POWER COMMANDER 6
Installation Guide for: PC6-11007
Model Coverage: 2005-2011 Arctic Cat 500, 600,
and 700 EFI Snowmobiles
PARTS LIST
1
POWER COMMANDER 6
1
INSTALLATION GUIDE
1
USB CABLE
2
DYNOJET DECALS
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION.
THE IGNITION MUST BE TURNED OFF BEFORE INSTALLATION.
2
POWER COMMANDER DECALS
2
VELCRO STRIPS
1
ALCOHOL SWAB
IPC6-11007.01
Advertisement
Related Manuals for Dynojet POWER COMMANDER 6
Summary of Contents for Dynojet POWER COMMANDER 6
- Page 1 POWER COMMANDER 6 Installation Guide for: PC6-11007 Model Coverage: 2005-2011 Arctic Cat 500, 600, and 700 EFI Snowmobiles PARTS LIST POWER COMMANDER 6 POWER COMMANDER DECALS INSTALLATION GUIDE VELCRO STRIPS USB CABLE ALCOHOL SWAB DYNOJET DECALS PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION.
-
Page 2: Wire Connections
Shifter (Input 1 or 2) Used for clutch-less full throttle upshifts. Insert the wires from the Dynojet quick shifter into either Input 1 or Input 2. The polarity of the wires is not important. Set to Input 2 by default. - Page 3 INSTALLING THE POWER COMMANDER 6 Locate the engine control unit (ECU) under the hood. Unplug the ECU connector on the MAG side. Attach the PC6 connectors to the ECU and the factory wiring harness. Warning: Verify you have the correct part number PC6 for your model snowmobile.
- Page 4 Optional Connections: Temperature Input - Using a t-tap or posi-tap, secure a 22-24 gauge wire to pin 19 on the power commander ECU connector. The pin numbers are located on the back side of the ECU connector. Connect this wire to the Analog input on the power commander.
- Page 5 2191 MENDENHALL DRIVE, NORTH LAS VEGAS, NV 89081 - 800-992-4993 - DYNOJET.COM © 2005-2022 DYNOJET RESEARCH ALL RIGHTS RESERVED...
