- Page 1 Operation and Maintenance Manual GASMAX CS Wireless Gas Monitor GDS Corp. 1245 Butler Road League City, TX 77573 409-927-2980 409-927-4180 (Fax) ww.gdscorp.com...
- Page 2 ENTRETENU ET RÉPARÉ UNIQUEMENT PAR UN PERSONNEL QUALIFIÉ. ÉTUDIER LE MANUE D’INSTRUCTIONS EN ENTIER AVANT D’UTILISER, D’ENTRETENIR OU DE RÉPARER L’ÉQUIPEMENT. REVISION HISTORY Revision 1.0 8//22/21 Initial Release Copyright © 2022 GDS Corp. All Rights Reserved P/N 1200-1109-01 Page 3...
-
Page 3: Table Of Contents
GASMAX CS User’s Manual, Revision 1.0 CONTENTS SAFETY INFORMATION _______________________________________________ 6 OVERVIEW _________________________________________________________ 7 INSTALLATION ______________________________________________________ 8 PROGRAMMING & SETUP ____________________________________________ 11 CALIBRATION ______________________________________________________ 15 MAINTENANCE _____________________________________________________ 18 TROUBLESHOOTING GUIDE ___________________________________________ 20 SPECIFICATIONS ____________________________________________________ 21 DRAWINGS AND DIMENSIONS ________________________________________ 22... - Page 4 GASMAX CS User’s Manual, Revision 1.0 TABLE OF FIGURES FIGURE 3-1: GASMAX CS MECHANICAL ASSEMBLY ..................10 FIGURE 3-2: GASMAX CS ELECTRONICS ASSEMBLY ..................10 FIGURE 4-1: GASMAX CS USER INTERFACE....................11 FIGURE 9-1: GASMAX CS DIMENSIONS ......................22 Page 5...
-
Page 5: Safety Information
Users should have a detailed understanding of GASMAX CS operating and maintenance instructions. Use the GASMAX CS only as specified in this manual or detection of gases and the resulting protection provided may be impaired. Read the following WARNINGS prior to use. -
Page 6: Overview
The GDS Corp GASMAX CS Non-Explosion-Proof Ambient Air Toxic Gas Detector is designed to detect a wide range of toxic gases in many environments. The GASMAX CS features non- intrusive magnetic switches that allow for complete system configuration, regular calibration, and product maintenance to be performed in the field, without opening the enclosure and breaking the seal of the enclosure. -
Page 7: Installation
GASMAX CS gas monitor or gas sensor. Even though the GASMAX CS is designed for rugged service, sensors and electronics should be protected from environmental damage due to water, snow, shock, vibration, and dirt. In addition, the sensor and / or display should be located such that regular maintenance and periodic sensor replacement can be readily accomplished. - Page 8 NOTE: THE GASMAX CS IS NOT DESIGNED FOR USE IN HAZARDOUS AREAS NOTE: These guidelines are ONLY intended as a general directive for the placement of the GASMAX CS. This information should NOT serve as a complete list when considering all potential parameters for the proper location of the unit.
-
Page 9: Figure 3-1: Gasmax Cs Mechanical Assembly
GASMAX CS User’s Manual, Revision 1.0 Figure 3-1: GASMAX CS Mechanical Assembly 1. Batteries 2. Battery plugs 3. Sensor housing connector 4. Sensor housing plug 5. Radio module 6. Internal flexible antenna 7. Battery plug connectors Figure 3-2: GASMAX CS Electronics Assembly... -
Page 10: Programming & Setup
GASMAX CS User’s Manual, Revision 1.0 4 PROGRAMMING & SETUP USER INTERFACE Once the batteries are installed, press the ADD button once to power-up the unit and start the 3 ½ minute warmup period. To turn the unit OFF, press and HOLD the SUB button for approximately six (6) seconds. - Page 11 During normal operation, the display shows the current measured and calibrated gas value, the gas engineering units (“ppm” or “%LEL”) and the type of sensor attached. During normal operating mode, the GASMAX CS continuously samples the air and updates the measured concentration of the target gas on the display screen.
- Page 12 GASMAX CS User’s Manual, Revision 1.0 2. Press ADD or SUB until the Network ID matches the value being used at the System Controller Press MENU to advance to next setting 3. The system information screen allows the user to view...
- Page 13 GASMAX CS User’s Manual, Revision 1.0 8. Press ADD or SUB to adjust the screen contrast setting. The adjust is from 1 to 64 Press MENU to advance to the next setting 9. Press the ADD button to select “Yes” to return the device to its factory default settings and to advance to the return to factory default settings confirmation screen.
-
Page 14: Calibration
Calibration is the process of evaluating and adjusting the precision and accuracy of measurement equipment. Although GDS Corp tests and calibrates every device at the factory, for best accuracy, the GASMAX CS SHOULD be initially calibrated in the environment where it is installed. - Page 15 GASMAX CS User’s Manual, Revision 1.0 3. The unit will automatically begin the 12-second null process. During null, the display will show a countdown of the time remaining until the process is complete. When the null process is complete, press the MENU button to advance to the next screen.
- Page 16 Press the MENU button to continue. Press the MENU button to start the automatic calibration process. 11. The GASMAX CS will automatically begin the 120- second calibration process. During calibration, the display will show a countdown of the time remaining until the process is complete.
-
Page 17: Maintenance
SENSOR REPLACEMENT The sensor elements used in the GASMAX CS detects gas in either % or PPM concentrations; this element must be fully functional for the system to operate correctly. GDS Corp recommends replacing the sensing element whenever a slow response to gas is observed during the normal calibration process. - Page 18 Press the ADD button to power-up the GASMAX CS BATTERY REPLACEMENT The GASMAX CS battery life will vary based on the sensor type and the presence of gas that will increase the radio transmission rate (and decrease this battery life) It is recommended that the batteries be replaced when the voltage reported is 3.2 volts or less.
-
Page 19: Troubleshooting Guide
GASMAX CS User’s Manual, Revision 1.0 7 TROUBLESHOOTING GUIDE DEVICE APPEARS INOPERATIVE • Batteries dead. Replace batteries. • Electronics damaged. Replace electronics. FAULT SHOWING “F4” • The control board has lost communications with the sensor element or sensor interface board. (Replace sensor interface board) FAULT SHOWING “F5”... -
Page 20: Specifications
GASMAX CS User’s Manual, Revision 1.0 8 SPECIFICATIONS 3.6 VDC 19Ah each, 38 Ah total Lithium-Thionyl (Li-SOCl2) Battery Power Electrochemical Sensor - 2 Years Maximum Estimated Battery Photo Ionization Detector Sensor – 14 Days + Life Dynament Lower Power IR – 2.5 - 3 Months -20⁰C to +54⁰C (operating) -
Page 21: Drawings And Dimensions
GASMAX CS User’s Manual, Revision 1.0 DRAWINGS AND DIMENSIONS 5.12” 6.5” 4.45” 4.45” Figure 9-1: GASMAX CS Dimensions Page 22... - Page 22 GASMAX CS User’s Manual, Revision 1.0 Page 23...
