25 LF-MINI Length Matrix Length Matrix The LUMENFLEX-MINI can be cut every 83.33mm. The below table gives information on the overall length, obtained by adding the total cable entry length and end mould, to all the available cut lengths up to 10M.
  • Page 26 LUMENFLEX LF-MINI Length Matrix Length Matrix Total Length (mm) Segments Luminaire/ Cutpoints Inline+End Left/Right+End Rear+End 3666.67 3684.67 3670.67 3670.67 3750.00 3768.00 3754.00 3754.00 3833.33 3851.33 3837.33 3837.33 3916.67 3934.67 3920.67 3920.67 4000.00 4018.00 4004.00 4004.00 4083.33 4101.33 4087.33 4087.33 4166.67 4184.67...
  • Page 27 LUMENFLEX LF-MINI Length Matrix Length Matrix Total Length (mm) Segments Luminaire/ Cutpoints Inline+End Left/Right+End Rear+End 7583.33 7601.33 7587.33 7587.33 7666.67 7684.67 7670.67 7670.67 7750.00 7768.00 7754.00 7754.00 7833.33 7851.33 7837.33 7837.33 7916.67 7934.67 7920.67 7920.67 8000.00 8018.00 8004.00 8004.00 8083.33 8101.33...
  • Page 28 LF-TOP Length Matrix Length Matrix The LUMENFLEX-TOP can be cut every 83.33mm. The below table gives information on the overall length, obtained by adding the total cable entry length and end mould, to all the available cut lengths up to 10M.
  • Page 29 LUMENFLEX LF-TOP Length Matrix Length Matrix Total Length (mm) Segments Luminaire/ Cutpoints Inline+End Left/Right+End Rear+End 3750.00 3768.00 3754.00 3754.00 3833.33 3851.33 3837.33 3837.33 3916.67 3934.67 3920.67 3920.67 4000.00 4018.00 4004.00 4004.00 4083.33 4101.33 4087.33 4087.33 4166.67 4184.67 4170.67 4170.67 4250.00 4268.00...
  • Page 30 LUMENFLEX LF-TOP Length Matrix Length Matrix Total Length (mm) Segments Luminaire/ Cutpoints Inline+End Left/Right+End Rear+End 7750.00 7768.00 7754.00 7754.00 7833.33 7851.33 7837.33 7837.33 7916.67 7934.67 7920.67 7920.67 8000.00 8018.00 8004.00 8004.00 8083.33 8101.33 8087.33 8087.33 8166.67 8184.67 8170.67 8170.67 8250.00 8268.00...
  • Page 31 LF-SIDE Length Matrix Length Matrix The LUMENFLEX-SIDE can be cut every 55.56mm. The below table gives information on the overall length, obtained by adding the total cable entry length and end mould, to all the available cut lengths up to 10M.
  • Page 32 LUMENFLEX LF-SIDE Length Matrix Length Matrix Total Length (mm) Segments Luminaire/ Cutpoints Inline+End Left/Right+End Rear+End 2500.00 2518.00 2504.00 2504.00 2555.56 2573.56 2559.56 2559.56 2611.11 2629.11 2615.11 2615.11 2666.67 2684.67 2670.67 2670.67 2722.22 2740.22 2726.22 2726.22 2777.78 2795.78 2781.78 2781.78 2833.33 2851.33...
  • Page 33 LUMENFLEX LF-SIDE Length Matrix Length Matrix Total Length (mm) Segments Luminaire/ Cutpoints Inline+End Left/Right+End Rear+End 5166.67 5184.67 5170.67 5170.67 5222.22 5240.22 5226.22 5226.22 5277.78 5295.78 5281.78 5281.78 5333.33 5351.33 5337.33 5337.33 5388.89 5406.89 5392.89 5392.89 5444.44 5462.44 5448.44 5448.44 5500.00 5518.00...
  • Page 34 LUMENFLEX LF-SIDE Length Matrix Length Matrix Total Length (mm) Segments Luminaire/ Cutpoints Inline+End Left/Right+End Rear+End 7833.33 7851.33 7837.33 7837.33 7888.89 7906.89 7892.89 7892.89 7944.44 7962.44 7948.44 7948.44 8000.00 8018.00 8004.00 8004.00 8055.56 8073.56 8059.56 8059.56 8111.11 8129.11 8115.11 8115.11 8166.67 8184.67...
  • Page 35 Accessories: Please ensure that any accessory used in conjunction with these products is approved by Orlight. Failure to do so will void any product guarantee. Orlight will not be held responsible for any loss incurred be it direct or consequential.
