- Page 1 Vega Kids' 12V Ride-On A guide for your ride. IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE. MODEL SKU: JVEGA-WHT...
- Page 3 Jetson's top two riding rules: Be safe. Have fun!
-
Page 4: Table Of Contents
Contents Safety Warnings ........................4 Warranty Coverage . - Page 5 3. Making Moves ................... 4 3 3.1 Opening &...
-
Page 6: Safety Warnings
Safety Warnings • Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety instructions. The user will be responsible for any loss or damage caused by improper use. • Failure to use correct charger can result in fire and explosion, resulting in property damage, injury, and death. •... - Page 7 • WARNING – Risk of Fire and Electric Shock – No User Serviceable Parts. MODIFICATIONS Do not attempt to disassemble, modify, repair, or replace the product or any components of the unit without instruction from the Jetson Care Team. This will void any warranty, and can lead to malfunctions which may cause injury.
- Page 8 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 9: Warranty Coverage
Jetson's user manuals (refer to ridejetson.com/support). Under this warranty, you will be able to direct your claims to Jetson even in situations where you purchased the Jetson Product from one of our authorized retailers. To read the full terms of our warranty, visit ridejetson.com/warranty. -
Page 10: About Your Product
1. About Your Product What’s in the Box A. FRAME B. CHARGER C. WHEEL (X4) D. HUBCAP (X5) E. SEAT BACK F. SEAT BASE WITH SEATBELT G. CENTER TAILSTOCK PIECE H. LEFT TAILSTOCK PIECE I. RIGHT TAILSTOCK PIECE J. "SPARE” WHEEL K. - Page 11 (X5) (X4)
- Page 12 TOOLS AND HARDWARE INCLUDED FOR ASSEMBLY, ADJUSTMENT, AND MAINTENANCE: N. M12 X 23 WASHER (X8, INCLUDING 2 SPARE) O. M10 AXLE NUT (X6, INCLUDING 2 SPARE) P. M4 X 16MM SCREW (X4) (X8, INCLUDING (X6, INCLUDING (X4) 2 SPARE) 2 SPARE) SOCKET WRENCH (X2) PHILLIPS-HEAD SCREWDRIVER...
-
Page 14: Product Overview
Product Overview 1. FRONT WHEEL (X2; LEFT AND RIGHT) 2. REAR WHEEL (X2; LEFT AND RIGHT) 3. LED LIGHT-UP GRILL 4. LED HEADLIGHT (X2; LEFT AND RIGHT) 5. DOOR (X2; LEFT AND RIGHT) 6. DOOR LEVER (X2; LEFT AND RIGHT) 7. - Page 15 *INTERIOR VIEW NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT.
-
Page 16: Product Specs
Product Specs · MAX SPEED IN FAST MODE: UP TO 3 MPH · MAX SPEED IN LOW MODE: UP TO 2 MPH · RUN TIME: UP TO 45 MINS · BATTERY: RECHARGEABLE 12V, 7AH LEAD-ACID · REMOTE CONTROL BATTERIES: 2 AAA (NOT INCLUDED) ·... -
Page 17: Online Resources
Online Resources Scan for our most updated Vega onboarding materials and support resources. -
Page 19: Getting Started
2. Getting Started Starting Notes · KICK OFF YOUR ADVENTURE RIGHT: PRIOR TO USE OF THIS PRODUCT, CAREFULLY READ THE ENTIRE USER MANUAL, INCLUDING SAFETY WARNINGS. MAKE SURE YOU UNDERSTAND, ACCEPT, AND ADHERE TO ALL: • MANUFACTURER’S RECOMMENDATIONS. • SAFETY INSTRUCTIONS AND WARNINGS. •... -
Page 20: Attaching The Front Wheels
Attaching the Front Wheels 1. CAREFULLY FLIP THE FRAME (A) UPSIDE-DOWN AND PLACE IT ON YOUR WORK SURFACE. 2. SLIDE 1 WASHER (M) ONTO EACH SIDE OF THE AXLE (2 TOTAL; LEFT AND RIGHT). 3. LEADING WITH THE GEAR SIDE OF THE WHEEL, SLIDE ONE WHEEL (C) ONTO EACH FRONT AXLE. 4. - Page 21 6. ALIGN THE TABS ON 1 HUBCAP (D) WITH THE TAB HOLES IN 1 FRONT WHEEL. POP THE HUBCAP INTO PLACE. REPEAT WITH A 2ND HUBCAP ON THE OTHER FRONT WHEEL. (2 TOTAL; LEFT AND RIGHT) HUBCAP (D) TAB SLOT FRONT WHEEL...
