DENAGO PAS Manual

Pedal Assist Speed Adjustments
The following instructions will outline how you set the MAX
Speed in Pedal Assist (PAS) level 5. Once this is set it will
adjust each of the other levels by a preset percentage
STEP 0 Locate the HMI-
Human Machine Interface
STEP 1 Press and hold M
(MODE) Button until screen
turns on Go to either AVE of
MAX screen
STEP 5- Press M (MODE) for 2seconds
to return to main screen.
You are ready to ride
Please let us know if you have any comments and/or follow up questions!
CS@BIKE.com or 1-877-755-2453(BIKE)
STEP 2 Press and hold
(UP/Down) Simultaneously for 2-4
seconds until screen flashes and
goes to setting interface
STEP 3- First screen to pop up is
wheel size-
to go to next screen
STEP 4- LS mode- (
where you can adjust MAX speed- Use the
+ -
(UP/Down) to adjust MAX limit-
The range is 28 – 11 mph as the Lowest Limit
+ -
PRESS M (MODE)
Limited Speed)
this is
