3M Versaflo TR-600 User Instructions
Used with battery chargers
Hide thumbs
Also See for Versaflo TR-600:
- User manual ,
- User instructions (35 pages) ,
- Quick start manual (3 pages)
Table of Contents
Advertisement
Quick Links
PSD Technical Content
Review Summary
Project Title: PSD - TR600 Battery UI
Details of Request:
Technical Content
MIRANDA DE LA VICTORIA
Contact:
Today's Date:
11/8/2022 3:42:44 PM
Date Needed:
2022-11-11
Requestor:
Jimmy Wong
Canada Use
-
Pre-Approval:
Collaborative
Nicole Idle
Review:
Management
scott larson
Review:
Legal Review:
lisa brihn
Content Summary:
Portfolio:
Respiratory
Region:
USAC
Audience:
External
Asset Type:
Instructions
Translations Needed:
Additional Comments:
Urgent in regards to active EARRP. Product production on hold. Only numerical/icon updates! No translation needed. Spoke to
Scott Lason, and this only needs to be acknowledged by himself, legal, and Nicole Idle in quality engineer for batteries. Changes
are found on "Specifications Table" AND "number of cycles" updates found in the verbiage outside the table (change from 250
cycles to 500 cycles).
Advertisement
Table of Contents
Related Manuals for 3M Versaflo TR-600
Summary of Contents for 3M Versaflo TR-600
- Page 1 PSD Technical Content Review Summary Project Title: PSD - TR600 Battery UI Details of Request: Technical Content MIRANDA DE LA VICTORIA Contact: Today’s Date: 11/8/2022 3:42:44 PM Date Needed: 2022-11-11 Requestor: Jimmy Wong Canada Use Pre-Approval: Collaborative Nicole Idle Review: Management scott larson Review:...
- Page 2 UI-98-0060-0224-4_3 Activity Summary for TR-600 Chargers and Battery Packs Initials Date Comments Sept 20, Added markings for California Energy Directive. Updated warnings to match other 2016 Versaflo charger and battery UI. Information. Updated format to match other Versaflo UI. Updated copyright 2016...
- Page 3 In Canada, CSA standard Z94.4 requirements must be met and/or requirements of the applicable jurisdiction, as appropriate. Misuse may result in injury, sickness or death. For proper use, see supervisor, User Instructions, or call 3M PSD Technical Service in USA at 1-800-243- 4630 and in Canada at 1-800-267-4414.
-
Page 4: Contact Information
System Description The 3M™ Single Station Battery Charger Kit TR-641N and 3M™ 4-Station Battery Charger Kit TR-644N are for charging the TR-630 Standard Battery and TR-632 High Capacity Battery for use with the 3M™ Versaflo™ Powered Air Purifying Respirator TR-600 Assemblies. - Page 5 Batteries may continue to be used as they age, as long as battery run time is sufficient to power the PAPR for sufficient time to safely perform the given task and exit the contaminated area. The following guidelines will help maximize useful life of the 3M battery packs. Contact 3M Technical Service for additional guidance if needed.
-
Page 6: Charge The Battery Pack
4. Battery charging: Ensure the gold electrical contacts on the battery and charger are clean and free of debris. Insert the battery pack into the 3M™ Battery Charger Cradle TR-640 by sliding the back end of the battery pack in first. Set front end down and click into place (Fig. 2), charging will begin. Refer... - Page 7 TR-630 and TR-632 battery packs. Battery Pack Connection to TR-600 Series PAPR Refer to the User Instructions for the 3M™ Versaflo™ Powered Air Purifying Respirator TR-600 assembly for specific directions on connecting and disconnecting the battery pack from the PAPR unit.
- Page 8 In the United States and Canada, 3M participates in the Call2Recycle program which provides for 3M™ PAPR Batteries to be dropped off (free of charge) at participating recycling collection sites. Please dispose of batteries according to federal, state, provincial and local regulations.
-
Page 9: Battery Pack
Weight • Approx. 1 lb (450 grams) 3M™ Standard Battery TR-630 • Approx. 1.3 lbs (620 grams) 3M™ High Capacity Battery TR- Electrical • Nominal 11.1 Vdc, 5.2 Ah., 58 Wh 3M™ Standard Battery TR-630 • Nominal 11.1 Vdc, 7.8 Ah., 87 Wh 3M™... -
Page 10: Charger Power Supply
100-240 V; 50-60 Hz; • DC Output 1.5A 19 V; 2.37 A • Fuse Fuse is not user replaceable 3M™ Power Supply for TR-944N ( for 4-Station Charger Base) • AC Input 100-240 V; 50-60 Hz; 2 A • DC Output 19 V;... - Page 11 DEFINITIONS OF PRODUCT ICONS Explanation of device markings containing safety information Symbol Description To reduce the risk of injury, user must read instruction manual Warning Warning – See product User Instructions Dangerous voltage Power ON or Off Battery should be charged immediately and fully upon receipt Battery should be fully recharged at least every 9-12 months...
-
Page 12: Troubleshooting
Do not use the chargers outdoors or in wet environments. Use this table to help identify possible causes and corrective actions for problems you may experience. Contact 3M Technical Service to help identify possible causes and corrective actions for any other problems. Problem... -
Page 13: Important Notice
User Instructions and/or recommendations. The only 3M obligation under this Warranty will be, at the option of 3M, to repair or replace without charge any defective parts of the 3M™ Versaflo™ respirator product returned to 3M in accordance with the instructions below and found by 3M to have been defective or during the warranty period as applicable. -
Page 14: Fcc Compliance
OR OTHER WARRANTY OF QUALITY, EXCEPT OF TITLE AND AGAINST PATENT INFRINGEMENT. LIMITATION OF LIABILITY: Except as provided above, 3M shall not be liable or responsible for any loss or damage, whether direct, indirect, incidental, special or consequential, arising out of sale, use or misuse of 3M™... - Page 15 Thank You, Nicole Nicole M Idle | Quality Engineer, Senior Personal Safety Division 3M Center, 235-02-C-89 | St. Paul, MN 55144-1000 | United States Office: +1 651 733 6210 nidle@mmm.com From: Miranda De la Victoria <mkdelavictoria@mmm.com> Sent: Tuesday, November 8, 2022 12:30 PM To: Nicole Idle <nidle@mmm.com>...
- Page 16 Miranda De la Victoria | Advanced Technical Writer Personal Safety Division 3M Center | St. Paul, MN 55144-1000 | United States mkdelavictoria@mmm.com...
