- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS WSE60WH & WSE60BK FREESTANDING COOKER Please read before attempting to install or use this appliance. It is recommended that you keep this user manual in a safe place.
- Page 2 WELCOME Thank you for choosing Willow for your new appliance. Your item is pre-registered and your warranty starts from the point of purchase: all you need to do is keep hold of your proof of purchase. We are proud to provide a range of appliances that have been designed with the consumer in mind.
- Page 3 Instruction Manual Models: WSE60WH & WSE60BK...
- Page 4 You’ll soon be enjoying your new Freestanding Cooker It all begins here, with your instructions. Don’t worry, there’s nothing too technical coming up. Just simple, step-by-step guidance to get you up and running quickly. Sound good? Then let’s get started.
-
Page 5: Table Of Contents
Contents Product Support Safety information Product Disposal Getting to know your Product Support Freestanding Cooker Warranty Installing your Freestanding Cooker Using your Freestanding Cooker Panel Care and Maintenance Energy fiche Circuit Diagram... -
Page 7: Safety Information
Safety information... - Page 8 Safety information Important - Please read these instructions fully before installing or operating INSTALLATION WARNINGS DURING USAGE IMPORTANT: Prior to Installation ensure that IMPORTANT: This appliance can be used by the local supply conditions (electricity voltage children aged from 8 years and above and and frequency) are compatible with the persons with reduced physical, sensory or requirements of your freestanding cooker.
- Page 9 Safety information Important - Please read these instructions fully before installing or operating insulation materials. To eliminate this odour IMPORTANT: When the door of the oven is run the oven at 250 degrees for 40-60 open, do not hang or lean anything on it. You minutes with the oven empty.
-
Page 11: Getting To Know Your Freestanding Cooker
Getting to know your Freestanding Cooker... - Page 12 Getting to know your Freestanding Cooker You’ll be up and running in no time Ready? Let’s begin... Please read these instructions carefully. They contain important information which will help you get the best from your freestanding cooker and ensure safe and correct installation and operation.
- Page 13 Getting to know your Freestanding Cooker You’ll be up and running in no time Overview 1. Hob plate 2. Electric furnace 3. Control panel 4. Shelf positions 5. Wire Shelf 6. Baking tray 7. Door seal 8. Hinge 9. Oven door 10.
- Page 14 Getting to know your You’ll be up and running in no time Accessories Baking tray x 1 Grill insert x 1 Chrome shelves x 1 Grill pan handle x 1 Getting to know your Freestanding Cooker...
-
Page 15: Installing Your Freestanding Cooker
Installing your Freestanding Cooker... - Page 16 Bringing it all together requirements irst se en using r t e irst time THIS COOKER MUST BE INSTALLED BY A er ma gi e an unusual ur r m t e eating QUALIFIED INSTALLER IN ACCORDANCE WITH elements an insulati n materials is is n rmal r ne eliminate t is...
- Page 17 Installing your Levelling feet CAUTION Safety chain RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION CAUTION:...
- Page 18 Installing your Freestanding Cooker Bringing it all together Electrical connection IMPORTANT: Electrical connections must be carried out by a suitably qualified person and in accordance with all relevant local building and installation regulations. Fitting on a Power Supply Cable Connecting appropriate power supply · terminal board/ connector block: •...
-
Page 19: Using Your Freestanding Cooker
Using your Freestanding Cooker... - Page 20 Using your Getting the most from your appliance Control panel ℃ Function switch Control Knob • Sets Oven Function/ Mode. B Oven Temperature Control Knob • Sets temperature for baking. C Hotplate Control Knob - can be rotated in either direction •...
- Page 21 Using your Freestanding Cooker Getting the most from your appliance Oven functions Oven light Grill Top & Bottom element Bottom element Oven light-The oven light will operate on all oven functions Grill-The top central heating elements comes on .The extremely high and direct temperature of the grill makes it possible to brown the surface of meats and roasts while locking the juices in to keep them tender.
