Emlid REACH RS3 User Manual

Multi-band imu rtk gnss receiver
Hide thumbs Also See for REACH RS3:

Advertisement

Table of Contents

REACH RS3
Multi-band IMU
RTK GNSS receiver
User guide
Version: 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REACH RS3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emlid REACH RS3

Summary of Contents for Emlid REACH RS3

  • Page 1 REACH RS3 Multi-band IMU RTK GNSS receiver User guide Version: 1.0...
  • Page 2 Introduction Reach RS3 is a multi-band RTK GNSS receiver with a built-in LTE modem and tilt compensation, designed for surveying, mapping, and navigation. The receiver delivers centimeter precision, streams its real-time position in the NMEA format, and records raw data in the industry-standard RINEX format.
  • Page 3 Package contents 1. Reach RS3 2. LoRa antenna 3. USB Type-C cable 4. User guide 5. Carrying bag 6. Shoulder strap...
  • Page 5 Overview 1. Front panel 2. Extension port 3. Nano-SIM port 4. Ventilation holes 5. Thread mount 6. USB Type-C port 7. Antenna port...
  • Page 7 LED status 1. Battery LEDs 2. Power LED The LEDs indicate The LED indicates the loading state the on-state and point and battery charge. collection mode. Running white Solid white Loading Solid white Blinking white Ready for use Point collection mode Charge level Blinking white Charging...
  • Page 9 LED status 3. Wi-Fi LED 4. RTK LED The LED indicates The LED indicates the network RTK status and the connection and its correction output state. state. Solid white Switching between Broadcasting Wi-Fi white and blue every 2 seconds Solid blue Correction Connected to Wi-Fi output is on...

  • Page 11: Antenna Attachment

    To attach the antenna, lift the silicone flap on the LoRa connector and carefully screw in the antenna. Note: Use only an external antenna that is designed to be used with Reach RS3. Caution: Antennas are excellent conductors of electricity, so use extreme caution when...
  • Page 13 SIM card insertion To insert a SIM card, follow the steps below: Caution: To prevent slot damage, use it with care. 1. Slide the metallic cover to the right to unlock the slot. 2. Pull the cover up to open the SIM card slot. 3.
  • Page 15 Installation introduction If this is your first time using Reach RS3, following these guides will help you to complete initial setup of your Reach. 1.install the RS3 device 1.1 Insert the SIM card into the card slot; Shown in SIM card insertion Page 1.2 Insert antenna to the polt;...

  • Page 16: Operation

    USB PD 5 V 3 A compliant adapters. Powering on/off To turn on or off Reach RS3, press and hold the power button for 3 seconds. Hard reset To hard reset Reach RS3, follow the steps below: 1.

  • Page 17: First Setup

    First setup Get started with your Reach RS3 in just three steps: 1. Download the Emlid Flow app. GooglePlay AppStore 2. Connect to Reach RS3 over Wi-Fi. reach:xx:xx emlidreach 3. Launch Emlid Flow on your device. To explore the Reach RS3 guides, tutorials, and videos, scan the QR-code: https://emlid.com/docs/...

  • Page 18: Specification

    Specification Positioning Precision Static H: 4 mm + 0.5 ppm V: 8 mm + 1 ppm H: 5 mm + 0.5 ppm V: 10 mm + 1 ppm H: 7 mm + 1 ppm V: 14 mm + 1 ppm Convergence time ~5 s typically Signal tracked...
  • Page 19 Connectivity 868MHz(Europe) Frequency LoRa radio 915MHz(North America) Power 0.1 W Distance Up to 8 km LTE modem Regions Global Bands FDD-LTE: 1, 2, 3, 4, 5, 7, 8, 12, 13, 18, 19, 20, 26, 28, 66 TD-LTE: 38, 40, 41 UMTS (WCDMA/FDD): 1, 3, 2, 4, 5, 6,...
  • Page 20 Bluetooth 4.0/2.1 EDR Ports RS-232, USB Type-C Data protocols Corrections NTRIP, RTCM3 Position NMEA, LLH/XYZ output Data logging RINEX Internal storage 16 GB Mechanical Dimensions 126 x 126 x 142 mm Weight 950 g +5...+45 Temperature °C...
  • Page 21 Electrical 16 hrs as LTE RTK rover, Autonomy 22 hrs of logging Li-Ion 5200 mAh, Battery 7.2 V, 37.44 Wh Charging USB Type-C 5 V 2 A FCC, CE Certification...

  • Page 22: Safety Instructions

    Safety instructions To ensure the safe operation of your Reach RS3, observe the following safety instructions: Caution: Failure to comply with safety instructions can lead to malfunction or damage to the receiver. Never disassemble or modify the receiver. • Keep the receiver free from mechanical stress, •...
  • Page 23 Observe safety precautions when using • the receiver in dangerous places. Do not obstruct the ventilation holes of the • receiver. Do not let foreign objects into the receiver. • Do not let insecticides, benzene, and thinner • come in contact with the receiver. Handle cables carefully.
  • Page 24 Use and care Although Reach RS3 is designed to withstand challenging environments, it is necessary to handle it with care, follow safety instructions, and comply with the operating limits given in the specification. Caution: Do not open the receiver, it leads to the loss of warranty.
  • Page 25 Cleaning To clean Reach RS3 from dirt, follow the steps below: 1. Rinse the receiver with fresh water. 2. Dry the receiver with a soft cloth. Caution: Do not use heat sources such as air dryers or ovens to dry the device. It may damage the receiver.
  • Page 26 Transportation To protect your Reach RS3 from damage, transport it according to the following instructions: Transportation in the field Carry the receiver and its accessories in the carrying bag or carry it attached to the tripod upright. Road transportation Transport the receiver and its accessories in the carrying bag and properly secure it in a road vehicle.

  • Page 27: Regulatory Information

    Regulatory information Certification United States of America Federal Communications Commission (FCC) Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 28 there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna.
  • Page 29 European Union CE Declaration of Conformity This device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.

  • Page 30: Recycling And Disposal

    Recycling and disposal The product's packaging is recyclable and can be reused. The recycling and disposal of the receiver and its components may vary in accordance with applicable local rules and regulations. For countries in European Union (EU) This product and the supplied accessories, excluding the batteries, constitute the applicable product according to the WEEE directive.
  • Page 32 If you need more information on your Reach RS3 or technical support, scan the QR code: https://emlid.com/support/ emlid.com...
