What is in the box
1 - VP92 Video Player
1 - Remote Control
1 - 5' HDMI Cable
1 - USB Power Supply
1 - 5' USB Power Cable
1 - 5' 3.5mm to RCA A/V Cable
1 - Wifi Antenna
4 - Mounting Screws
Connections
The VP92 is capable out outputting
HDMI video to either 1 or both ports
(A - up to 4K or B - up to 1080)
(4)
The I/O port
is used for RS232/TTL
communication and connecting to our
line of interactive solutions including
PUSH, MOVE, SENSE, WAVE, RFID, SCAN,
TAP and ELEVATE. The USB on the front
or back
(3)
can be used for a keyboard
and/or mouse. Use the enclosed Wifi an-
tenna and attach to the threaded plug
(8)
if you plan to use Wifi. The audio jack
(9)
is used for outputing line level (not
amplified) stereo audio (R & L) . Use the
enclosed power supply
and make sure to line up
the pins on the plug and
then "Twist & Lock" the
plug into the jack (1).
Videotel Digital
Chula Vista, California
(619) 670-4412
www.videoteldigital.com
d
i
g
i
t
a
(5 &
6).
l
(3)
(1)
(2)
Remote Functions
Power On & Off
Change Video
Output -
HDMI
only (A/V is N/A)
Mouse Mode -
Press to enter
& exit "mouse
mode", then
use arrow keys
Home -
Returns
to start up
screen
Rewind
Play / Pause
Previous Video
Volume Down
Volume Up
Rotate
-Rotates
video counter
clockwise /
clockwise /
normal
VP92 Operation Manual
(13)
(3)
(4)
(5) (6)
(7)
OS Settings
-
(HDMI, Wifi,
Time, Date, Etc)
ALL -
tent on SD/USB/
Internal RAM
Turns on/off OSD
Arrow & SELECT
-
Navigate all op-
tions
Last -
previous screen
Fast Forward
Next Video
Stop Video
Mute Audio
Scale -
output
4 : 3 / 1 6 : 9 / f u l l
screen/origin
Zoom
screen size with
11 pre set op-
tions
(8)
(9)
Lists all con-
Returns to
Various
options
-
Trim