- Page 22 Using your Freestanding Cooker Getting the most from your appliance General oven and cooking tips General Oven Tips The wire shelves should always be pushed firmly to the back of the oven. Baking trays with food cooking on them should be placed level with the front edge of the oven’s wire shelves.
- Page 23 Using your Freestanding Cooker Getting the most from your appliance Practical Cooking Advice The oven offers a wide range of alternatives which allow you to cook any type of food in the best possible way. With time you will learn to make the best use of this versatile cooking appliance and the following directions are only a guideline which may be varied according to your own personal experience.
- Page 24 Using your Freestanding Cooker Getting the most from your appliance Selector knob Food to be cooked Weight Cooking rack Preheating Thermostat Cooking setting (in kg ) position from time knob time bottom (Minutes) setting (Minutes) Convection Duck 65-75 Roast veal or beef 70-75 Pork roast 70-80...
- Page 25 Using your Freestanding Cooker Getting the most from your appliance Using the hotplates of your cooker Hotplates safety warnings Do not use pots and pans which are unsteady, as these could overbalance. Do not use mats, heat diffusers or wok stands. These will cause a temperature build-up which can damage the ...
-
Page 26: Care And Maintenance
Care and Maintenance... - Page 27 Care and maintenance Looking after your appliance Cleaning WARNING! Isolate the power supply to the appliance and make sure that the cooker is cool. Before cleaning your cooker or performing maintenance, make sure that the cooking mode selection knob and the cooking temperature selection knob is set to ‘OFF’.
- Page 28 Replacement lamps are available from our support team. Please call 01759 487837. Light source shall be replaced by professional. WARNING: Ensure that the appliance is switched o fore replacing the lamp to avoid the possibility of electric shock. Remove the glass cover of the lamp-holder as shown below. Remove the lamp and replace with a lamp resistant to high temperatures (300°C) with the following characteristics:...
- Page 29 WSE60WH / WSE60BK Model Voltage and frequency 220-240V AC/50-60Hz Oven power 2220-2640W Oven usable capacity Power consumption for big hot plate (1370-1630W)x2 Power consumption for small hot plate (915-1090W)x2 Total Hot plate power consumption 4570-5440W Total power 6790-8080W Energy rating...
-
Page 30: Energy Fiche
Energy fiche Brand Model WSE60WH / WSE60BK Type of Oven ELECTRIC Mass 36.5(+/-2) 90.5 Energy Class Energy consumption (electricity) - conventional kWh/cycle 0.77 Energy consumption (electricity) - fan forced kWh/cycle Number of cavities Heat Source ELECTRIC Volume This oven complies with EN 60350-1... -
Page 31: Circuit Diagram
Circuit Diagram HOT PLATE HOT PLATE HOT PLATE HOT PLATE Lamp Light junction box Lamp Bottom 8 P8 Grill Top Grill Thermostat switch 40402501081... -
Page 32: Product Support
Note: Only service centers should carry out servicing. Otherwise warranty may be void. Product support... -
Page 33: Product Disposal
01759 487837 support@willowappliances.co.uk General Enquiries 0330 0564 777 sales@willowappliances.co.uk Willow Appliances Limited Willow is a UK household electrical Registered in England & Wales, Company number 12117113 appliance company, based in Staffordshire. Unit 7 Wellington Crescent, Fradley Park, Lichfield, Staffordshire, WS13 8RZ... -
Page 34: Product Support
‘Troubleshooting’ section of this user manual. Your Willow product is guaranteed against faults and breakdowns for 24 months. If you need assistance within the first 28 days of your purchase, please contact the retailer supplier. -
Page 35: Warranty
The warranty will be rendered invalid if the product is re-sold or has been damaged by inexpert repair. Willow disclaim any liability for loss or damage arising from the breakdown of a product. Specifications are subject to change without notice. - Page 36 WSE60WH & WSE60BK FREESTANDING COOKER...
