- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS WDOC60TBL 60CM ELECTRIC DOUBLE OVEN COOKER Please read before attempting to install or use this appliance. It is recommended that you keep this user manual in a safe place.
- Page 2 WELCOME Thank you for choosing Willow for your new appliance. Your item is pre-registered and your warranty starts from the point of purchase: all you need to do is keep hold of your proof of purchase. We are proud to provide a range of appliances that have been designed with the consumer in mind.
-
Page 3: Table Of Contents
Contents Safety information Product support Safety information Troubleshooting Help and assistance Getting to know your Declaration of conformance to product Freestanding Cooker standards Disposal Overview Accessories Installing your Freestanding Cooker Installation requirements Electrical connection Using your Freestanding Cooker Control panel Oven functions General oven and cooking tips Practical Cooking Advice... -
Page 4: Safety Information
Safety information Important - Please read these instructions fully before installing or operating INSTALLATION WARNINGS DURING USAGE IMPORTANT: Prior to Installation ensure that IMPORTANT: This appliance can be used by the local supply conditions (electricity voltage children aged from 8 years and above and and frequency) are compatible with the persons with reduced physical, sensory or requirements of your freestanding cooker. - Page 5 Safety information Important - Please read these instructions fully before installing or operating WARNING: Before obtaining access to IMPORTANT: When the door of the oven is terminals, all supply circuits must be open, do not hang or lean anything on it. You may unbalance your appliance or damage disconnected.
-
Page 6: Getting To Know Your Freestanding Cooker
Getting to know your Freestanding Cooker You’ll be up and running in no time Ready? Let’s begin... Please read these instructions carefully. They contain important information which will help you get the best from your freestanding cooker and ensure safe and correct installation and operation. -
Page 7: Overview
Getting to know your You’ll be up and running in no time 1. Hob 2. Cooking zone 3. Control Panel 4. Shelf positions Wire Shelf Oven Door Shelf positions Baking tray Oven Door 10. Hinge 11. Wire Shelf 12. Door lock 13. -
Page 8: Accessories
Getting to know your You’ll be up and running in no time Accessories Baking tray x 1 Grill insert x 1 Chrome shelves x 1 Grill pan handle x 1 Getting to know your Freestanding Cooker... -
Page 9: Installation Requirements
Bringing it all together THIS COOKER MUST BE INSTALLED BY A a gi an n a ing an in a i n i i n QUALIFIED INSTALLER IN ACCORDANCE WITH i ina LOCAL REGULATIONS Unpacking IMPORTANT: CONTACT AN AUTHORISED Carefully unpack and examine the appliance for any SERVICE AGENT FOR INSTALLATION OF YOUR damage. - Page 10 Installing your Levelling feet CAUTION Safety chain RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION CAUTION:...
-
Page 11: Installing Your Freestanding Cooker
Installing your Freestanding Cooker Bringing it all together Electrical connection IMPORTANT: Electrical connections must be carried out by a suitably qualified person and in accordance with all relevant local building and installation regulations. Fitting on a Power Supply Cable Connecting appropriate power supply · terminal board/ connector block: Using a screwdriver ,prize open tabs of the Terminal board cover. -
Page 12: Using Your Freestanding
Using your Control panel... -
Page 13: Oven Functions
Using your Freestanding Cooker Getting the most from your appliance Oven functions Grill Defrost mode Top & Bottom Element Fan Baking Bottom Element Oven light Grill -The top central heating elements comes on .The extremely high and direct temperature of the grill makes it possible to brown the surface of meats and roasts while locking the juices in to keep them tender. - Page 14 Using your Freestanding Cooker Getting the most from your appliance Programmable Timer As an example: If cooking time takes 45 minutes and you want it to finish at 14:00 This model has a digital display, 24hr clock with 3 control buttons. When the power is connected, the Press the function button repeatedly until screen displays ‘AUTO’...
