Summary of Contents for Citysports CS-WP9
- Page 1 User Manual MODE:CS-WP9 Please read this manual carefully and keep it properly before using the product! EU V1.2.2...
- Page 2 Step 3: Click the "Ask a Question" button. Choose your topic from list displayed. Step 4: Select Contact seller. *If you purchased CITYSPORTS products by other platforms or channels, please also find the corresponding seller contact support. Thanks for your support and patience!
- Page 3 EN------------------------------------------------------01 FR------------------------------------------------------21 DE------------------------------------------------------41 ES------------------------------------------------------61 IT-------------------------------------------------------81 NL-----------------------------------------------------101 PL-----------------------------------------------------121...
-
Page 4: Table Of Contents
Catalogue Safety Precautions and Warning Instructions--------------02 Product Instruction------------------------------------------------06 Installation Steps -------------------------------------------------08 Workout Routines ------------------------------------------------12 Manual Guidelines -----------------------------------------------13 Error Codes and Solutions ------------------------------------17 Maintenance -------------------------------------------------------19 Service Commitment----------------------------------------------20... -
Page 5: Safety Precautions And Warning Instructions
1.Safety Precautions and Warning Instructions Attentions: Please read the instructions carefully before use and pay attention to the follow- ing safety precautions: ◆The treadmill should be properly placed indoors to avoid moisture. It should not splash water on the treadmill or place any foreign matter. ◆Please wear proper sportswear and shoes before exercise. - Page 6 Warning! ◆When receiving treatment from a doctor or the following patients, please consult with a professional doctor before use. ◆(1) Those who are suffering from back pain now or have been injured in the past in their legs, waist and neck, and those who are numb in their legs, waist, neck and hands (those with chronic diseases such as intervertebral disc herniation, spondylolisthesis, cervical spondylosis, etc.).
- Page 7 Forbidden！ ◆ Do not use it when the shell is cracked, or peeled off (the internal structure is exposed) or the welding part is peeled off. ——Otherwise, accidents or injuries may occur. ◆ Do not jump up or down during exercise. ——Injury may result from falling.
- Page 8 Pull out the power plug! ◆ When not in use, pull out the power head from the socket. ——Dust and moisture will degrade the insulation, resulting in leakage fire. ◆ Be sure to pull out the power plug from the socket during maintenance. ——Failure to comply may result in electric shock or injury.
-
Page 9: Product Instruction
2. Product Instruction LCD Screen LCD Screen Holder Handlebar Button Knob Knob Safety Lock Left Tube Right Tube Top Shield Tube Cover Belt Sidebar Tube Cover Right Rear Tail Decorative Footpads Adjustable Footpads Decorative Footpads Left Rear Tail Package Lists： Name Remarks Quantity... - Page 10 Technical Parameter： AC 100-120V Voltage 50/60Hz Max Load 120 Kg Folding Size 1232*610*102 mm 1238*610*1030 mm Product Size Running Area 400*1020 mm Power 1400W Speed 1-12km/h Console LCD Screen Net Weight 26.5 kg Max. transmission power 8dBm (at the antenna input) Frequency Range 433.05~434.79 MHz Parts Lists：...
-
Page 11: Installation Steps
3. Installation Steps 1. Remove the main unit from the box and place it flat on the carpet or soft cushion, as shown in step ① of the following figure, first loosen the folding knob under the left and right risers by 2-3 turns counterclockwise, at this time the lower end of the risers will naturally rise up to the outside. - Page 12 3. As shown in step ④ below, pull out the pull pin on the top of the right and left risers, and then rotate the pin a little bit to make the pin snap into place. As shown in step ⑤, rotate the electronic watch stand to the horizontal position (pay attention to the communication line in the right riser to prevent extrusion), and then return the pull pin in step ④...
- Page 13 Footpad Installation and Adjustment 1 . First, use a packaging material to pad the front of the treadmill high; As shown in the picture on the right, screw the two pads into the screw holes, tighten clockwise and loosen counterclockwise. (The footpad can be mounted to elevate the runway, which users can install as required) 2.
- Page 14 2. As shown in step ② of the figure, fold the knobs below the left and right pillars and rotate counterclockwise to loosen them by 3 to 4 turns. 3. As shown in step ③ of the figure, slowly lower the electronic watch stand and the left and right vertical pipes onto the running platform.
-
Page 15: Workout Routines
4. Workout Routines Warm-up A warm-up exercise of 5-10 minutes is required before each operation. Breathing Do not hold your breath during the operation. Normally, when you are ready to restore your movements, breathe through your nose and exhale with your mouth. Breathing should be coordinated with your movements. -
Page 16: Manual Guidelines
1. Stretch down Your knees are slightly bent, your body slowly bends forward, your back and shoulders relaxed, and your hands touch your toes as much as possible. Hold for 10-15 seconds, then relax. Repeat three times (see Fig.1). 2.Stretching of hamstring Sit on a clean cushion and straighten one leg. - Page 17 1.Display and Key: (1) The LCD window displays the Time display range：0:00-99:59 following functions: Speed display range：1-12KM/H Time/Speed/Distance/Calorie Window: Distance display range：0.00-99.99 5 seconds to switch display time, speed, Calorie display range：0.00-9999 distance and calorie data， PAUSE (2)Spreadsheet function keys: 3, 6, 9, speed+, speed-, stop/stop. A.3: In the running state, at any speed, press the speed direct key, then the running speed of the running belt is adjusted to 3KM/H.
- Page 18 First of all, turn on your mobile phone Bluetooth, long press the "-" key on the armrest, with a beep when the Bluetooth device name "CITYSPORTS-Audio" appears on your phone then connect it, and then the screen shows the Bluetooth logo indicates that the Bluetooth has been connected, and wait until you hear the ding-dong alert that means the match is completed.
- Page 19 -16-...
-
Page 20: Error Codes And Solutions
6. Error Codes and Solutions If you have any other questions, please call your dealers or our company's after-sales service. -17-... - Page 21 Fault Cause Solution not plugged in Insert the power plug into the outlet The power switch is not Treadmill Put the power switch in the ON position turned on not work- Safety lock not in place Put the safety lock in place circuit signal system maybe Check controller inputs and signal lines open circuit...
-
Page 22: Maintenance
7.Maintenance Keep your treadmill at its best forever, and incorrect maintenance can damage or shorten its life. a.Frequent inspection is required due to wear and tear; Worn or damaged acces- sories, such as motors, electronic controls, power lines, running belts, may be repaired or professionally repaired to the same degree of safety as when they are removed. -
Page 23: Service Commitment
3、Adjust the belt tension. All treadmills should adjust the belt tension before and after installation, but the belt tension may occur after a period of time. For example, it causes the runners to stop and slip when running. When this phenomenon occurs, adjust the adjusting bolt of the running belt from left to right in a clockwise direction with half a turn as the unit. - Page 24 Remote control warning This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 25 Household electric treadmill FCC ID:2BEPD-HET IC:31938-HET HVIN:CS-WP9 FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
