Table of Contents
Related Manuals for Tekky Wednesday 61096
Summary of Contents for Tekky Wednesday 61096
- Page 1 Entertainment Inc. WEDNESDAY is a trademark of Tee & Charles Addams Foundation. Archway © 2024 Metro-Goldwyn-Mayer Studios Inc. All Rights Reserved. TEKKY and the logo design are trademarks of JCW ATTACH YOUR Investments, Inc., d/b/a Tekky, and used under license. TekkyDesign.com RECEIPT HERE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents..................................3, 4 Safety Information and Preparation............................5 Assembly Instructions................................ 6 - 11 Operating Instructions................................12 Care and Maintenance................................13 Troubleshooting and FCC................................. 14... -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Right Side Metal Base (H) Left Side Metal Base (H1) Short Metal Base Frame Stabalizer (O, P) Long Metal Base Frame Stabalizer (P) Left Side Metal Lower Support Frame (G1, H1) Left Side Metal Mid Support Frame With Electrical Connectors (F1, G1) Left Side Upper Metal Frame With Tether &... - Page 4 PACKAGE CONTENTS CONTINUED PART DESCRIPTION QUANTITY Molded Plastic Column With Control Box / Speaker and IR Sensor, Right Side Base Molded Plastic 3-Block Column Molded Plastic 2-Block Colum (Has Opening For Lantern) Right & Left Side Molded Plastic Thin Column Ledge Right &...
-
Page 5: Safety Information And Preparation
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate, or install the product. WARNING • Warning: Risk of injury to persons. Read and understand instruction manual before use. • Warning: CHOKING HAZARD! Small parts. This item is not a toy. For decoration only. •... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Please Note : To beging assembly of the Wednesday Nevermore Academy Archway, you will need to assemble this with the parts face down on the floor as shown in illustration 1, 2 and 3. Due to that, please follow directions of “Left” and “Right”... - Page 7 ASSEMBLY INSTRUCTIONS 4. Slide right side Thin Column Ledge (part 14) over Upper Metal Frame with tether and electrical connector (Part 10). Make sure slot on bottom is facing inward. Snap lock to the assembled sign by matching D to D and E to E. Connect the electrical wires from the sign to the wires of the top of the metal frame by matching A5 to A5.
- Page 8 ASSEMBLY INSTRUCTIONS 8. Snap-lock the Left Side Lower Metal Frame Support pole (Part 5) to the Mid Left Side Metal Frame Support Pole (Part 6) by matching G1 to G1. 9. Slide the Molded Plastic 2-Block Column, opening for lantern facing the floor (Part 13) and slide up from the bottom of the assembled left side metal frame.
- Page 9 ASSEMBLY INSTRUCTIONS 12. Slide the Right Side Plastic Molded 3-Block Column (Part 12) up from the bottom and match to the 2-Block part. Please note that there are no wires that go through on this side. 13. Slide the Plastic Molded Left Side Bottom of the Column (Part 11) up from the bottom and attach the wires coming through Part 12, to the wires coming out from the Control Box on the inside by matching both A3 wires to both A3...
- Page 10 ASSEMBLY INSTRUCTIONS 16. With the archway still flat on the floor and the Metal Base attached, connect the Short Metal Base Frame Stabilizer (Part 3) by matching O to O. Then Snap Lock the Long Metal Base Frame Stabilizer (Part 4) to Part 3 by matching P to P. 17.
- Page 11 ASSEMBLY INSTRUCTIONS 20. Slide the Molded Plastic Thick Column Ledge (Part 15) over the top of the Upper Metal Frame on the left side, then place the Molded Plastic Crows (Part 17) over the top of each exposed upper Metal Frames. Please note that the Crows are to point inwards.
-
Page 12: Operating Instructions
OPERATING INSTRUCTIONS 1. Insert the 5.9V 1.5 A ADAPTER (Part 22) in to the CONTROL BOX. Make sure it is fully secure by twisting it tight. 2. Move the switch to the ON position. Move in front of the item or make a loud sound (clap) to activate the item. -
Page 13: Care And Maintenance
CARE AND MAINTENANCE • STORE IN A COOL AND DRY ENVIRONMENT. • SURFACE WASHABLE ONLY. DO NOT USE ANY HARSH OR ABRASIVE CLEANING AGENTS. • DESIGNED FOR SEASONAL OPERATION ONLY. • NOT INTENDED FOR CONSTANT OR LONG-TERM USE. • PROPER STORAGE AND USE ARE ESSENTIAL TO THIS ITEM’S LONGEVITY. •... -
Page 14: Troubleshooting And Fcc
FCC REGULATION FCC STATEMENT FCC RULES: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modi cations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Need help?
Do you have a question about the Wednesday 61096 and is the answer not in the manual?
Questions and answers
