Summary of Contents for Pressalit MCT 3
- Page 1 R9612717, R9612719 R9612721, R9632717 R9632719, R9632721 R9652717, R9652719 R9652721, R9662717 R9662719, R9662721 MCT 3 Change trolley – Operation and maintenance manual – Operation and maintenance manual...
- Page 2 English ..............The warranty covers faults or defects in the material of our products within a period of 3 years from date of invoice.
- Page 3 1 7 0 0 ( 6 6 . 9 R9612717, R9632717, R9652717, R9662717 1 9 0 0 ( 7 4 . 8 R9612719, R9632719, R9652719, R9662719 2 1 0 0 ( 8 2 . 6 R9612721, R9632721, R9652721, R9662721...
- Page 4 R9632717 R9632719 R9632721 R9652717 R9652719 R9652721 R9612717 R9612719 R9612721 R9662717 R9662719 R9662721...
- Page 5 R9612717, R9632717, 74 kg /163 lbs R9652717, R9662717 R9612719, R9632719, 76 kg / 167 lbs R9652719, R9662719 200 kg / 440 lbs R9612721, R9632721, 78 kg / 172 lbs R9652721, R9662721 Max P Max I R9632717, R9632719, R9632721 330W 100-240V 1,5 -2,75A R9652717, R9652719, R9652721 50/60Hz...
- Page 6 R9612721, R9632721, R9652717, R9662717 R9652719, R9662719 R9652721, R9662721 RZZZZYYYXXX-X XX-XX Hz IPXX YYYY-MM-DD U:XXXV P:X W I:XXA xxx kg xxx kg xxx lbs xxx lbs xxx kg xxx lbs YY-MM-DD Pressalit A/S, Pressalitvej 1 DK-8680 Ry +45 8788 8777, www.pressalit.com...
- Page 7 . 5 6 ( 2 7 7 0 0 1 5 5 3 ( 6 1 . 1 2 1 7 ( 8 . 5 1 5 8 ( 6 . 2 4 5 0 - 9 5 ( 1 7 .
-
Page 8: Table Of Contents
Content Symbols used in this manual..........9 General safety . -
Page 9: Symbols Used In This Manual
Symbols used in this manual The following symbols are used in this manual as well as the associated documentation supplied with the product. WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. - Page 10 Do not leave the user unattended. Compatible products Spare parts Max. user weight Article number/ versions Product weight Electrical data...
-
Page 11: General Safety
• The information in this manual is based on correct fitting of the product in accordance with our mounting instruction. • Pressalit cannot be held liable if the product is used in any way which differs from that described in the guide. -
Page 12: Safety Distances
Safety distances Make sure that the unit is at safe distance from surrounding objects. Check the distances before any use. ISO 17966:2016 Max 120/60 mm Min 300 mm Max 4.72/2.36” Min 11.81" Max 8/4 mm Min 25 mm Max 0.31/0.16” Min 0.98"... -
Page 13: Intended Use
Intended use This product is intended for changing a person who is unable to stand or sit. The person is lying horizontally on the change trolley. Intended operator profile Only personnel who are trained in healthcare and/or in changing someone under their care should use this product. -
Page 14: Contraindications For Use
Contraindications for use If the product is being used for users with damaged skin, wounds, or other similar conditions, it is recommended to use a towel as a barrier to prevent open wounds from coming into direct contact with the substrate. Biocompatibility The biocompatibility of the materials that come in contact with the user’s skin during the intended use has been evaluated according to the procedures... -
Page 15: Operating Instructions
Operating instructions Safety brakes The change trolley has brakes on all four wheels to prevent it from moving accidentally. To lock the brakes: Step on the To unlock the brakes: Step on the lock pedal on all four wheels to release button on all four wheels to engage the brakes. -
Page 16: Safety Rails
Safety rails The safety rails can be folded up and down individually for easy transfer of the user. To fold down: Lift the safety rail To fold up: Swing the safety rail up upwards to unlock it, and swing it and push it down to lock it in place. -
Page 17: Height Adjustment
Height adjustment 200 kg / 440 lbs The change trolley can be adjusted 500 mm / 19.69" up and down. The maximum height is 950 mm / 37.4". The height adjustment is controlled by the wired remote control unit. Press and hold the up button to raise the unit. When the button is released, the motion stops. -
Page 18: Moving
Moving To move the trolley, unlock all four wheels as described. Grab hold onto the lying surface itself, not the safety rails when moving the unit. Be careful when you move the unit. WARNING Make sure that the power cord is not wrapped around the user’s feet or positioned in a way that could lead to suffocation. -
Page 19: Accessories
A mounting instruction water or a mild soapy cleaning agent. is included with the 20XX-01-01 Page 1/4 mattress. A list of suitable cleaning agents/ disinfectants tested by Pressalit can be downloaded from be found on pressalit.com. pressalit.com. Mounting instruction Montage-voorschrift Monteringsvejledning... -
Page 20: Cleaning
IMPORTANT To maintain hygiene, it is recommended to check for any visible damages or signs of wear and tear on the mattress regularly. If any damages are found, the mattress should be replaced immediately to prevent any risk of contamination or infection. Cleaning To clean the product, use a damp cloth that has been wrung out in a mild soap mixture, such as universal cleaning solution. -
Page 21: Maintenance
Maintenance It is recommended that a maintenance inspection be carried out once a year. Maintenance inspection Lubricate the sliding rails at least every six months. Use a food grade grease. Check whether all nuts, screws and Check the wheels for corrosion. hinges have become loose. -
Page 22: Electromagnetic Compatibility
Electromagnetic compatibility WARNING • Use of accessories, transducers and cables other than those specified or provided by the manufacturer could result in increased electromagnetic emissions or decreased electromagnetic immunity of this equipment and result in improper function. • Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the unit, including its cables, to avoid any degradation of the performance of this unit. - Page 23 Immunity to proximity fields from RF wireless communication equipment Test standard Immunity test level EN 61000-4-3 385 MHz, 27 V/m, 18 Hz PM (50 % duty cycle square wave) 450 MHz, 28 V/m, FM +/- 5 kHz deviation, 1 kHz sine 710 MHz, 9 V/m, 217 Hz PM (50 % duty cycle square wave) 745 MHz, 9 V/m, 217 Hz PM (50 % duty cycle square wave) 780 MHz, 9 V/m, 217 Hz PM (50 % duty cycle square wave)
-
Page 24: Product Label
YY-MM-DD 2 min 18 min Pressalit A/S, Pressalitvej 1, DK-8680 Ry XXXXX Consult manual for use Medical device Maximum user weight Production date Article number Max load Mains voltage... - Page 25 • Council Directive 2006/42/EC (of 17 May 2006) on machinery. • Council Directive 2011/65/EC (of 8 June 2011) on RoHS. A declaration of conformity can be found at pressalit.com This product does not contain any of the hazardous substances mentioned in the Council Directive 2011/65/EC on RoHS.
-
Page 26: Storage And Transportation
Contact Pressalit A/S or your local dealer if the problem cannot be remedied. Do not attempt to repair the product yourself, as this will invalidate the warranty. Expected service life of the change trolley is 10 years. -
Page 27: Disposal And Recycling
Contact Pressalit for a list of available spare parts. Power cord Remote control EU/world LB0696 UK/IRL V6336 AUS/NZ T4285 T4361 US/CAN LB0688 Disposal and recycling The unit contains reusable materials. There are no known hazards or risks associated with disposal of the product. All components can be discarded after having been cleaned and disinfected.
