INSTALL GUIDE

OPERATION MANUAL AND SERVICE PARTS LIST

KEEP THE MANUAL WITH THE VEHICLE

NOTE:

Read this manual before installing, operating or servicing this equipment. Failure to comply with the operation and

maintenance instructions in this manual will VOID THE EQUIPMENT WARRANTY.

This publication contains the latest information available at the time of preparation. Every effort has been made to ensure accuracy.

Vanair

Manufacturing, Inc. reserves the right to make design change modifications or improvements without prior notification.

Making unauthorized modification to the system components WILL VOID THE WARRANTY! Always contact Vanair

beginning any changes to the EPEQ

I N S T A L L G U I D E

EPEQ

Electrified Power Equipment

Part No. 90204 - System Installation Guide

System Components.

EPEQ INSTALL GUIDE_ 90204_r1

before

Effective Date: 08/01/2023

Table of Contents

Need help?

Do you have a question about the EPEQ and is the answer not in the manual?

Questions and answers

Summary of Contents for Vanair EPEQ

Page 1 This publication contains the latest information available at the time of preparation. Every effort has been made to ensure accuracy. Vanair Manufacturing, Inc. reserves the right to make design change modifications or improvements without prior notification. ® Making unauthorized modification to the system components WILL VOID THE WARRANTY! Always contact Vanair before ® beginning any changes to the EPEQ System Components.
Page 2 -- This page intentionally left blank--...
Page 3 INTRODUCTION This guide is designed to provide an overview of the overall system, its components, connection diagrams and to walk users through the basics of properly setting up and connecting their EPEQ ® components.
Page 5: Table Of Contents
EV CHARGER ....................39 EPEQ INVERTER3000 ....................43 ® EPEQ INVERTER5000 ....................47 ® INVERTER6000 ....................... 71 WARRANTY ........................77 INSTALLATION FINAL FINISH FORM ..........PAGE 1 & 2 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 6: Safety / Warning Symbols & Meanings
FIRE HAZARD WARNING (Electricity and electrical (Conditions and/or materials circuits present that may exist that may be flammable or cause electrical shock or cause a fire) sparking) 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 7: General Safety
C rating for electrical fires. This includes or cause adverse chemical reactions with certain ABC rated extinguishers. Halon (when permitted) battery types. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 8 It is recommended to allow the MOVING AND ROTATING PARTS. equipment to cool before handling any equipment Compressor belts, pulleys, fans, that may be hot. Pertains to all EPEQ products. ® and motors are used in EPEQ ®...
Page 9: System Overview
Up to 95% efficient compressor provides up to 20 CFM at 150 PSI • Strong built-in protections • Runs independently from the vehicle using 48V DC power 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 10: Installation Environment
Pure Sine wave 48V DC to 120V AC inverter wet and exposed to adverse environments. • 3000W output • 300A maximum DC The most robust components in the EPEQ line ® • Up to 93.5% efficient are the DC-DC Converters and Shore Power INVERTER5000 Charger.
Page 11: System Basics
This can cause damage to the cables which could result in failure, malfunction or damage to the equipment. Press connectors firmly together until they are fully secure. Figure 1-1 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 12: System Battery & Signal Cable Connection Diagrams
Generally, the orange cables shown on the • Use tools with insulated handles, (or wrap diagrams depict the 48V DC power cables handles with electrical tape). that are used between the different EPEQ ® • Wear insulated gloves. components. Many of the EPEQ components ®...
Page 13 052147 - EPEQ AIR20 SYSTEM SINGLE BATTERY - NOTES: 1. GRAYED OUT COMPONENTS INDICATE POWER CABLING DIAGRAM THOSE IN THE SYSTEM WITHOUT CABLE CONNECTIONS ELiMENT 100 283346-### 283346-### 283346-### 6210000 TO WALL 120V AC 6040226-001 283346-### 6230003 Diagram 1-1...
Page 14 052147 - EPEQ AIR20 SYSTEM NOTES: SINGLE BATTERY SIGNAL CABLING DIAGRAM CHARGER SAFETY IS UNUSED FOR THIS APPLICATION 2873599 CAN BE REPLACED WITH 283599 AND A TOGGLE SWITCH IF DESIRED GRAYED OUT COMPONENTS INDICATE THOSE IN THE SYSTEM WITHOUT HARNESS CONNECTIONS SYSTEMS EQUIPPED WITH THE AIR20 USE DISPLAY 604244, SYSTEMS WITHOUT THE AIR20 USE DISPLAY 6040226-001.
Page 15 052147 - EPEQ AIR20 SYSTEM, 6240000 - INVERTER 60000 OR, 624001 INVERTER 3000 & DC-DC CONVERTER CHARGERS - POWER CABLING DIAGRAM Notes: 6260001 - ASSY,EPEQ POWER DISTRIBUTION MODULE RECOMMENDED BREAKER SIZES: 6230000: 175A 6230004: 120A GRAYED OUT COMPONENTS INDICATES COMPONENTS IN THE SYSTEM WITHOUT...