- Page 22 7. CHECK THAT THE FRONT WHEELS ARE SECURE ON THE AXLE AND THE HUBCAPS ARE SECURE ON THE WHEELS.
-
Page 23: Attaching The Rear Wheels
AXLE NUT WHEEL SOCKET WRENCH SOCKET WRENCH GEAR BOX REAR AXLE WASHER GEAR BOX IMPORTANT: TAKE CARE NOT TO OVER-TIGHTEN THE NUT, AS OVER-TIGHTENING CAN CAUSE THE WHEEL TO CRACK. STOP TURNING THE NUTS WITH THE WRENCHES ONCE GEAR THERE IS A LOT OF RESISTANCE. Attaching the Rear Wheels 1. - Page 24 HUBCAP (D) REAR WHEEL TAB SLOT HUBCAP (D) 4. ALIGN THE TABS ON 1 HUBCAP (D) WITH THE TAB HOLES IN 1 REAR WHEEL. POP THE HUBCAP INTO PLACE. REPEAT WITH A 2ND HUBCAP ON THE OTHER REAR WHEEL. (2 TOTAL; LEFT AND RIGHT)
- Page 25 5. CHECK THAT THE REAR WHEELS ARE SECURE ON THE AXLE AND THE HUBCAPS ARE SECURE ON THE WHEELS.
-
Page 26: Inserting The Seat
Inserting the Seat 1. CAREFULLY FLIP THE FRAME (A) OVER SO THAT IT IS UPRIGHT. 2. POSITION THE SEAT BACK (E) ABOVE THE PASSENGER AREA SUCH THAT: • THE HEADRESTS ARE AT THE TOP. • THE HEADRESTS FACE FORWARD. • THE 2 TABS ON THE BACKSIDE OF THE SEAT BACK ARE ALIGNED WITH THE 2 BACK TAB HOLES IN THE CARGO AREA. BACK SIDE OF SEAT BACK PASSENGER AREA... - Page 27 3. GENTLY PUSH THE SEAT BACK INTO THE PASSENGER AREA SUCH THAT THE 2 UPPER TABS CLICK INTO THE 2 TAB HOLES AT THE TOP OF THE FRAME AND THE 2 LOWER TABS CLICK INTO THE 2 TAB HOLES IN THE PASSENGER AREA. SEAT BACK (E) FRAME PASSENGER AREA...
- Page 28 4. CHECK THAT THE SEAT BACK IS SECURE IN THE FRAME. 5. POSITION THE SEAT BASE (F) ABOVE THE PASSENGER AREA SUCH THAT: • THE SEATBELT IS ON THE TOP SIDE. • THE 3 TABS AT THE BACK OF THE SEAT BASE ARE ALIGNED WITH THE 3 TAB HOLES AT THE BOTTOM OF THE SEAT BACK. SEATBELT TAB (X3) SEAT BASE (F)
- Page 29 6. ENSURE THAT THE SEATBELT STRAPS ARE NOT DANGLING BELOW THE SEAT BASE. SLIGHTLY TILT THE FRONT OF THE SEAT BASE UP AND PUSH IT BACK UNTIL THE 3 TABS ARE FULLY INSERTED IN THE 3 TAB HOLES. 7. LOWER THE FRONT OF THE SEAT BASE SO THAT •...
