- Page 1 Operating and care instructions AERO Ventilation control unit Window systems Door systems Comfort systems...
-
Page 3: Table Of Contents
AERO – Operating and care instructions Ventilation control unit Table of contents ABOUT THIS DOCUMENTATION ... 4 Read the instructions .... 4 Producer . -
Page 4: About This Documentation
This information is aimed at all persons who carry out the following activities: • operation and maintenance of SIEGENIA products • operation and maintenance of window elements or door elements that are equipped with SIEGENIA products Other relevant information • Operating and service instructions for AEROMAT VT A / Z link.si/td/fens012/1023... -
Page 5: Safety
AERO – Operating and care instructions Ventilation control unit Safety Designated use • The ventilation control unit is an external, wired ventilation unit is out of reach, for example) or can control unit for SIEGENIA ventilation systems with be used for the synchronised control of up to 9 SI-BUS. -
Page 6: Product Specifications
AERO – Operating and care instructions Ventilation control unit Product specifications Operating element Item Name Purpose Status LED • Lights up white when the coupled ventilation units are switched on. ON/OFF button • Switches the coupled ventilation units on and off. -
Page 7: Operation
Y-adapter cable 3.2.1 Master functionality • The master is directly controlled by the ventilation • In the SIEGENIA Comfort app, the slaves and the control unit and transmits the commands to the ventilation control unit are displayed in the detail slaves. -
Page 8: Slave Functionality
3.2.4 Temperature and humidity sensor • The temperature and humidity sensor measures the temperature and humidity. • In the SIEGENIA Comfort app, the measured values are displayed in the detail view of the master. 3.2.5 CO2 sensor • The CO... -
Page 9: Ventilation Levels
AERO – Operating and care instructions Ventilation control unit 3.2.6 Ventilation levels • The air throughput can be set at 5 levels on the ventilation control unit. • The ventilation control unit displays the ventilation levels using 5 LEDs. • Following a power failure, the ventilation control unit switches to the last ventilation level used. -
Page 10: Technical Specifications
AERO – Operating and care instructions Ventilation control unit Technical specifications Ventilation control unit Ventilation control unit sensors Power consumption 0.6 W 0.8 W SI-BUS nominal voltage 24 V DC (+5 %, -10 %) 24 V DC (+5 %, -10 %) -
Page 11: Operation
AERO – Operating and care instructions Ventilation control unit Operation Pairing the ventilation control unit with ventilation units → All units that are connected are automatically Prerequisite integrated into the system one after the other. • All units that are to be paired are connected to →... -
Page 12: Activating And Deactivating Automatic Mode
AERO – Operating and care instructions Ventilation control unit Activating and deactivating automatic mode 1. Switch the paired ventilation units on by pressing 2. Activate automatic mode by pressing the "AUTO" the "ON/OFF" button. button. → If night ventilation was active, night ventilation is deactivated. -
Page 13: Setting The Led Brightness
AERO – Operating and care instructions Ventilation control unit Setting the LED brightness 1. Switch the unit on by pressing the "ON/OFF" 3. Press the "plus" button repeatedly until the desired button. brightness has been set. 2. Press and hold the "minus" button. -
Page 14: Troubleshooting
AERO – Operating and care instructions Ventilation control unit Troubleshooting Error messages 1. If this table does not describe the error, contact the producer: link.si/td/service001/0324 LED Possible cause Solution Ventilation control unit not paired Connect the ventilation control to the SI BUS system via the master menu... -
Page 15: Certificates
AERO – Operating and care instructions Ventilation control unit Certificates EU declaration of conformity We, the producer, hereby declare that our product complies with the following directives. Producer Product SIEGENIA-AUBI KG Device type: Type designation: Industriestraße 1 – 3 Central control unit for ventilation units... - Page 16 www.siegenia.com...
