Orlight IP65 DOWNLIGHT STEAMSPOT Installation Instructions

INSTALLATION -

Orlight does not recommend the cutting of holes prior to receipt of product in hand.
Please see reverse for full instructions.
Allow +5mm for Cable Clearance
72mm

LAMP MAINTENANCE -

removed from below. This requires care in order not to damage the ceiling. Use a large flat blade tool to lever
down one side of the fitting, place a small batten or pencil to hold the bezel away from the ceiling.
Then use the flat bladed tool to lever the other side of the fitting down. Taking care, to avoid damaging the
ceiling. Evenly pull the whole fitting away from the ceiling, this may require some force to bend the springs fully
back. Be careful to avoid the spring folding back and pinching your fingers.
Flat tool - One Side
Please note: The above standards are dependent on the fixture option selected from the range.
PLEASE OBSERVE MAXIMUM WATTAGES AS STATED ON FIXTURES.
Compatible Orlight dimmable lamps (may require mains converter) :
5W CR-5
Installation instructions
IP65 DOWNLIGHT
STEAMSPOT
36mm
72mm 4mm
If the lamp is not readily accessible from above, the fitting has to be completely
Insert Batton/Pencil
7W LUMENSTAR 7W MTG2PLUS
www.orlight.com | 01923 851 890
6W
R9-99-3
56mm
Flat tool - Opposite Side
100
DIMMABLE
3
%
7W MTG2
CIRCULAR
CUT OUT : 68MM
13W
R9-99-1
94mm
8W
R9-99-2
66mm
Pull Through
IP65
R9-99
