Summary of Contents for Dockin D TUBE 2
- Page 1 D TUBE 2 D TUBE 2 B L U E T O O T H S P E A K E R B L U E T O O T H S P E A K E R U S E R M A N U A L...
-
Page 2: Table Of Contents
Explanation of symbols and terms ..............4 Proper use ........................5 Safety Notes ........................6 Checking the package contents ...............9 OPERATION Controls ...........................10 Turning the D Tube 2 on ..................11 Pairing ..........................11 Connections ........................12 Stereo link function ....................13 Technical Specifications ..................14 FAQ ............................15 Declaration of conformity ...................16... -
Page 3: Welcome To The Dockin Family
The love for music, sound and technology unites our team and makes our products unique in the audio landscape. You can find out more about us on www.dockin.net! Spotify: Instagram:... -
Page 4: Reading And Storing The User Manual
This user manual is based on the standards and rules in force in the European Union. When abroad, also be sure to observe the country-specific guidelines and laws. You can download this user manual as a PDF file at www.dockin.net under Support. EXPLANATION OF SYMBOLS AND TERMS Here, you will find a list of the safety-relevant symbols and terms, which are used in this user manual, on the D TUBE 2 or on its packaging. -
Page 5: Proper Use
The GS symbol on the mains adapter stands for tested safety. Products labelled with this symbol meet the requirements of the German Product Safety Act (ProdSG). This symbol indicates that the wall adapter is a device belonging to protection class II. Declaration of conformity (see chapter “Declaration of conformity”): This symbol indicates products that fulfil all applicable Community regulations in the European... -
Page 6: Safety Notes
SAFETY NOTES WARNING Risk of electrical shock! Improper handling, incorrect electrical installation or excessive mains volt- age may result in an electrical shock. Make sure that the mains voltage of the socket corresponds to the specification on the rating plate if you connect the D TUBE 2 to it for charging purposes. - Page 7 WARNING Risk of explosion and fire! Improper handling of the D TUBE 2 can cause the integrated rechargeable battery to explode or cause a fire. Do not subject the D TUBE 2 to excessive warmth or heat such as direct sunshine, fire or similar. Only use the power cable contained in the package contents to charge the D TUBE 2.
- Page 8 WARNING Health hazard! During operation, the D TUBE 2 generates magnetic fields, which can inter- fere with the functioning of medical devices such as pacemakers. Using the D TUBE 2 in certain locations can also result in faults or accidents. Always keep a distance of at least 10 cm between the medical device and the D TUBE 2.
-
Page 9: Checking The Package Contents
Take the D TUBE 2 and all accessories out of the packaging. 2. Use the following list to check whether the package contents are complete. The package contents contain the following individual parts: • D TUBE 2 speaker • USB charging cable • AUX cable (3.5 mm plug cable) •... -
Page 10: Controls
CONTROLS LED Indicator » Blue LED blinking - Bluetooth pairing mode » Blue LED lit - Bluetooth connected » Blue LED blinking fast - Max/Min Vol indicator [+] button » Press: Increase volume » Press and hold: Next song Power button »... -
Page 11: Turning The D Tube 2 On
Go to the Bluetooth® settings and scan for discoverable devices. Select “DOCKIN D TUBE 2” from the Bluetooth® device list. After successful pairing, the blue LED on your D TUBE 2 stays lit and you will hear a confirmation sound. -
Page 12: Connections
CONNECTIONS AUX port Battery indicator Connect the AUX cable, input will Four indicator LEDs show battery switch to AUX automatically and a charging level. Each LED equals 25% sound is played. charge. Micro USB C Port Micro SD Card slot »... -
Page 13: Stereo Link Function
STEREO LINK FUNCTION Pair two DOCKIN D TUBE 2: Power on both speakers and make sure they are not connected to any device. Press “M” button to disconnect, if necessary. Press “+” and “-” buttons on the first speaker (This will be the left speaker). -
Page 14: Technical Specifications
TECHNICAL SPECIFICATIONS 90mm 210mm Product: D TUBE 2 Bluetooth® speaker Item number: 15964 Rechargeable battery: Lithium ion (3,000 mAh) Music playback time: Up to 10 hours Drivers: 2x 60mm full range drivers, 2x 65mm passive radiators Frequency range: 65Hz-18kHz Nominal output:... -
Page 15: Faq
Information about the Bluetooth® function: Frequency range: 2.402–2.480 GHz Transmission power: 4 dBm Formats supported for audio files on Micro SD card: MP3, WMA, WAV, APE, FLAC Can not connect 1. Restart the Speaker 2. If passcode is needed enter “0000” Connection unstable 1. -
Page 16: Declaration Of Conformity
If you have questions regarding the D TUBE 2 or if any problems occur during operation or similar, first contact the following body via e-mail: info@dockin.net DOCKIN is a trademark of Stage10 GmbH | Torstr. 49 | 10119 Berlin | Germany... -
Page 17: Disposal
DISPOSAL Disposing of the packaging Dispose of the packaging sorted into single-type materials: • Paperboard and cardboard for recycled paper • Films in the recyclable material collection service Disposing of the device (Applicable in the European Union and other European states with systems separate collection reusable... -
Page 18: Fcc
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfe- rence, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. - Page 19 www.dockin.net...
