3G/HD/SD/CVBS Channel Integrator
– UDX / Frame Sync with Video Optimization, Advanced Audio DSP
9902-UDX-DSP-CI
9902-UDX-DSP-CI
Features, and SFP I/O Options
Product Manual
Cobalt Digital Inc.
2506 Galen Drive
Champaign, IL 61821
Voice 217.344.1243 • Fax 217.344.1245
www.cobaltdigital.com
9902-UDX-DSP-CI-OM (V1.0)