Page 16 REGULATOR 11 YEL CAN_H 12 GRN CAN_L 180A MAX GRN CAN_L 6210000 48V DC YEL CAN_H 6230000 EPEQ 7” DISPLAY CONTROLLER 6040226-001 ORG PB OUT ORG PB IN CAUTION: High YEL CAN_H Voltage (+48V DC) GRN CAN_L on orange wires.
Page 17 4. 6230000 OR 6230004 TO BE INSTALLED NO FURTHER THAN 6 FT. FROM THE CHASSIS BATTERY INVERTER 6000 5. GRAYED OUT COMPONENTS INDICATE THOSE IN THE SYSTEM 7" DISPLAY EPEQ WITHOUT A HARNESS CONNECTION CONTROL PANEL 6. FOR SYSTEMS THAT REQUIRE LESS THAN 240V AC, THE 283346-### INVERTER6000 (PART NO.
Page 18 052147 - EPEQ AIR20 SYSTEM, 6240000 - INVERTER 6000 & DC-DC CONVERTER CHARGERS - SIGNAL CABLING DIAGRAM Notes: 6240000 - INVERTER,LF 6KW 283599 CAN BE REPLACED WITH 282932 AND A TOGGLE SWITCH IF DESIRED. GRAYED OUT COMPONENTS INDICATES COMPONENTS IN THE SYSTEM WITHOUT HARNESS CONNECTIONS.
Page 19 052147 - EPEQ AIR20 SYSTEM, 6240000 - INVERTER 6000 NOTES: 1. 283599 CAN BE REPLACED WITH 282932 AND A & DC-DC CONVERTER CHARGERS SIGNAL CABLING TOGGLE SWITCH IF DESIRED 2. GRAYED OUT COMPONENTS INDICATE THOSE IN THE SYSTEM WITHOUT A HARNESS CONNECTION 3.
Page 20 DANGER: SYSTEM MUST BE BONDED TO CHASSIS GROUND AND ALL PANEL BOX GROUNDS. FAILURE TO DO SECONDARY ALTERNATOR (48V) SO MAY RESULT IN INJURY OR DEATH. REGULATOR 12-48V DC 30A CONVERTER (POWER AND GROUND CONNECTIONS SHARE COMMON RAILS WITHIN THE INVERTER POWER DISTRIBUTION MODULES) 5000...
Page 21 052150 - EPEQ LEVEL 2 CHARGING SYSTEM, 10kW WITH 12V to 48V DC-DC CHARGER - POWER CABLING 6240002 - INVERTER,HF STACKABLE 5KW 240V 6240002 - INVERTER,HF STACKABLE 5KW 240V 6270000 - CHARGER LEVEL 2 EV 40A 5000W 5000W 283346-### 6220004 - BATTERY,ELiMENT100 48V 100AH...
Page 22 052150 - EPEQ LEVEL 2 CHARGING SYSTEM, 10kW WITH 12V to 48V DC-DC CHARGER - SIGNAL CABLING 6240002 - INVERTER,HF STACKABLE 5KW 240V 6240002 - INVERTER,HF STACKABLE 5KW 240V 6220003 - BATTERY,ELiMENT100 48V 100AH 6270000 - CHARGER BATTERY 1 LEVEL 2 EV 40A...
Page 23 DUAL BATTERY, MULTI-COMPONENT POWER DIAGRAM SECONDARY ALTERNATOR (48V) AIR 20 48-12V DC 60A REGULATOR 12-48V DC CONVERTER 30A CHARGER 30A MAX. MAX. +48V DC MAX. (POWER AND GROUND CONNECTIONS SHARE COMMON RAILS WITHIN THE FUSE GND +12V +48V DC POWER DISTRIBUTION MODULES) VEHICLE MAX.
Page 24 1 GRN CAN_L 2 YEL CAN_H 48V DC 6210000 48V DC 11 YEL CAN_H 12 GRN CAN_L EPEQ 7” DISPLAY CONTROLLER AIR 45 6040226-001 1 ORG PB OUT 2 ORG PB IN 1 YEL CAN_H CAUTION: HIGH 2 GRN CAN_L...
Page 25: Eliment™ Battery Setup
Always wear protective gloves if a battery leak is present and avoid contact with skin. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 26 ELiMENT™ battery has two sets of orange facilitate easy disconnection and relocation. power cables with Anderson-type connectors 6. Plug in the cable from the EPEQ charging ® which are installed at the factory to handle device using the orange battery connectors.
Page 27 • Turn off any connected equipment • Disconnect any signal or communications wires attached to the battery • Disconnect any charger connected to the battery 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 29: Shore Power Charger Setup
Anderson- 2. Plug in the Shore Power charger to begin type connector and is ready to connect to the charging. ELiMENT™ battery for reliable charging. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 30 7. (Refer to the Shore Power User Manual for proper ventilation for the battery and the more details and troubleshooting.) battery is not damaged or in an abnormal state. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 31: Air20 Air Compressor
ELiMENT™ battery however, • Wear eye protection during use as the power to the motor is controlled by a 3-way compressed air can send loose debris toggle switch attached next to the EPEQ ® 7” flying without notice Display Controller (See Figure1-7).
Page 32 12. If used - connect the CANBUS plug from the wire harness into the CANBUS connector ON the compressor to enable communication with OIL DRAIN DRAIN PLUG the ELiMENT™ Battery. See (Figure 1-5) HOSE Figure 1-6 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 33 Check pressure relief valve and sensor • Check that air filters are not dirty or clogged • Check for proper tension on belts • Battery level low - recharge battery as needed 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 35: 48V Dc-Dc Converter
• Negative (-) connector from the 12V battery hot, The case of the converter can connects to the Negative (-) INPUT terminal reach temperatures of 180° F (85°C) 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 36 If unit continues to fail after checking these the polarity. (If hardwired - be sure the polarity issues - please contact Vanair Customer ® is correct. Positive to Positive - Negative to Service. Negative) 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 37: 12V Dc-Dc Converter
