36”, 48” wide, gas cooktopsde
Hide thumbs Also See for Epicure ESG366:

Advertisement

Vertical Non-Combustible
Surface Rear Wall
22"
25" (635mm)
(559mm)
Typical Counter
3" (76mm)
Model No.
"A" Cooktop Width
ESG366
36" (914mm)
ESG486
48" (1219mm)
27" (686mm)
Top of
26 1/2" (673mm)
finished
2 1/2" (64mm)
counter
to combustible surface
7 3/4"
(197mm)
1 1/2" (38mm) Min.
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
EsG366, EsG486
36", 48" wide,
Epicure™ Gas Cooktops
091605
Utility Cutout
Location
3/4" Support
Platform
6"
(152mm)
"D"
1/2" (13mm)
Mounting Holes
"C"
"B"
"A"
CUToUT DImENsIoNs
"B" Cooktop Cutout
Width
34 3/4" (883mm)
46" (1168mm)
Combustible
rear wall
material
3/4" (19mm) Min.
Cooktop
platform
sIDE vIEw
"A"
ovErALL DImENsIoNs
(ESG486 Shown)
6"
(152mm)
"E"
10"
(254mm)
Min. to Combustible
side wall (both sides)
"C" Mounting Holes Set
Back
11 1/4" (286mm)
Specifications are subject to change without notice.
See installation instructions for additional details.
PLANNING
GUIDE
1/2
25 1/2"
(648mm)
3 1/2"
(89mm)
"D" Distance Between
Mounting Holes
33 1/4" (845mm)
41 5/16" (1049mm)
Optional Stainless Steel
Dacor Backsplash
(AEB3609 or AEB3612)
sIDE vIEw wITH bACksPLAsH
5/8"
(16mm)
"E" Distance from
Countertop
1 3/8" (35mm)
3 15/16" (100mm)
Combustible
Rear Wall
Material
3/4" (19mm) Min.
Cooktop
Platform
4.1