- Page 30 8. INSERT 1 SCREW (O) INTO EACH SET OF ALIGNED HOLES BY TURNING IT CLOCKWISE. (2 TOTAL; 1 LEFT & 1 RIGHT) 9. TIGHTEN THE SCREWS WITH THE PHILLIPS-HEAD SCREWDRIVER. 10. CHECK THAT THE SEAT BASE IS SECURE IN THE FRAME. PHILLIPS-HEAD SCREWDRIVER SEAT BASE...
-
Page 31: Assembling & Attaching The Tailstock
Assembling & Attaching the Tailstock 1. CLICK THE LEFT TAILSTOCK (G) AND RIGHT TAILSTOCK (H) ONTO THE CENTER TAILSTOCK (I). RIGHT TAILSTOCK (H) LEFT TAILSTOCK (G) CENTER TAILSTOCK (I) - Page 32 2. POSITION THE TAILSTOCK ABOVE THE CARGO AREA SUCH THAT: • THE 4 TAILSTOCK LEGS ARE POINTING DOWN AND ALIGNED WITH THE 4 HOLES AROUND THE CARGO AREA. • THE LEFT TAILSTOCK IS ON THE LEFT SIDE OF THE CARGO AREA AND THE RIGHT TAILSTOCK IS ON THE RIGHT SIDE OF THE CARGO AREA (AS VIEWED FROM BEHIND THE FRAME).
- Page 33 4. ENSURE THAT THE SCREW HOLE IN EACH TAILSTOCK ARM IS ALIGNED WITH THE SCREW HOLES IN THE SEAT BACK. INSERT 1 SCREW (O) INTO EACH SET OF ALIGNED HOLES BY TURNING IT CLOCKWISE. (2 TOTAL; 1 LEFT & 1 RIGHT) 5.
- Page 34 6. CHECK THAT THE TAILSTOCK IS SECURE ON THE FRAME.
-
Page 35: Attaching The "Spare" Wheel
Attaching the “Spare” Wheel* 1. POSITION THE “SPARE” WHEEL (J) ABOVE THE CARGO AREA SUCH THAT SPARE WHEEL SUPPORT IS FACING DOWN AND THE WHEEL IS TILTED TOWARDS THE TOP OF THE TAILSTOCK. 2. CLICK THE SPARE WHEEL SUPPORT INTO THE HOLE AT THE REAR OF THE CARGO AREA. TAILSTOCK SPARE WHEEL (J) SPARE WHEEL... - Page 36 3. CHECK THAT THE SPARE WHEEL IS SECURE ON THE FRAME (A). 4. ALIGN THE 4 TABS ON 1 HUBCAP (D) WITH THE 4 TAB HOLES IN THE SPARE WHEEL. CLICK THE TABS INTO THE TAB HOLES. 5. CHECK THAT THE HUBCAP IS SECURE ON THE SPARE WHEEL. TAB SLOT (X4) TAB (X4) HUBCAP (D)
-
Page 37: Attaching The Steering Wheel
Attaching the Steering Wheel IMPORTANT: THE HARDWARE FOR THIS STAGE OF ASSEMBLY IS PRE-INSTALLED ON THE STEERING WHEEL STEM. 1. LOOSEN AND REMOVE THE PRE-INSTALLED BOLT (SIZE M5) FROM THE STEERING WHEEL (K) STEM BY TURNING IT COUNTERCLOCKWISE WITH THE PHILLIPS-HEAD SCREWDRIVER. REMOVE THE NUT (SIZE N7) AND SET THE HARDWARE ASIDE. STEERING WHEEL (K) BOLT PHILLIPS-HEAD... - Page 38 2. SLIDE THE STEERING WHEEL STEM OVER THE STEERING ROD AND INTO THE STEERING TUBE. ROTATE THE STEERING WHEEL UNTIL THE BOLT HOLES IN THE SIDES OF THE STEERING WHEEL STEM ARE ALIGNED WITH THE BOLT HOLES IN THE STEERING ROD. STEERING WHEEL STEM STEERING WHEEL STEERING TUBE...