- Page 15 Using your Freestanding Cooker Getting the most from your appliance Timer The digital countdown timer can be set up to 23 hours and 59 minutes maximum. To set the timer, press the button and then + or - button until the desired time is displayed. Once button is released, the current time and U is displayed.
-
Page 16: General Oven And Cooking Tips Practical
Using your Freestanding Cooker Getting the most from your appliance General oven and cooking tips General Oven Tips The wire shelves should always be pushed firmly to the back of the oven. Baking trays with food cooking on them should be placed level with the front edge of the oven’s wire shelves. -
Page 17: Cooking Advice
Using your Freestanding Cooker Getting the most from your appliance Practical Cooking Advice The oven offers a wide range of alternatives which allow you to cook any type of food in the best possible way. With time you will learn to make the best use of this versatile cooking appliance and the following directions are only a guideline which may be varied according to your own personal experience. -
Page 18: Using The Ceramic Zones Of Your Cooker
Using your Freestanding Cooker Getting the most from your appliance Using the ceramic cooking zones of your cooker Do not use mats, heat diffusers or wok stands. These will cause a temperature build-up which can damage the hob. Do not let cooking pots over spill, this could leave a mark and residue on the glass. -
Page 19: Care And Maintenance
Care and maintenance Looking after your appliance Cleaning WARNING! Isolate the power supply to the appliance and make sure that the cooker is cool. Before cleaning your cooker or performing maintenance, make sure that the cooking mode selection knob and the cooking temperature selection knob is set to ‘OFF’. -
Page 20: Replacing Oven Lamps
Looking after your appliance Replacement lamps are available from our support team. Please call 0333 305 2263. Light source shall be replaced by professional. WARNING: Ensure that the appliance is switched o fore replacing the lamp to avoid the possibility of electric shock. -
Page 21: Technical Specification
Upper door Lower door Model WDOC60TBL Voltage and frequency 220-240V AC 50-60Hz Upper oven power consumption 1600-1900W Lower oven power consumption 1710-2030W Total oven power consumption 3310-3930 Upper oven usable capacity Lower oven usable capacity Power consumption for large zones... -
Page 22: Energy Fiche
Energy fiche Brand Model WDOC60TBL Type of Oven ELECTRIC Mass 46 (+/-2) Upper: 73.5 Lower: / Upper: / Lower: 94.5 Energy Class Energy consumption (electricity) - conventional kWh/cycle Upper: 0.50 Lower: / Energy consumption (electricity) - fan forced kWh/cycle Upper: / Lower: 0.79... -
Page 23: Circuit Diagram
Circuit Diagram SCHE SCHE SCHE SCHE SCER SCER SCER SCER Heat dissipation fan junction box 45°C Temperature adjuster 120°C Thermal cut-out Light Circulation fan Lamp Lamp Light Top Grill Thermostat switch Back Bottom Grill Grill 1a ACL Thermostat switch 40402501448 Note: HIL: HEAT INDICATION LAMP SCHE: SINGLE CIRCUIT HEATING ELEMENT... - Page 24 Product support Help is always at hand Troubleshooting If you have a problem with your appliance, check the troubleshooting table below to try and rectify your problem before calling your product support service centre.
- Page 25 01759 487837 support@willowappliances.co.uk General Enquiries 0330 0564 777 sales@willowappliances.co.uk Willow Appliances Limited Willow is a UK household electrical Registered in England & Wales, Company number 12117113 appliance company, based in Staffordshire. Unit 7 Wellington Crescent, Fradley Park, Lichfield, Staffordshire, WS13 8RZ...
- Page 26 ‘Troubleshooting’ section of this user manual. Your Willow product is guaranteed against faults and breakdowns for 24 months. If you need assistance within the first 28 days of your purchase, please contact the retailer supplier.
- Page 27 The warranty will be rendered invalid if the product is re-sold or has been damaged by inexpert repair. Willow disclaim any liability for loss or damage arising from the breakdown of a product. Specifications are subject to change without notice.
- Page 28 WDOC60TBL 60CM ELECTRIC DOUBLE OVEN COOKER...
