Concerning Compact Disc£~
Portable CD player
Panasonic
Only compact discs bearing this mark can be used with this unit.
How to remove a disc from its case How to store the disc in its case
How to hold a disc
o
(SP
If the surface is dirty
Wipe it with a damp cloth and then wipe dry. Wipe from the center toward the outer circumfer¬
ence
Play surface (shiny surface)
o(5i>
If moisture has formed on a disc
When moisture has formed because the disc
was brought suddenly into a warm room from
a cold environment, wipe it off using a soft dry
cloth.
When storing discs
Avoid locations which are
•Exposed to direct sunlight.
•Susceptible to high levels of humidity or
dust.
•Directly exposed to heat from a heating appli¬
ance.
•On top of a car dashboard or near the rear
window
Handling precautions
•On the label side (the side with writing)
Do not write anything using a penal, ball¬
point pen. etc Do not stick paper or labels.
•On the disc (shiny) side
Handle this side carefully to keep it free from
fingerprints or scratches. Do not use record
cleaners, solvents, etc.
•Do not attach labels or stickers to CD's.
Do not use CDs with exposed adhesive from
tape or left over peeled off stickers.
•Do not use scratch-proof protectors or covers
other than those specified for use with this
unit.
Panasonic Consumer Electronics Company, Division of
Matsushita Electric Corporation of America
One Panasonic Way Secaucus. New jersey 07094
Panasonic Sales Company, Division of Matsushita Electric of
Puerto Rico, Inc. ("PSC")
Ave 65 de lnfantena. Km. 9.5 San Cabnd Industrial Park. Carolina.
Puerto Rko 00985
Panasonic Canada Inc.
RQT3745-P
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
FI
296R0
Dear Customer
Thank you for purchasing this product.
For optimum performance and safety, please
read these instructions carefully
The model number and serial number of this
product can be found on either the back or
the bottom of the unit.
Please note them in the space provided
below and keep for future reference.
MODEL NUMBER __
SERIAL NUMBER _
SL-S221CSSL-S321C/SL-S332C ONLY
To install this product in the car, please refer
tn the "Installation Instructions" (attached
sheet).
The SL-S225 and SL-S332C models are only for
USA.
Operating Instructions
SL-S220/SL-S225
SL- S3 20/SL-S221C
SL-S321C/SL-S332C
DIGITAL AUDIO
For U.S. A and Canada (RFEA403C-S)
For others (RFEA403Z-S)
For Canada only
Stereo earphone. 1 pc.
(RFEV317P-KS)
For others
Stereo headphones. 1 pc.
(RFEV705P-KS)
SL-S225 ONLY
Rechargeable Ni-Cd batteries.2 pcs.
(RP-BP60PYS)
Battery carrying case.1 pc.
(RFKNL37(hK)
SL-S221C/SL-S321C/SL-S332C
ONLY
Car adaptor. . 1 pc.
(SH-CDC2PPY)
Car stereo cassette adaptor.1 pc.
(SH-CDM8ASY-K)
SL-S332C ONLY
Wireless remote controller . 1 pc.
(RAK-SL927WH)
Battery for Wireless remote
controller .1 pc.
(CR2025/1P0D)
For area except U.S.A and Canada
Power plug adaptor.1 pc.
(SJP5213-2)
Remove the rechargeable
batteries
from
their case before use
Use numbers indicated in parentheses when asking for replacement parts
(Only for USA) To order accessories call PASC Accessory Dept 1-800-332-5368
Supplied Accessories
Check the packing carton for these accessories.
AC adaptor .... 1 pc.
Before connecting,*operating or adfusting this product, please read
these instructions completely. Please save this manual.
i~Pl (PCI fPXl
Precautions
Before using Ihis unit, be sure to read the applicable
items of the operating instructions and these safety sug¬
gestions carefully.
Afterwards keep them handy for future reference. Take
special care to follow the warnings indicated on the unit
itself as well as in the operating instructions.
Safety
1. Power Source -The unit should be connected to
power supply only of the type described in the oper¬
ating instructions or as marked on the unit. Use only
the AC adaptor or car adaptor described in the oper¬
ating instructions when recharging.
2. Polarization—If the unit is equipped with a polar¬
ized AC power plug (a plug having one blade wider
than the other), that plug will fit into the AC outlet
only one way. This is a safety feature. If you are un¬
able to insert the plug fully into the outlet, try revers¬
ing the plug. If the plug should still fail to fit. contact
your electrician to replace your obsolete outlet Do
not defeat the safety purpose of the polarized plug
3. Care of AC adaptor Take care that the cord of the
AC adaptor should be routed so that they arc not
likely to be walked on or pinched by items placed
upon or against them. Never take hold of the AC
adaptor if your hand is wet, and always grasp the
plug body when connecting or disconnecting it.
4. Nonuse Periods—When not in use, be sure to dis¬
connect the AC adaptor from theAC power outlet.
H
5. Batteries—If the set is not used for a long period of
time or is used only from an AC power source, re¬
move all the batteries to prevent potential damage
due to possible battery leakage. Do not mix batteries
(old and new) or different types of batteries.
Installation
■ Environment
1. Water and Moisture—Do not use this unit near
water—for example, near a bathtub, washbowl,
swimming pool, or the like. Damp basements should
also be avoided.
2. Condensation —Moisture may form on the lens in
the following conditions...
•immediately after a heater has been turned on.
• in a steamy or very humid room.
•when the unit is suddenly moved from a cold envi¬
ronment to a warm one. If moisture forms inside
this unit, it may not operate properly. To correct
this problem wait about one hour for the moisture
to evaporate
3. Heat—Never use or place this unit near a heat
source. Do not leave it in an automobile exposed to
direct sunlight for a long time with the doors and
windows closed as this may deform the cabinet.
■ Placement
1. Foreign Material-Care should be taken so that ob¬
jects do not fall into and liquids are not spilled into
the unit. Do not subject this unit to excessive smoke,
dust, mechanical vibration, or shock.
2. Magnetism— The unit should be situated away from
equipment or devices that generate strong magnetic
fields.
3. Stacking — Do not place any objects, on top of the
unit.
Mainfenance
(See page 7 for details.)
Clean the cabinet, panel and controls with a soft cloth
lightly moistened with mild detergent solution.
Do not use any type of abrasive pad, scouring powder
or solvent such as alcohol or benzine.
Service
1. Damage Requiring Service The unit should be
serviced by qualified service personnel when:
(a) The AC adaptor is damaged; or
(b) Objects have fallen or liquid has been spilled
into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit docs not appear to operate normally or
exhibits a marked change in performance; or
(e) The unit has been dropped, or the enclosure
damaged.
2. Servicing The user should not attempt to service
the unit beyond that described in the operating in¬
structions. All other servicing should be referred to
an authorized service personnel.
(Only for U.S.A.)
Call 1-800-545-2672 for the address of an authorized
factorv sorvicenter.
