POWER VISION
Installation Guide for:
PV3-1605C / PV3-1615C / PV3-1622C
PV3-1616C / PV3-1617C
Model Coverage:
2016-2017 Honda CRF1000L Africa Twin
2014-2018 Honda CB500 / CBR500
2013-2022 Honda CBR600RR
2014-2022 Honda CB650 / CBR650
PARTS LIST
1
POWER VISION
1
REFLASH HARNESS
1
USB CABLE
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
2
VELCRO
2
DYNOJET DECAL
1
E.O FRAME LABEL
98200132.12
Advertisement
Table of Contents
Related Manuals for Dynojet POWER VISION PV3-1622C
Summary of Contents for Dynojet POWER VISION PV3-1622C
- Page 1 2016-2017 Honda CRF1000L Africa Twin 2014-2018 Honda CB500 / CBR500 2013-2022 Honda CBR600RR 2014-2022 Honda CB650 / CBR650 PARTS LIST POWER VISION VELCRO REFLASH HARNESS DYNOJET DECAL USB CABLE E.O FRAME LABEL PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION 98200132.12...
- Page 2 INTRODUCTION Thank you for purchasing the Power Vision from Dynojet RETURN Research. At Dynojet, our mission is to make every ride the ultimate ride. The Power Vision allows you to tune SCROLL your stock ECU to achieve optimal performance from ENTER your vehicle.
-
Page 3: Getting Started
PV3 will only display files which directly fit your vehicle. Note: The Dynojet tune file (.djt) is a tune file which is different (better than stock performance or the necessary file when bolting on an exhaust, for example); the stock file (.stk) is the direct duplicate of what the OEM shipped. - Page 4 VIEWING THE VEHICLE INFORMATION This menu allows you to view the device status (paired/not VEHICLE TOOLS paired), VIN #, Model ID, ECU serial number, tune compat, and VEHICLE INFORMATION checksum compat. DIAGNOSTICS Select Vehicle Tools>Vehicle Information. DELETE DATA LOGS VIEWING THE DIAGNOSTIC CODES This menu allows you to read and clear diagnostic trouble VEHICLE TOOLS codes.
-
Page 5: Logging Data
DELETE DATA LOGS RESTORE ECU VIEWING THE DEVICE INFORMATION This menu allows you to view the device firmware version, DEVICE INFORMATION serial number, and stock code. DYNOJET POWER VISION FW VERSION: 5.16.8297.41698 Select Device Tools>Device Information. SERIAL NUMBER: PV00029757 STOCK CODE: 76125082... -
Page 6: Reformatting The Disk
This will turn on diagnostic logging. Logging will continue until DIAGNOSTIC ENABLE the device is restarted. If requested by Dynojet Tech Support, connect your Power Vision to a computer and email the diagnostic file to PV3tech@dynojet.com. Diagnostic log files are placed in the log files directory. -
Page 7: Usb Mode
Click Update to load the current firmware. If the Update button is grayed out, your Power Vision already has the latest firmware. Click Restore to reload all original Dynojet tune and stock files. Click Get Tunes to open the Dynojet Tune Finder. Follow the instructions to Upload your PV_Info.txt file and retrieve new tunes.
