Orlight EXIT-LUME-SUS Datasheet

EXIT-LUME-SUS
ITEM NO. 34754
Features
• For LED module with a forward voltage of 12-14Vdc/9-
12Vdc
• Complete set with integrated electronics, LED module,
housing, and battery
• Plug-in Lithium Iron Phosphate battery
• SELV for output voltage
• Very low stand-by power loss
• Polycarbonate white RAL 9016
• 850°C Glow-wiring
Technical Specification
Rated supply voltage
AC voltage range
Mains frequency
Power factor
Starting time
Ambient temperature ta
IP rating
In-rush current
In-rush current duration
Mains surge capability (between L – N)
Emergency Lumens
Colour Temperature
FROM SOURCE TO SITE
Functions
• Maintained and non-maintained mode
• Standard function and self-test function
• Self testing products can switch the self testing,standard
function through the dial switch
Dimension
220 - 240 V
140-180VAC
50/60Hz
≥0.5
0.5S
5-45°C
IP20
1.5A
1ms
1KV
60LM
6000K
W - www.orlight.com T - 01923 851 890 E - info@orlight.com