Do not cover. OUTPUT terminal of the converter. 3. Locate where there is good air circulation. 4. Mounting holes are located in the unit’s base 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 38 If so, replace it. If an installed circuit breaker is tripped - reset the breaker. Check again to see if the converter is now functioning. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 39: Epeq ® Ev Charger
(see Figure 1-10) Use a dedicated circuit for 50A; 208-240 V replace the cover and (4) cover screws. Torque AC, 50-60Hz, single-phase circuit. = 13.88 lbs-in (16kgf-cm). 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 40 L1, the Black wire for L2 and the Green • Allen Key 3/16” wire for Ground. (See Figure 1-11) 8. The EPEQ™ EV Charger MUST be grounded INSTALL THE CHARGING STATION using a permanent wiring system or the use 1. Mounting bracket - push down on the “U”...
Page 41 2. To begin charging, lift the charger connector 8. Eight flashes - Pilot state is status F from the holster and insert it into the EV port 9. Nine flashes - Diode error 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 43: Epeq ® Inverter3000
• Banks of batteries are capable of disconnect both the AC and DC delivering very high levels of current which power to reduce risk of electric shock. can melt metals, cause combustion of 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 44 2. Verify the battery has an adequate charge the unit, please refer to the following.) level. (Starting with a fully charged battery 3. For best results, locate the battery bank as 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 45 - this combined surge could cause a fault. 8. When finished using the inverter, simply power down the connected devices and switch the inverter unit OFF 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 46 Vanair for assistance. rated voltage. Motorized appliances not Motorized tools and appliances Choose a higher power inverter. operating properly. require high start power that exceed inverter’s rated voltage. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 47: Epeq ® Inverter5000
Such a connection equipment or tools that will be attached could cause permanent damage to the to the INVERTER5000. equipment. If the unit survives such 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 48 9. Recommended DC circuit breaker specification side, and 20” (~50cm) above and below. Make for each inverter on the battery side: 150A / sure air can circulate freely around unit. 60V DC. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 49 DC BATTERY CABLES 4. Suggested AC wire size to connect AC INPUT GND the INVERTER5000 to AC power is 8 AWG. Figure 1-15 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 50 AC source or generator to be • DOWN - Go to next selection fed back into the inverter causing • ENTER - Confirm selection/Enter settings instant damage to the inverter 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 51 Battery voltage drops to either low-level warning voltage or the setting point in program 12 (Battery to Utility Transfer Voltage in “SOL Priority”). Once the solar power is lost, the utility will have 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 52 19, 20 and 21. This setting works for 03 APL: Appliance Mode GEL batteries etc. In Appliance Mode, the acceptable AC input voltage range is 90~280VAC±5V. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 53 RS485 communication protocol is L01 to L49. The battery SOC will be displayed when BMS The CAN communication protocol is L51 to L99. communication is established. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 54 When enabled, the unit will transfer to line mode in standby mode. (Switch off.) if overload occurs in battery mode. Power saving function will be automatically disabled when in parallel operation. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 55 23, and the lower two digits represent the time Program 41 Real time setting---Minute when utility end to charge the battery, setting Default 00, range 00~59 range from 00 to 23. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 56 23:00 to the next day at 20:59, and the inverter AC output power is prohibited outside of this period). (See Program Reference Tables on the next few pages). 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 57 09 AC Output Frequency 50Hz (Default) 10 Number of 12V Batteries The default value is 4 for Connected In Series 48V model, and 2 for 24Vdc model. