- Page 1 866.332.2403 (TOLL FREE); 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE HEXAGONAL RETREAT PAVILION...
- Page 2 P| 1 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 3 P| 2 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 4 P| 3 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 5 P| 4 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 6 P| 5 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 7 Step 2: Use 2 ½´´ deck screws (C) to attach the floor board (0) to the floor panels. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 2 ½´´ Deck Screw P| 6 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 8 Step 3: Install the anchor bases with ½´´ X 4´´ anchor bolts (D) or lag bolts. Please see the “How to anchor your pergola document” for all details. Step 4: Place the floor above the anchor bases. P| 7 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 9 Step 6: Use 3/8´´ x 6´´ lag bolts (F) to attach the Fences (1B to 5B) to the posts and 5/16´´ x 3´´ lag bolts (E) to attach to the floor. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ X 6´´ Lag Bolts 5/16´´ X 3´´ Lag Bolts P| 8 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 10 With Corvels: Use 3/8´´ x 9´´ bolts (I) to attach the corvels to the posts and 3/8´´ x 8´´ bolts to attach to the roof frames. 3/8´´ X 8´´ Bolts 3/8´´ X 9´´ Bolts P| 9 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 11 3/8´´ x 5 ½´´ bolts (H) to attach to the roof frames. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ X 5 ½´´ Bolts P| 10 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 12 Step 10: Attach the metal plaques to the roof frames with 5/16´´ X 3´´ Lag Bolts (E). 5/16´´ X 3´´ Lag Bolts Step 11: Remove the lower tables from the roof panels, as shown below. P| 11 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 13 Step 13: Use 4´´ deck screws (K) to attach the second roof frame (1F) to the roof panels at the height indicated in the drawings. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 4´´ Deck Screw P| 12 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 14 5/16´´ X 4´´ Bolts Step 15: Place the tables that were removed from the roof panels. After that, put exterior clear silicone on the roof panels with the second roof frame joints. Exterior Clear Silicone P| 13 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 15 ¾´´. After that, put exterior clear silicone on the roof boards joints. Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 14 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 16 Step 18: Use 3´´ deck screws (B) to attach the roof trims (1G to 6L) to the roof boards. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3´´ Deck Screws P| 15 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 17 Step 19: Insert the second roof (1M) in the small center base on the second roof frame. After that, use 4´´ deck screws (K)to attach. 4´´ Deck Screws 4´´ Deck Screws Step 20: Finally, attach the boots to the posts with 3´´´deck Screws (B). 3´´ Deck Screws P| 16 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 18 The Hexagonal Retreat Pavilion with Corvels: The Hexagonal Retreat Pavilion with Upper Panels: P| 17 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
- Page 19 This completes the Pavilion assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 18 THE HEXAGONAL RETREAT PAVILION www.ForeverRedwood.com...
