Emlid Reach RS3 Quick Start Manual

Configuring 12d field
Hide thumbs Also See for Reach RS3:
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
Configuring 12d Field and Emlid Reach RS3
12d Field now supports connecting to an Emlid Reach RS3 with tilt corrections.
The following steps are required to get it working.
1. Configure Emlid Reach RS3 using Emlid Flow to stream NMEA
2. Connect the receiver to Windows PC over Bluetooth
3. Configure 12d Field to talk to the Emlid receiver
4. Configure 12d Field to use tilt corrections
5. Check
This guide is based on the following software and firmware versions:
● Emlid Reach Firmware version 32
● Emlid Flow App version 10.9
● 12d Field version 15 C1p
Configure 12d Field with Emlid Reach RS3
Issue Date: 24 July 2024
Page 1 of 7

Advertisement

loading
Need help?

Need help?

Do you have a question about the Reach RS3 and is the answer not in the manual?

Questions and answers

Related Manuals for Emlid Reach RS3

Summary of Contents for Emlid Reach RS3

  • Page 1 Configuring 12d Field and Emlid Reach RS3 12d Field now supports connecting to an Emlid Reach RS3 with tilt corrections. The following steps are required to get it working. 1. Configure Emlid Reach RS3 using Emlid Flow to stream NMEA 2.
  • Page 2 For the best performance, 12d software benefits from position streaming rates using NMEA to be at least 5Hz - preferably 10Hz. In order to output at 10Hz, the GNSS update rate needs to be 10Hz. Step 1 - Open Emlid Flow, connect to the receiver Go to Settings > GNSS settings Set the GNSS update rate to 10Hz Configure 12d Field with Emlid Reach RS3...
  • Page 3 ● GSA and GSV set to 0.5Hz ● RMC, VTG, ZDA and EMP turned off. Step 3 - Enable Reach RS3 to be found as a Bluetooth device by the Windows tablet Go to Settings > Bluetooth > Discoverability > On Configure 12d Field with Emlid Reach RS3...
  • Page 4 Step 4 - Add a new bluetooth device on Windows 10 in the Bluetooth & other devices menu Select the Reach device from the list to pair it to your computer. Configure 12d Field with Emlid Reach RS3 Issue Date: 24 July 2024...
  • Page 5 Configure 12d Field to talk to the Emlid receiver Step 5 - Install 12d Field 15 C1p or later, which has the Emlid driver built in. https://downloads.12dmodel.com/V15/12d_Model_15_C1p/12d_Model_15_C1p_64_Setup.exe Step 6 - Configure N values and Projection Using the following guide - ensure you select the correct zone with the projection you are using https://12dwiki.com.au/12df-using-a-gsb-for-n_values-instead-of-winter-files-and-tdf_hel/...
  • Page 6 Green confirms the setup is working correctly. Step 8 - Use tilt corrections Press the button to configure tilt. From the Tilt dropdown select Use tilt corrections. Configure 12d Field with Emlid Reach RS3 Issue Date: 24 July 2024 Page 6 of 7...
  • Page 7 Check, check and check again Now you are receiving NMEA strings from Emlid Flow and you should be able to get a FIX solution in 12d Field. We need to confirm if the Phase Centre Offset and Geoid-Ellipsoid separation values are being applied properly, and if the tilt is working.
