Remote Microphone Connection
Procedures for the Kanso –
Roger Touchscreen as Transmitter
1. Pair the MM2+ to the Kanso. (Pairing only needs to be done once, unless MM2+ has been paired to
another processor)
a. Turn off the Kanso by pressing and holding the button for five seconds
until the indicator light turns a steady orange, then release the button.
b. Turn on the MM2+ by pressing the ON/OFF button until the LED turns
green, then release the button.
c. With the tip of a ballpoint pen, press the pairing button
once. The LED will flash yellow. Within 20 seconds, turn on the Kanso by pressing and holding
the button until the LED turns green, then release the button.
d. The LED on the Kanso will blink blue, which indicates pairing is successful.
2. Connect the Roger X receiver to the Roger Touchscreen transmitter. (Connecting only needs to be done
once unless the Roger X has been connected to another transmitter)
a. Turn ON the Roger Touchscreen by pressing the side off and on button.
b. Turn ON the MM2+.
c. Insert the Roger X into the FM connector of the MM2+.
Pairing button
Page 1 of 3
Advertisement
Table of Contents
Related Manuals for Cochlear MM2+
Summary of Contents for Cochlear MM2+
- Page 1 Remote Microphone Connection Procedures for the Kanso – Roger Touchscreen as Transmitter 1. Pair the MM2+ to the Kanso. (Pairing only needs to be done once, unless MM2+ has been paired to another processor) a. Turn off the Kanso by pressing and holding the button for five seconds until the indicator light turns a steady orange, then release the button.
- Page 2 d. While holding the powered-up Roger X within one inch of the Roger Touchscreen, press "Connect" on the home screen. e. If the operation is successful, the message “Roger X is connected” will appear on the screen of the Touchscreen. Daily Classroom Routine Before instruction begins: 1.
- Page 3 6. Remote microphone connection is now established. Conduct Functional Check. Functional check From a distance of at least 3 metres, cover your lips and speak to the student via the Roger Touchscreen. Ask the student to do things like “point to the windows”...
- Page 4 During small group work (up to 5-6 people around a table): 1. Activate the built-in mic on the Touchscreen by placing it flat at the center of the table. 2. To resume instruction, simply pick up the Touchscreen and wear it as normal. During listening to personal audio (i.e.
