The drain hose should stay at a height of no
less than 60 cm and not more than 100 cm.
You can extend the drain hose to
maximum 400 cm. Contact the
authorised service centre for the other
drain hose and the extension.
It is possible to connect the drain hose in
different ways:
1. The drain hose can be bent into U shape
and put around the plastic guide.
Buy accessories from authorised
supplier.
On the edge of a sink - Fasten the guide to
the water tap or to the wall.
Make sure that the plastic guide cannot
move when the appliance drains and the
drain hose end is not immersed in the
water. There may be a return of dirty
water into the appliance.
2. If the end of the drain hose looks like this
(see the picture), you can push it directly into
the stand pipe.
10 ENGLISH
3. To a stand pipe with vent hole - Insert the
drain hose directly into a drain pipe. Refer to
the illustration.
The end of the drain hose must always
be ventilated , i.e. the inner diameter of
the drain pipe (min. 38 mm - min. 1.5")
must be larger than the external diameter
of the drain hose.
4. Without the plastic hose guide, to a sink
spigot- Put the drain hose in the spigot and
tighten it with a clamp. Refer to the
illustration.
Make sure that the drain hose makes a loop
to prevent particles going into the appliance
from the sink.
