- Page 1 Instruction Installing the coin box WE170PP, WE170VP Read the instruction in full before starting work. If anything is unclear or incorrect, please contact your local sales office or service representative. 438907644/EN 2022.01.12...
- Page 3 Instruction 1 Instruction for installing the coin box to WE170PP and WE170VP Demount the rear cover on the coin box. fig.X00174 The connection cable is at delivery inside of the coin box. Note! The connection cable is 3 m. Take this into consideration when positioning the coin box.
- Page 4 Instruction Fasten the cable with the counter nut and cable gland at the bottom of the coin box. There are two holes prepared, select one of them. The other counter nut and cable gland shall be mounted to the machine. fig.X00176 Level the coin box by adjusting the feet (A).
- Page 5 Instruction Disconnect the power to the machine. Demount the top panel. fig.X00169 Locate one of the holes that is prepared for the cable to the coin box on the back of the machine. (One hole is used for the coin box and one hole is used for connection of external payment system). Drill a 20–21 ⌀...
- Page 6 Instruction Remove the screw and demount the lid to the “satelite board”. fig.X00172 Connect the cable to connection J29. The connection on the cable is marked with J29. fig.X00170A...
- Page 7 Instruction The cable shall be led out on the right side of the “satelite board”. fig.X00173A Note! All jumpers on J30 and J31 must be removed. fig.X00171A Strap the cable at suitable positions. The cable must not be in contact with any moving parts. Remount the lid to the “satelite board”.
-
Page 8: Programming The Machine
Instruction 1.1 Programming the machine When the coin box has been installed; connect the power to the machine and switch on the machine. Remove the drawer on the front of the coin box. fig.X00196 Press the price programming button that is located on the right behind where the drawer was. fig.X00197 When the button has been pressed the display on the machine switches to the following view: fig.X00184... - Page 9 Instruction Select if the price shall be displayed with a decimal or not. Press the first button to the left to select or deselect the decimal. Save your selection by pressing the start/paus button to the right. The next menu is automatically displayed when saving through the complete programming. fig.X00185 Set the value of coin 1 (C1).
- Page 10 Instruction Set the value of coin 2 (C2). Decrease the value with the first button to the left and increase the value with the second button to the left. Note! The value must be over zero if tokens are to be accepted. Save the value by pressing the start/paus button.
- Page 11 Instruction When the last program has been programmed and saved the display switches to the following view: fig.X00189 Note! The menu will go back to normal status if the programming is inactive for 15 seconds. You can also go back to normal status by pressing any other button or if the machine is switched off and on again.
- Page 12 Instruction The microswitches (C) are located at the left side of the coin meter. fig.X00199 Program the coin meter by setting the microswitches according to the following table. Note! Set the microswitches to the currencies that ARE to be used in lower position (D). The microswitches to the currencies that are NOT to be used shall be set to ON (upper position = E).
- Page 13 Instruction Coin meter Currency Individual coins The whole currency Microswith position Microswith position 0,10 EUR 0,20 EUR 0,50 EUR 1 EUR 2 EUR 1GBP 2017 0,1GBP 438894201 0,2GBP 0,5GBP 1GBP 2GBP 0,1GBP 2010 Token WA 4 TK16 50 JPY 100JPY 500 JPY new Token WA 4 TK16...
- Page 14 Instruction 0,50 EUR 1,00 EUR 2,00 EUR 5,00 SEK 2016 10,00 SEK 5,00 DKK 438894205 10,00 DKK 5,00 NOK 10,00 NOK 50,00 ISK 100,00 ISK Token WA 4 TK16 1 PLN 2 PLN 5 PLN 1 HRK 2 HRK 5 HRK 100 HUF 438894206 200 HUF...
- Page 16 Electrolux Professional AB 341 80 Ljungby, Sweden www.electroluxprofessional.com...