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 58 20 Float Charging Voltage 21 Low DC Cut-Off Voltage Without BMS communication 21 Low DC Cut-Off Voltage With BMS communication 23 AC Output Mode Single Unit Operation 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 59 47 Equalization Interval Setting range is from 1 to 90 days. Increment of each click is 1 day. 48 Equalization Activated Disabled (Default) Immediately 48 Equalization Activated Enable Immediately 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 60 ① AC input power in Watts ② Inverter temperature ③ Load power in Watts ④ PV energy sum in KWH ⑤ Battery percentage ⑥Warning or Fault code 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 61 The unit will Charging by PV energy provide output Line Mode power from the mains. It can also charge the battery 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 62 7. Check for any fault indicators. If there is no from the AC power input. If AC connection is fault, system is completely installed. detected and all three phases are matched 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 64 EPEQ ® INSTALL GUIDE INVERTER5000 WIRING DIAGRAM FOR RUNNING MULTIPLE INVERTER5000 UNITS IN PARALLEL Two Inverters in Parallel BATTERY AC INPUT AC OUTPUT Communication Wire Connection 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 65 9. Finally, switch on the breakers on the LOAD only one will indicate “HS” the other L1-phase side. The inverters will provide 230V AC inverters will show “3P1”. power to the output. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 67 Over DC voltage in AC output Battery connection is open Current sensor failed Output voltage is too low Negative power fault PV voltage is too high Internal communication error 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 68 Beep once every second PV power insufficient Beep once every second Parallel forbidden without battery Beep once every second Parallel inverters’ capacity different BMS communication loss Beep once every second 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 69 Check if battery wires are connected well. switching on and off flashing repeatedly. Buzzer beeps Fault code 01 Fan fault. Check whether all fans are working properly. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 70 3. If problem still exists, contact repair center NOTE: To restart the inverter, disconnect all power sources. Once LCD display is off, restart the inverter using only the battery. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 71: Inverter6000
• Do not over tighten DC terminals. NOTE: Unit comes pre-wired for connection Torque rated at 17NM or 12.6 ft.lbs. to 48V DC power source utilizing Anderson 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 72 1. DIP switch settings (Refer to Figure 1-23 and the DIP Switch Table 1-1) SW1 (1) SW2 (0) SW3 (1) SW4 (1) SW5 (1) Figure 1-21 Figure 1-23 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 73 Acid Lithium type. Gel Euro 57.6 55.2 Open Lead Acid 59.2 53.2 Calcium 60.4 54.4 De-Sulphation 62.0 (4hrs then off) (Not Used) Battery Type Selector Table 1-2 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 74 See following pages for Troubleshooting Power Saver Auto Battery charger (shore power on) Unit Inverter (inverter power on) Alarm Power Saver (check alarm on box) Figure 1-25 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 75 Battery Continuous High beep Inverter Continuous Mode beep Overload Fault Output Continuous Mode Short beep Continuous Over-Temp beep Over- Continuous Charge beep Back Feed Continuous Short beep 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 76 DIP switch, or install between grid and inverting. sustain certain loads. a UPS if possible. Noise from Transformer/case. Applying specific loads Remove the loads. such as a hair dryer. 08/01/2023 (844) VAN-SERV • vanair.com © 2023 Vanair Manufacturing Inc. All rights reserved.
Page 77: Warranty
Vanair® or (Vanair® designated facility) within the first Vanair® must be notified in writing within thirty (30) days of any year of the applicable warranty period. Any additional expedited such defect or failure.
Page 78 PROVISION, MIGHT ARISE IMPLICATION, OPERATION OF LAW, CUSTOM OF TRADE, OR Vanair® must be notified in writing within thirty (30) days of any COURSE OF DEALING ARE EXCLUDED AND DISCLAIMED BY (844) VAN - SERV such defect or failure. All warranty or returns must be VANAIR®.
Page 79 1.) EPEQ Display Turns ON When Vehicle Key is ON Pass Fail 2.) With Key ON, Vehicle ON, You Can Turn the EPEQ Display OFF at the Display Fail Pass 3.) The 12V to 48V Converter Charger is Operating and Charging the ELiMENT Battery(s)
Page 80 1.) Ensure display is off before testing. Display should be tied to keyed ignition with the wake harness and turns on when the key is on. 2.) Press power button on EPEQ display. The display should turn off. If display does not turn off or gives an error banner, the wake harness is installed backwards.
Page 82 Parts Fax: (219) 879-5340 Service (toll free): (844) VAN-SERV (844) 826-7378 Sales Fax: (219) 879-5800 Telephone: (219) 879-5100 vanair.com ® Effective Date: 08/01/2023 © 2023 Vanair Manufacturing Inc. All rights reserved. Printed in the U.S.A. Specifications subject to change without prior notice.
