- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS WT60CCB - FREESTANDING COOKER Please read before attempting to install or use this appliance. It is recommended that you keep this user manual in a safe place.
- Page 2 WELCOME Thank you for choosing Willow for your new appliance. Your item is pre-registered and your warranty starts from the point of purchase: all you need to do is keep hold of your proof of purchase. We are proud to provide a range of appliances that have been designed with the consumer in mind.
- Page 3 Contents Safety information Product support Product Disposal Getting to know your Product Support Freestanding Cooker Warranty Installing your Freestanding Cooker Using your Freestanding Cooker Care and Maintenance Energy fiche Circuit Diagram...
- Page 4 Safety information Important - Please read these instructions fully before installing or operating INSTALLATION WARNINGS DURING USAGE IMPORTANT: Prior to Installation ensure that IMPORTANT: This appliance can be used by the local supply conditions (electricity voltage children aged from 8 years and above and and frequency) are compatible with the persons with reduced physical, sensory or requirements of your freestanding cooker.
- Page 5 Safety information Important - Please read these instructions fully before installing or operating WARNING: Before obtaining access to IMPORTANT: When the door of the oven is terminals, all supply circuits must be open, do not hang or lean anything on it. You may unbalance your appliance or damage disconnected.
- Page 6 Getting to know your Freestanding Cooker You’ll be up and running in no time Ready? Let’s begin... Please read these instructions carefully. They contain important information which will help you get the best from your freestanding cooker and ensure safe and correct installation and operation.
- Page 7 Getting to know your 1. Hob 2. Cooking zone 3. Control Panel 4. Shelf positions Wire Shelf Oven Door Shelf positions Baking tray Oven Door 10. Hinge 11. Wire Shelf 12. Door lock 13. Anti slip feet...
- Page 8 Getting to know your Freestanding Cooker Accessories Baking tray x 1 Grill insert x 1 Chrome shelves x 3 Grill pan handle x 1...
- Page 9 Bringing it all together THIS COOKER MUST BE INSTALLED BY A a gi an n a ing an in a i n i i n QUALIFIED INSTALLER IN ACCORDANCE WITH i ina LOCAL REGULATIONS Unpacking IMPORTANT: CONTACT AN AUTHORISED Carefully unpack and examine the appliance for any SERVICE AGENT FOR INSTALLATION OF YOUR damage.
- Page 10 Installing your Levelling feet CAUTION Safety chain RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION CAUTION:...
- Page 11 Installing your Freestanding Cooker Bringing it all together Electrical connection IMPORTANT: Electrical connections must be carried out by a suitably qualified person and in accordance with all relevant local building and installation regulations. Fitting on a Power Supply Cable Connecting appropriate power supply terminal board/ connector block: •...
- Page 12 Using your Control panel Top Oven Lower Oven Grill Function Temperature Control Knob Temperature/Function Control Knob Ceramic Hob Control Knob...
- Page 13 Using your Freestanding Cooker Getting the most from your appliance Oven functions Defrost mode Grill -The top central heating elements comes on .The extremely high and direct temperature of the grill makes it possible to brown the surface of meats and roasts while locking the juices in to keep them tender. The grill is also highly recommended for dishes that require a high temperature on the surface: beef steaks, veal, rib steak, fillets, hamburgers etc.
- Page 14 Using your Freestanding Cooker Getting the most from your appliance General oven and cooking tips General Oven Tips The wire shelves should always be pushed firmly to the back of the oven. Baking trays with food cooking on them should be placed level with the front edge of the oven’s wire shelves.
- Page 15 Using your Freestanding Cooker Getting the most from your appliance Practical Cooking Advice The oven offers a wide range of alternatives which allow you to cook any type of food in the best possible way. With time you will learn to make the best use of this versatile cooking appliance and the following directions are only a guideline which may be varied according to your own personal experience.
- Page 16 Using your Freestanding Cooker Getting the most from your appliance Using the ceramic cooking zones of your cooker Do not use mats, heat diffusers or wok stands. These will cause a temperature build-up which can damage the hob. Do not let cooking pots over spill, this could leave a mark and residue on the glass.
- Page 17 Care and maintenance Looking after your appliance Cleaning WARNING! Isolate the power supply to the appliance and make sure that the cooker is cool. Before cleaning your cooker or performing maintenance, make sure that the cooking mode selection knob and the cooking temperature selection knob is set to ‘OFF’.
- Page 18 Care and maintenance Replacing the oven lamps Disconnect the oven from the power supply at the fuse-box by means of the switch used to connect the appliance to the electrical mains ;or unplug the appliance. Remove the glass cover of the lamp-holder by rotating anti-clockwise.
- Page 19 Model WT60CCB Voltage and frequency 220-240V AC 50-60Hz Upper oven power consumption 1210-1440W Lower oven power consumption 1710-2030W Total oven power consumption 2920-3470W Upper oven usable capacity Lower oven usable capacity Power consumption for large zones (1660-1960W)x1 (1100-1307W)x3 Power consumption for small zones...
- Page 20 Energy fiche Brand Model WT60CCB Type of Oven ELECTRIC Mass 46 (+/-2) Upper: / Lower: / Upper: / Lower: 91.0 Energy Class Energy consumption (electricity) - conventional kWh/cycle Upper: / Lower: / Energy consumption (electricity) - fan forced kWh/cycle Upper: / Lower: 0.76...
- Page 21 Circuit Diagram SINGLE CIRCUIT HEATING ELEMENT SINGLE CIRCUIT HEATING ELEMENT SCHE SCHE SINGLE CIRCUIT HEATING ELEMENT SINGLE CIRCUIT HEATING ELEMENT SCHE SCHE SCER SCER DCER SCER Lamp junction box Top Grill Thermostat switch Circulation fan Lamp Light Thermostat switch Back Grill Note: HIL: HEAT INDICATION LAMP...
- Page 22 Troubleshooting...
- Page 23 01759 487837 support@willowappliances.co.uk General Enquiries 0330 0564 777 sales@willowappliances.co.uk Willow Appliances Limited Willow is a UK household electrical Registered in England & Wales, Company number 12117113 appliance company, based in Staffordshire. Unit 7 Wellington Crescent, Fradley Park, Lichfield, Staffordshire, WS13 8RZ...
- Page 24 ‘Troubleshooting’ section of this user manual. Your Willow product is guaranteed against faults and breakdowns for 24 months. If you need assistance within the first 28 days of your purchase, please contact the retailer supplier.
- Page 25 The warranty will be rendered invalid if the product is re-sold or has been damaged by inexpert repair. Willow disclaim any liability for loss or damage arising from the breakdown of a product. Specifications are subject to change without notice.
- Page 26 WT60CCB - FREESTANDING COOKER...