- Page 39 3. RE-INSTALL THE HARDWARE. HOLD THE NUT IN PLACE WHILE YOU INSERT THE BOLT THROUGH THE ALIGNED HOLES OF THE STEERING WHEEL STEM BY TWISTING IT IN CLOCKWISE WITH THE PHILLIPS-HEAD SCREWDRIVER. TIGHTEN THE BOLT INTO THE NUT. 4. CHECK THAT THE STEERING WHEEL IS SECURE IN THE FRAME (A). STEERING WHEEL FRAME (A) PHILLIPS-HEAD...
-
Page 40: Attaching The Windshield
Attaching the Windshield 1. POSITION THE WINDSHIELD (L) ABOVE THE FRAME (A) SUCH THAT • THE 4 WINDSHIELD LEGS ARE POINTING DOWN AND ALIGNED WITH THE 4 HOLES ON THE TOP OF THE FRAME IN FRONT OF THE STEERING WHEEL. •... - Page 41 3. CHECK THAT THE WINDSHIELD IS SECURE ON THE FRAME. WINDSHIELD FRAME...
-
Page 42: Connecting The Battery
Connecting the Battery 1. USE THE HANDLES ON THE HOOD TO LIFT THE HOOD OPEN. 2. FROM THE 2 SETS OF WIRES IN THE BATTERY COMPARTMENT, MAKE THE ELECTRICAL CONNECTION BY CLICKING THE INSERTION COUPLER INTO THE RECEIVING COUPLER. HOOD IMPORTANT: HANDLE ELECTRICAL COMPONENTS WITH CAUTION. -
Page 43: Charging The Battery
IMPORTANT: TO PREP THE BATTERY FOR LONG-TERM USE, AN EXTENDED INITIAL CHARGING SESSION IS NECESSARY. BEFORE RIDING THE VEGA FOR THE FIRST TIME, CHARGE THE BATTERY FOR A MINIMUM OF 18 HOURS —EVEN IF THE CHARGING INDICATOR LIGHT ON THE CHARGER IS ILLUMINATED IN GREEN. THEN, CHARGE ONLY UNTIL THE BATTERY POWER IS FULL—6 HOURS PER CHARGING SESSION. - Page 44 IMPORTANT CHARGING NOTES: · ONLY USE THE INCLUDED CHARGER OR ONE OBTAINED DIRECTLY THROUGH JETSON LABELED WITH: SL12-12-04 OR THE PART SKU PJVEGA-CH. FAILURE TO USE CORRECT CHARGER CAN RESULT IN FIRE AND EXPLOSION. · ALWAYS KEEP THE CHARGING PORT CLOSED WHEN NOT ACTIVELY CHARGING THE BATTERY.
-
Page 45: Making Moves
CHECK THAT THE BELT IS SECURE AND SNUG OVER THE RIDER'S LAP. IF NECESSARY, SHORTEN OR LENGTHEN THE BELT BY MOVING THE ADJUSTMENT SLIDE BUCKLE ALONG THE STRAP. ADJUSTMENT SLIDE BUCKLE IMPORTANT: ENSURE THAT CHILD IS SECURELY FASTENED BY THE SEAT BELT BEFORE POWERING ON THE VEGA. -
Page 46: Using The Remote Control
Using the Remote Control YOU WILL NEED 2 AAA BATTERIES (NOT INCLUDED) TO OPERATE THE REMOTE CONTROL. WHEN THE REMOTE CONTROL IS BEING USED, IT GIVES PARENTAL OVER-RIDE OF THE VEHICLE'S MOVEMENT. USE THE BUTTONS ON THE REMOTE CONTROL TO: ·... - Page 47 5. INSERT AND TIGHTEN THE SCREW IN THE HOLE BY TURNING IT CLOCKWISE WITH THE SCREWDRIVER. TO RE-ESTABLISH CONNECTION OF THE REMOTE WITH YOUR VEGA: THE REMOTE CONTROL MAY NEED TO BE RE-PAIRED WITH YOUR VEHICLE IF THE CONNECTION IS LOST. TO RE-PAIR THE REMOTE CONTROL: 1.
