8

Operation

This chapter describes the detailed information on how to operate.

8.1 Start of operation

8.1.1 Confirmation before operation

1) Confirm that the recirculating fluid has reached a L level
2) Supply radiating water.
3) Confirm that there is no incorrect wiring of the
connected cables and turn on the power supply of the
unit.
4) When power is turned on, software version is indicated
on display panel for approx. 1 sec. (Ex. : 1.0）

8.1.2 Setting of values

When the product has been found to start operating normally set the values such as
temperature.(see section 8.3). Once the value is set, it will remain set even if the power supply
is turned off.
Be sure to operate the operation and display panel by finger. Using tools
such as a screwdriver, pen, or pencil may damage the panel.

8.1.3 Cautions for Operation Control

1) Wait at least 30 min. the after power supply is turned on before operating to allow the product to warm
up.
2) If an alarm occurs during operation, refer to section 9 for the remedy
Do not operate the unit with remaining the outer panel open or removed.
Contact with inside of the unit may cause injury or electric shock.
The level of a tank should be checked once a day to keep the level within
the appropriate range (H to L). The level may go down due to the
evaporation of the recirculating fluid. When the level goes down "L"
level, it may degrade the performance or damage the installed pump.
Operate the unit with a proper level of fluid.
If lower-temperature radiating water is supplied, dew may condense in
the product and the equipment could be damaged. Keep the temperature
above the atmospheric pressure dew point.
Please do not use the device which generates the electromagnetic
radiation such as cellular phones beside the unit. There is a possibility
that the unit miss-operate.
Operation
SOFT VERSION
1 . 0
8-1