-
Page 48: A Guide To Your Dashboard & Controls
A Guide to Your Dashboard & Controls STEERING BATTERY CHARGE WHEEL INDICATOR SCREEN DIRECTION SHIFTER SPEED SWITCH ACCELERATOR PEDAL POWER BUTTON... - Page 49 TO TURN THE VEGA ON OR OFF: QUICK-PRESS THE POWER BUTTON. TO MOVE THE VEGA: PUSH DOWN ON THE ACCELERATOR PEDAL. TO SLOW DOWN: EASE UP ON THE PEDAL. TO STOP: RELEASE THE ACCELERATOR PEDAL. TO TURN: ROTATE THE STEERING WHEEL TO THE LEFT OR RIGHT.
-
Page 50: Maximizing Speed & Run Time
RIDING STYLE – FREQUENT STARTING AND STOPPING WILL REDUCE RUN TIME. · AIR TEMPERATURE – THE IDEAL TEMPERATURE FOR RIDING AND STORING THE VEGA IS BETWEEN 50 -75°F (10-23.9°C). · INCLINE – THE MOTOR HAS TO WORK HARDER WHEN YOU RIDE UPHILL, AND GOING AGAINST GRAVITY MAKES IT HARD TO HIT THE MAXIMUM ACHIEVABLE SPEED. -
Page 51: Safe Journeying
4. Safe Journeying Pre-Ride Safety Checks CONDUCT THESE IMPORTANT SAFETY CHECKS BEFORE EVERY RIDE: SEAT BELT · CHECK THAT THE SEAT BELT IS SECURELY ATTACHED TO THE SEAT. · ENSURE THAT THE BELT CAN BE FASTENED SECURELY WITH THE CLIPS AND ADJUSTMENT BUCKLE. FRAME ·... -
Page 52: Helmet Safety
Helmet Safety A HELMET SHOULD BE WORN BY THE RIDER AT ALL TIMES. PROPER POSITIONING: IMPROPER POSITIONING: THE FOREHEAD IS COVERED THE FOREHEAD IS EXPOSED. BY THE HELMET. A FALL COULD RESULT IN SERIOUS INJURY. * WEAR A HELMET, APPROPRIATE CLOTHING, SHOES, AND SAFETY GEAR. AVOID CLOTHING THAT CAN GET CAUGHT INTO OR UNDER THE WHEELS. -
Page 53: Care & Maintenance
DIRECTLY TO THE PRODUCT, AS THE ELECTRICAL AND ELECTRONIC SYSTEMS MAY GET WET, WHICH COULD LEAD TO A MALFUNCTION THAT PUTS RIDER SAFETY AT RISK. · IF THE ELECTRIC PARTS OR BATTERY GET WET, DO NOT POWER ON THE VEHICLE. CONTACT THE JETSON CARE TEAM FOR ASSISTANCE. STORING THE VEGA ·... - Page 55 Stay connected. Be sure to follow @ridejetson on social media to learn about fantastic offers, giveaways, and all the latest Jetson news. Loving your ride? Then be sure to leave a review at ridejetson.com/reviews. We can’t wait to hear from you!
- Page 56 Date Code: 08/2024 Document Edition: v1.0 © 2024, JETSON. ALL RIGHTS RESERVED. Manufactured by JETSON ELECTRIC BIKES LLC. No portion of this document, including shape, copy, graphics, and design, may be reproduced or transmitted in any form or by any means.
